User Manual
• Set IP Address, Subnet Mask and Default Gateway IP Address
Please refer to Fig. 2-6 Console Management for details about the ex-factory
setting. They are default setting of IP address. You can first either configure your PC
IP address or change IP address of the switch, next to change the IP address of
default gateway and subnet mask.
For example, your network address is 10.1.1.0, and subnet mask is
255.255.255.0. You can change the switch's default IP address 192.168.1.1 to
10.1.1.1 and set the subnet mask to be 255.255.255.0. Then, choose your default
gateway, may be it is 10.1.1.254.
Default Value
IP Address
Subnet
Default Gateway
After completing these settings in the switch, it will reboot to have the
configuration taken effect. After this step, you can operate the management through
the network, no matter it is from a web browser or Network Management System
(NMS).
Publication date: May, 2005
Revision A1
GSW-1291
192.168.1.1
255.255.255.0
192.168.1.254
Table 2-3
Fig. 2-7 the Login Screen for CLI
18
Your Network Setting
10.1.1.1
255.255.255.0
10.1.1.254
