LevelOne OfficeCon GSW-2420 Specifications

16-Port
10/100/1000 Mbps
with 4-Port SFP
H/W Version: 2
Product Overview
GSW-1656 is a Gigabit switch that is the ideal solution
for networks that demand a reliable and stable high-
bandwidth environment to connect workgroups with
file servers. GSW-1656 has 16 10/100/1000 Mbps Nway
ports of which 4 ports are SFP shared ports. These SFP
ports are Mini-GBIC ports for obtaining long distance
network connectivity via fiber optic connections.
With a 32 Gbps backplane, GSW-1656 provides high-
speed data transmission through effective buffering
to each port. With a store-and-forward switching
architecture the data flow between transmit and
receive nodes is controlled to protect against packet
loss.
Save Power With LevelOne Green Technology
Active Link Detection: A LevelOne Green device can
Key Features
- IEEE802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3z
compliant
- 24 10/100/1000 Mbps RJ-45 Nway ports
- 4 shared Mini-GBIC ports for optional fiber optical
communication
- Wire-speed packet filtering and forwarding rate
- Supports 9K bytes Jumbo frame
- Supports 8K bytes MAC address entries
- 340K bytes buffer memory
- RoHS compliant with FCC,VCCI and CE Class A
certification
- Save up to 56% power compare to non Green Switch
with similiar functions

1 2
1. LEDs
2. 10/100/1000 Mbps
3. SFP Slot
4. Internal power socket
tell if there is activity on each individual LAN port. If an
8-port switch only has 6 active devices connected to
it, power is saved because no traffic is routed to the 2
inactive ports.
Cable Length Detection: The switch is able to detect
the distance of the connected device and adjusts
its power accordingly. For example, if you have a
LevelOne Green switch a computer connected to
a 10-meter cable will consume less power than a
computer connected to a 100-meter cable.
Sleep Mode: The device will enter sleep/standby mode
when the connected devices are powered down and
no active links are detected. This helps save energy
consumption during extended periods of network
inactivity, such as nights,
weekends and holidays.
3
Related Products
GSW-1656
4
GSW-2456
24-Port 10/100/1000Mbps
w/4-Port SFP
GSW-2420
24-Port 10/100/1000Mbps
