ADV3221-EVALZ/ADV3222-EVALZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Item Qty Description
1 6 Capacitor, ceramic, chip, X8R, 0.1 µF
2 2 Capacitor, ceramic, monolithic, X5R,10 µF
3 2 Capacitor, ceramic, X7R, 0.01 µF
4 1 Capacitor, ceramic, 6.8 pF
5 2 Do not install (TBD_C0603)
6 5 Switch, PCB mount slide
7 2 Generic SO16 footprint chip
8 13 Connector, PCB pin vector
9 14 Connector, PCB, coaxial, SMA end launch
10 7 Connector, PCB, BNC, RA, insulated, PCB socket, 75 Ω, BLK
11 1 Connector, PCB, header, 3 position
12 5 Connector, PCB, straight, header, 3 pin
13 1 Connector, PCB, shrouded, header, 34 position, straight
14 4 Resistor, ultra precision, ultra reliability, MF chip, 49.9 Ω
15 6 Resistor, precision, thick film chip, R0603, 49.9 Ω
16 3 Resistor, precision, thick film chip, R0402, 49.9 Ω
17 1 Resistor, ultra precision, ultra reliability, MF chip, 150 Ω
18 4 Resistor, precision, thick film chip, R0402, 75 Ω
19 1 Resistor, film, SMD, 0603, 75 Ω
20 1 Resistor, thick film chip, 0603, 86.6 Ω
Manufacturer
TDK
Murata
Phycomp (Yageo)
Samsung
TBD_C0603
SECMA
Not Applicable
Vector
Johnson
Tyco Electronics
Molex
Molex
3M
Susumu
Panasonic
Panasonic
Susumu
Panasonic
Vishay
Panasonic
Rev. 0 | Page 9 of 10
Reference
Manufacturer Part No. Designator
C1608X8R1E104K C1, C2, C8, C17,
C28, C29
GRM31CR61E106KA12L C7, C16
2238 586 15636 C9, C18
CL05C6R8DBNC C3
TBD_C0603 C4, C5
09-03-201-02 S1 to S3, CK1, CK2
GEN_SO16 DUT_50, DUT_75
K24A TP1 to TP9,
GND1 to GND4
142-0701-851 J1 to J4, J6, J8 to
J10, S4, S5, J12,
J13, J17, J18
1-1634622-0 J14 to J16, J21,
J23 to J25
22-23-2031 P1
22-03-2031 P2, P4-P7
2534-6002UB P3
RG1005P-49R9-B-T5 R1 to R4
ERJ-3EKF49R9V R5 to R8, R10, R11
ERJ-2RKF49R9X R9, R12, R13
RG1005P-151-B-T5 R23
ERJ-2RKF75R0X R25 to R28
P0603E75R0BBT R30
ERJ-3EKF86R6V R31
UG-844
