Levitronix PuraLev i100SU User Manual page 5

System Name Article # Pump Head Socket
PLD-i100SU.1 100-91054 PHS-i100.1
PLD-i100SU.5 100-91511 PHS-i100.1
PLD-i100SU.2 100-91095 PHS-i100.1
PLD-i100SU.3 100-91055 PHS-i100.1
Pos. Component
1a
1b
Single-Use (SU)
1c
Pump Heads
1d
SU Pump Head
1e
with Sterile Fittings
Integrated Pump Driver
2a
("OEM Model")
Integrated Pump Driver
2b
("EasyConnect" Model)
Integrated Pump Driver
2c
("Stand-Alone" Model)
Integrated Pump Driver
2d
("OEM ATEX" Model)
3 Pump Head Socket
Note 1: Designed and tested for IP67. Note 2: Serial pumping as one unit according to Figure 6 special firmware available on request.
Pos. Component
4a AC/DC Power Supply
Desktop AC/DC Power
4b
Supply
AC Mains Cables
4c
(for Desktop power supply 5b)
USB to RS485
5
Adaptor-TR Isolated
IPS Cable Power 2
6
Wires
IPS Cable Signal 6
7a
Wires
IPS Cable Signal 6
7b
Wires
IPS Cable Signal 12
8
Wires
Fieldbus Termination
9
Connector
10 User Panel
ATEX Cable
11
Sealing System
PL-4063-00, Rev03, DCO# 20-275
Driver
IPD-100.1-50-02
IPD-100.10-50-02
IPD-100.4-02
IPD-100.6-02
Table 1: Standard driver system configurations
Article Name Article #
100-90734
DCP-200.2 (Triclamp)
100-90792
DCP-200.3 (Barb)
100-91078
DCP-200.2-G25
100-91122
DCP-200.3-G25
(Gamma Irradiated with
Dosage ≥ 25 kGy)
DCP-200.3-SF1-G25 100-91233
IPD-100.1-50-02 100-10070
IPD-100.4-02 100-10111
IPD-100.6-02 100-10106
IPD-100.10-50-02 100-10201
PHS-i100.1 100-91053
Table 2: Specification of standard components
Note 3: CPC ® and AseptiQuik ®
Article Name Article #
TSP 180-124 (Traco) 100-40018
GST160A24-R7B
100-40020
IC915
AMC-1.1 (2m) 190-10331
AMC-1.2 (2.5m) 190-10332
AMC-1.3 (2.5m) 190-10333
AMC-1.4 (2.5m) 190-10334
AMC-1.5 (2.5m) 190-10335
YN-485I-TR 100-30392
ICP-2.1-50 (5 m) 190-10370
ICS-1.1-02 (0.2 m) 190-10381
ICS-1.1-10 (1 m) 190-10344
ICS-1.1-30 (3 m) 190-10345
ICS-1.2-50 (5 m) 190-10346
ICS-2.1-50 (5 m) 190-10347
FTC-1.1
190-10348
LUI-B.1-01 100-30448
ACS-A.1
100-90292
(Roxtec)
Table 3: Specification of cables and other accessories
1: Designed and tested for IP67.
Note
OEM - Driver, 5 m PVC cable with open wires, pump head socket.
OEM - ATEX/IECEx - 5 m FEP cable with open wires, pump head socket.
EasyConnect - Driver with interface connectors, pump head socket.
Stand-Alone - Driver with integrated user panel, pump head socket.
Characteristics Value / Feature
Impeller / Pump Housing Polypropylene (FDA, USP Class VI, BSE/TSE/Animal free)
Housing Sealing Infrared welding
Triclamp ½" or Barb ½ for tubing with typical ID 3/8""
In-/Outlet Fittings
Max. Flow 17 liters/min / 4.5 gallons/min
Max. Diff.-Pressure 2 bar / 29 psi
Max. Viscosity < 20 cP
Wet Pump
24 ml / 150 cm
Volume/Surface
Max. Liquid Temp. 60 0 C / 140 0
Applicable Sterilization Gamma radiation up to 40kGy
Pump Type (A) / Tubing
DCP-200.3 (Barb) / Silicone
(C)
AseptiQuik
Sterile Fittings (B)
Various sizes and types including autoclavable versions available at CPC
Fitting Compatibility
≥ 25 kGy
Applied Gamma Dosage
24 VDC ±10%, 110 W
Voltage, Power
Epoxy coated Alu., IP65
Housing / Cable
PLC and RS485 with Modbus protocol (see Error! Reference source not found. f
Interfaces
or details)
Standard Firmware
G3.48
Housing Epoxy coated Aluminum, PP for bottom lid, IP65
Interfaces 2x Fieldbus RS485 with Modbus protocol, PLC and power supply
Standard Firmware G3.48 2
Housing Epoxy coated Aluminum, PP for bottom lid, IP65
Interfaces User panel with 3 user buttons, PLC and power supply
Standard Firmware G3.48
ETFE coated Alu., IP65
Housing / Cable
PLC and RS485 with Modbus protocol
Interfaces
ATEX / IECEx Marking
II 3G Ex ec h mc IIC T4 Gc /
Standard Firmware
G3.48
Mounting Type Bayonet type with locking pin
Material Anodized Aluminum
Assembly Screws 4 pcs M3 x 8 mm (Stainless Steel, INOX A4)
are registered marks of the Colder Product Company.
Characteristics Value / Feature
Voltage Output / Input 24 VDC with 180 W
Basic Dimensions 110 x 110 x 54 mm (mountable on DIN rail 35 mm)
Certification or Standards UL/cUL, CB, Semi F47
Voltage Output / Input 24VDC, 160W
Basic Dimensions 175 x 72 x 35 mm
Safety Approvals UL60950-1, CSA C22.2, TUV EN60950-1
Note Connector for direct connection to power supply of driver with cable length 1.2 m.
Approvals and Country UL, cUL, US, Canada
Approvals and Country CB, Germany, Denmark, Norway, Finland, Belgium, Netherl., Sweden, Austria
Approvals and Country PSE, Japan
Approvals and Country Switzerland
Approvals and Country CE, United Kingdom
Cable Specifications Black color, ROHS
Structure/Design USB connector (A) with termination resistor and cable (2m) with connector pair (B
and C) for external RS485 wire connection. Magnetically isolated. Cable length is
2m. Included is a USB space saver cable (D).
Purpose Communication over fieldbus of driver with PC
Cable Material / Wires PVC jacket / 2x 1.5 mm
Connection In / Out Open wires / Circular Intercontec type to driver
Connection of power supply to "Stand-Alone" and "EasyConnect" drivers
Main Purpose
Cable Material / Wires PVC jacket / 6x 0.08 mm
Connection In / Out Circular Hirose type / Circular Hirose type
Fieldbus connection between "EasyConnect" drivers (e.g. multi-pump arrays)
Main Purpose
PVC jacket / 6x 0.08 mm
Cable Material / Wires
Connector with screw type plug for open wire connection / Circular Hirose type
Connection In / Out
Fieldbus connection to "EasyConnect" drivers and to PLC of "Stand-Alone"
Main Purpose
drivers.
Cable Material / Wires PVC jacket / 12x 0.14 mm
Connection In / Out Connector with screw type plug for open wire connection / Circular Hirose type
General connection to PLC of "EasyConnect" drivers.
Main Purpose
Materials PPS for connector housing and FPM for sealing.
Main Purpose Termination of fieldbus.
Interface / Housing Rating RS485 / IP65
Standard Firmware A3.00
Sleeve (A) and Gasket (B) Stainless Steel and EPDM
Frame (C) Roxylon (EPDM rubber)
2x Cable Module (D) Roxylon (EPDM rubber)
User Manual for PuraLev
www.levitronix.com
2 with Triclamp and 25 ml / 150 cm 2 with Barb fittings
F
® G from CPC ® with part # AQG17008 3
1 / PVC jacket, open wires, cable length 5 m
1 / FEP jacket, open wires, cable length 5 m
II 3D Ex h tc IIIC T90°C Dc
85 – 132 and 187 – 264 VAC (autoselect)
/
85 – 264 VAC, 47-63 Hz
/
2
2 and shielding
2
and shielding
2 and shielding
Note:
Lubricant (E) and measurement
plates (F) are included.
®
i100SU
®
