Levitronix PuraLev i100SU User Manual page 13

6
IPS Cable Power ICP-2.1 (for EasyConnect and Stand-Alone drivers)
to driver DC supply
7b IPS Cable Signal ICS-1.2 (for EasyConnect and Stand-Alone drivers)
EasyConnect driver: to fieldbus
Stand-Alone driver: to PLC
Figure 16: Basic dimensions and specifications of standard cables
Table 5: Specifications for min. bending radius of cables
Note: If not mentioned explicitly all the cables are not suited for constant dynamic bending and movement!
PL-4063-00, Rev03, DCO# 20-275
Wire size: 1.5 mm
Signal wires 1-14 are
cut off and not used.
to AC/DC Supply
Screw type wire
connector
Wire size: 0.08 mm 2
to external interface
Cable Cable Minimum Bending Radius
Jacket Diameter Permanent Installation
PVC 8.4 mm
User Manual for PuraLev
7a
IPS Cable Signal ICS-1.1 (for EasyConnect drivers)
2
to driver fieldbus OUT
8 IPS Cable Signal ICS-2.1 (for EasyConnect drivers)
to driver PLC
7x Cable OD
®
i100SU
www.levitronix.com
Wire size: 0.08 mm
to driver fieldbus IN
Screw type wire
connector
Wire size: 0.14 mm 2
to external PLC
Minimum Bending Radius
Sometimes Moved
15 x Cable OD
2
13
