7 Troubleshooting

7.1 Trouble Shooting with Stand-Alone Model

For troubleshooting and failure analysis with the Stand-Alone model the integrated display gives advice about
status and potential failure details.
If the PLC is used the digital output ("Status") indicates if the system is active. However, the source of an error
cannot be identified by this signal.

7.2 Trouble Shooting with EasyConnect and OEM Models

7.2.1 Troubleshooting for Operation with Driver
The integrated PLC provides a Status and Error signal feedback according to Table 14. However, the source
of error cannot be identified by these signals.
For more detailed analysis the Levitronix
interface cable.
7.2.2 Troubleshooting with Levitronix

The Levitronix Service Software allows communication with the pump system in connection with a PC and a
USB interface. The USB to RS485 adaptor cable as specified in Table 3 can be used to setup communication.
The software can be used for performing detailed troubleshooting.
7.2.3 Troubleshooting with User Panel LUI-B.1
For troubleshooting and failure analysis with the user panel LUI-B.1 the integrated display gives advice about
status and potential failure details.

8 Technical Support

For troubleshooting, support and detailed technical information contact Levitronix
Department:
PL-4063-00, Rev03, DCO# 20-275

Service Software can be used with a PC and a USB to RS485

Levitronix
Technical Service Department
Technoparkstr. 1
CH-8005 Zurich
Switzerland
Phone for US:
Phone for outside US:
E-Mail:
®
Service Software
888-569 07 18
+1 888-569 07 18
TechSupport@levitronix.com
User Manual for PuraLev
www.levitronix.com

Technical Service
®
i100SU
