UG-965

ORDERING INFORMATION

BILL OF MATERIALS

Table 4. EVAL-MBnanoDAC-SDZ
Reference Designator
C1, C6, C7, C9
C2, C5, C8, C10, C15 to C17
C3, C4
C11
EXT_REF_1 to EXT_REF_4
J1
J2
J3, J7, J8
J4
J5
J6
J9
J10
L1
LK5
LK6, LK7
REF1 to REF 4
R1
R2, R3
R5 to R15
U2
U3
U4
U5
U6
U7
U10
U11, U12
1 FEC refers to Farnell Electronic Component Distributors.
2 GRM refers to Murata Manufacturing Company.
Table 5. EVAL-AD5313RDBZ
Qty Reference Designator
2 C1, C3
2 C2, C4
2 C5, C8
1 J1
1 J2
1 J3
1 J4
2 LK1, LK2
2 R1, R2
4 R3, R4, R7, R8
3 R5, R6, R9
1 U1
1 VOUT_A
1 VOUT_B
1 FEC refers to Farnell Electronic Component Distributors.
Motherboard
Description
6.3 V tantalum capacitors (Case A), 10 µF, ±20%
50 V, X7R ceramic capacitors, 0.1 µF, ±10%
10 V, X5R ceramic capacitors, 1 µF, ±10%
6.3 V tantalum capacitor (Case A), 4.7 µF, ±20%
Straight PCB mount SMB jacks, 50 Ω
Header, 2.54 mm, 2 × 8-way
Header, 2.54 mm, 2 × 5-way
Header, 2.54 mm, 1 × 6-way
Header, 2.54 mm, 1 × 8-way
3-pin terminal block
2-pin terminal block
Header, 2.54 mm, 2 × 4-way
120-way connector
Inductor, SMD, 600 Ω
6-pin (3 × 2-way) 0.1 inch header and shorting block
4-pin (2 × 2-way) 0.1 inch header and shorting block
10-pin (5 × 2-way) 0.1 inch header and shorting block
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistors, 100 kΩ, 1%, 0603
SMD resistors, 100 Ω, 1%, 0603
3.3 V linear regulator
32 kΩ I 2 C serial EEPROM
5 V reference MSOP
Ultralow noise XFET® voltage reference
4.096 V reference
Dual-op amp
Quad-op amp
Op amp
Daughter Board
Description
50 V, X7R ceramic capacitors
6.3 V tantalum capacitors (Case A)
Do not insert
16-pin (2 × 8-way) header
10-pin (2 × 5-way) straight header, 2.54 mm pitch
6-pin (1 × 6-way) straight header, 2.54 mm pitch
Header, 2.54 mm, PCB, 1× 8-way
Jumper blocks using 3-pin SIP header
Do not insert
Do not insert
Resistors, 0603, 1%, 0 Ω
10-bit DAC
Red test point
Red test point
Supplier
FEC 1190107
FEC 1759122
GRM188R61A105A61D
FEC 1432350
FEC 1206013
FEC 2308428
FEC 9689583
FEC 9689508
FEC 1766172
FEC 1667472
FEC 151789
FEC 1667509
FEC 1324660
FEC 9526862
FEC 148-535 and FEC 150-411 (36-pin strip)
FEC 148-535 and FEC 150-411 (36-pin strip)
FEC 1022227 and FEC 150-411
FEC 1627674
FEC 9330402
FEC 9330364
ADP121-AUJZ33R7
FEC 1331330
ADR445ARMZ
ADR431BRZ
REF198ESZ
AD8616ARZ
AD8608ARMZ
AD8655ARMZ
Rev. A | Page 12 of 13
EVAL-AD5313RDBZ User Guide
1 /Part Number
2
Supplier 1 /Part Number
FEC 1759122
FEC 1190107
Do not insert
FEC 2308428 inserted from solder side
FEC 9689583 inserted from solder side
FEC 9689508 inserted from solder side
FEC 1766172 inserted from solder side
FEC 1022248 and FEC 150410
Do not insert
Do not insert
FEC 9331662
AD5313RBRUZ
FEC 8731144 (pack)
FEC 8731144 (pack)
