- Page 1 User Manual PCIE-1203 EtherCAT Master PCI Express Card...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. PCIE-1203 User Manual...
-
Page 5: Table Of Contents
Chapter Hardware ..........13 Outline..................... 14 Table 3.1: Point to point............. 14 Board ID Switch (SW1) ................14 Table 3.2: Board ID Setting ............14 LAN Port (LAN1, LAN2) ................15 D-Sub Connector (CN8)................15 3.4.1 Wiring..................16 PCIE-1203 User Manual... - Page 6 PCIE-1203 User Manual...
-
Page 7: Chapter 1 Introduction
Chapter Introduction... -
Page 8: Ethercat Introduction
Every EtherCAT datagram ends with a 16 Bit Working Counter (WKC). The Working Counter counts the number of devices that were successfully addressed by this Eth- erCAT datagram. PCIE-1203 User Manual... - Page 9 If one of the slaves in the network is removed, the rest of the network can con- tinue to operate normally. Additionally, EtherCAT also enables other communication features such as cable redundancy or even master redundancy with Hot Standby. PCIE-1203 User Manual...
- Page 10 EtherCAT network to make the first slave the refer- ence clock and forcing all other slaves to set their internal clock by the calculated off- set. ∆t = (t ) - t Local Time Offset Propagation Delay Received System Time PCIE-1203 User Manual...
- Page 11 In addition to the error detection and localization protocol, transmission physics and topology of the EtherCAT system allow an individual quality monitoring of every sin- gle transmission path. There is a very effective monitoring mechanism in EtherCAT. PCIE-1203 User Manual...
-
Page 12: Features
PCIE-1203L (Basic function, PCIE interface) PCIE-1203IO (IO function only, PCIE interface) Process of data exchange and memory location in EtherCAT communication can be executed automatically by PCIE-1203 series. User can benefit from EtherCAT high performance communication feature without handling complicated EtherCAT commu- nication protocol. -
Page 13: On-Board Real-Time Os Support
Runtime monitoring and correction of deviation 1.2.6 Supports Common Motion SDK Support “Common Motion API” to integrate all Advantech SoftMotion controller EtherCAT slaves are completely configurable via the API without ENI data Graphical utility interface is easy to use and configure EtherCAT system ... -
Page 14: Digital Input
175 x 100 mm (6.9" x 3.9") @ 0.5 A typical Power Consumption Humidity 5 ~ 95% RH, non-condensing (IEC 60068-2-3) Operating Temp. 0 ~ 60°C (32 ~ 140°F) Storage Temp. -20 ~ 85°C (-4 ~ 185°F) PCIE-1203 User Manual... -
Page 15: Chapter 2 Installation
Chapter Installation... -
Page 16: Unpacking
Driver Installation We recommend you install the driver before you install the PCIE-1203 series card into your system. The DLL driver setup program for the card is included on the companion CD-ROM that is shipped with package. -
Page 17: Hardware Installation
Save the screws to secure the retaining bracket of interface card. Carefully grasp the upper edge of the PCIE-1203 series. Align the hole in the retaining bracket with the hole on the expansion slot and align the gold striped edge connector with the expansion slot socket. - Page 18 PCIE-1203 User Manual...
-
Page 19: Chapter 3 Hardware
Chapter Hardware... -
Page 20: Outline
Outline Table 3.1 shows location of the connectors and switches of the PCIE-1203. Table 3.1: Point to point Part Reference Function Isolated digital input/output connector LAN1 RJ45 with Transformer (Motion) LAN2 RJ45 with Transformer (IO) Gold finger PCI Express x 1... -
Page 21: Lan Port (Lan1, Lan2)
Encoder In 1 Phase A - EC1B+ Encoder In 1 Phase B + EC1B- Encoder In 1 Phase B - General Digital Output 0 General Digital Output 0 CMP0 Position Compare Output 0 CMP1 Position Compare Output 1 PCIE-1203 User Manual... -
Page 22: Wiring
3.4.1 Wiring PCIE-1203 User Manual... - Page 23 3.4.1.1 Digital Input Note: All the above DI are common with +VEX pin 3.4.1.2 Digital Output PCIE-1203 User Manual...
- Page 24 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022...
