Advantech PCIE-1730H Startup Manual

PCIE-1730H 32-ch Isolated Digital I/O with
Digital Filter PCI Express Card
Startup Manual
Packing List
Before installation, please make sure that you have re-
ceived the following:
• PCIE-1730H card
• Driver CD
• Quick Start User Manual
If anything is missing or damaged, contact your distributor
or sales representative immediately.
User Manual
For more detailed information on this product, please refer to
the PCIE-1730H User Manual on the CD-ROM (PDF format)
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in ac-
cordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause interfer-
ence in which case the user is required to correct interfer-
ence at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact
your local supplier for ordering information.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/products/ProView/
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCIE-1730H.
Part No. 2001173000
Print in China
Overview
The Advantech PCIE-1730H is a 32-channel, isolated digi-
tal input/output card for the PCI Express bus. The isolated
digital input/output channels feature high isolation protec-
tion which can save your system investment. In addition,
this card also offers 32-channel 5V/TTL compatible digital
input/output channels. The PCI Express interface makes
this card workable with latest computing platform.
Specifications
Isolated Digital Input
• Input Channels: 16
• Input Voltage:
- Logic 0: 3 V max. (0 VDC min.)
- Logic 1: 10 V min. (30 VDC max.)
• Input Current:
- 12 VDC @ 3.18 mA
- 24 VDC @ 6.71 mA
• Interrupt Capable Channel: 16
• Digital Filter Channel: 16
• Isolation Protection: 2,500 VDC
• Overvoltage Protection: 70 VDC
• ESD Protection: 2,000 VDC
• Opto-Isolator Response: 50 μs
Isolated Digital Output
• Output Channels: 16
• Output Type: Sink (NPN)
• Isolation Protection: 2,500 VDC
• Output Voltage: 5 ~ 40 VDC
• Sink Current: 500 mA/channel (max.)
• Opto-isolator Response: 50 μs
Non-isolated Digital Input/Output
• Input Channels: 16 (support digital filter and interrupt
function)
• Input Voltage:
- Logic 0: 0.8 V max.
- Logic 1: 2 V min.
• Output Channels: 16
• Output Voltage:
- Logic 0: 0.5 V max. @ 24 mA (sink)
- Logic 1: 2.4 V min. @ -15 mA (source)
• Digital Filter for DI/ IDI:
Digital Filter Time[sec.] = 2n / (8 x 106) n: = setting
data(0 - 20)
1st Edition
April 2017
PCIE-1730H Startup Manual 1
