  • Page 1 User Manual PCIE-1730H 32-ch Isolated Digital I/O with Digital filter PCI Express Card...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 4: Safety Instructions

    If one of the following situations arises, get the equipment checked by service personnel: The power cord or plug is damaged. Liquid has penetrated into the equipment. The equipment has been exposed to moisture. PCIE-1730H User Manual...
  • Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). Safety Precaution - Static Electricity DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.
  • Page 6 PCIE-1730H User Manual...

  • Page 7: Table Of Contents

    Specifications ..................16 A.1.1 Isolated Digital Input ..............16 A.1.2 Isolated Digital Output..............16 A.1.3 Non-isolated Digital Input/Output ..........16 A.1.4 General ..................17 A.1.5 Digital Filter Time ................ 17 Appendix B Block Diagram ........19 PCIE-1730H .................... 20 PCIE-1730H User Manual...
  • Page 8 PCIE-1730H User Manual viii...

  • Page 9: Chapter 1 Overview

    Chapter Overview...

  • Page 10: Introduction

    , the PCIE-1730H can still manage to work properly, albeit only for a short period of time. Wide Input Range The PCIE-1730H has a wide range of input voltage from 10 to 30 V , and is suitable for most industrial applications with 12 V or 24 V input voltage.

  • Page 11: Applications

    Board ID The PCIE-1730H has a built-in DIP Switch that helps define each card’s ID when multiple PCIE-1730H cards have been installed on the same PC chassis. The board ID setting function is very useful when users build their system with multiple PCIE- 1730H cards.

  • Page 12: Software Overview

    Software Overview Advantech offers device drivers, SDKs, third-party driver support and application software to help fully exploit the functions of your PCIE-1730H card. All these soft- ware packages are available on the companion CD-ROM or you can browse Advan- tech website to get the latest update: http://www.advantech.com/.

  • Page 13: Chapter 2 Hardware Installation

    Chapter Hardware Installation...

  • Page 14: Installation

    This chapter gives users a package item checklist, proper instructions about unpack- ing and step-by-step procedures for both driver and card installation. Unpacking After receiving your PCIE-1730H package, please inspect its contents first. The pack- age should contain the following items: ...

  • Page 15: Driver Installation

    Touch the metal part on the surface of your computer to neutralize the static electricity that might be on your body. Insert the PCIE-1730H card into a PCI Express slot. Hold the card only by its edges and carefully align it with the slot. Insert the card firmly into place. Use of excessive force must be avoided, otherwise the card might be damaged.

  • Page 16: Figure 2.1 Device Manager

    After the PCIE-1730H card is installed, you can verify whether it is properly installed on your system through the Device Manager: Access the Device Manager through Control Panel/System/Device Manager. The device name of the PCIE-1730H should be listed on the Device Manager tab as follows.

  • Page 17: Chapter 3 Signal Connections

    Chapter Signal Connections...

  • Page 18: Overview

    PC and other hardware devices. This chapter provides useful information about how to connect input and output signals to the PCIE-1730H via the I/O connector. Switch and Jumper Settings Figure 3.1 Card Connector, Jumper and Switches Table 3.1: Summary of Jumper Settings...

  • Page 19: Signal Connections

    Signal Connections PCIE-1730H Pin Assignments IDO 0 1 IDO 1 IDI 0 IDI 1 IDO 2 3 IDO 3 IDI 2 IDI 3 IDO 4 5 IDO 5 IDI 4 IDI 5 IDO 6 7 IDO 7 IDI 6 IDI 7...

  • Page 20: Figure 3.2 Ttl-Level Di/O Connection

    TTL-level Digital Input/Output The PCIE-1730H has 16 TTL-level digital inputs and 16 TTL-level digital outputs. The following figure shows connections to exchange digital signals with other TTL devices: Figure 3.2 TTL-level DI/O Connection If you want to receive an OPEN/SHORT signal from a switch or relay.

  • Page 21: Figure 3.4 Isolated Di Connection

    The following figure shows how to connect an external output load to the card's isolated outputs. Internal External Diode PCOM Common IDO0 IDO1 Isolated IDO2 Relay Circuit IDO3 IDO4 IDO5 IDO6 5~40V IDO7 EGND Figure 3.5 Isolated Digital Output Connection PCIE-1730H User Manual...
  • Page 22 PCIE-1730H User Manual...

  • Page 23: Appendix A Specifications

    Appendix Specifications...

  • Page 24: Specifications

    Non-isolated Digital Input/Output 16 (Interrupt function and Digital filter support) Input Channels 0.8 V max. Input Voltage High 2.0 V min. Output Channels 0.5 V max. @ +24 mA (sink) Output Voltage High 2.4 V min. @ -15mA (source) PCIE-1730H User Manual...

  • Page 25: General

    8.192msec 3 (03h) 1μsec 10 (0Ah) 128μsec 17 (11h) 16.384msec 4 (04h) 2μsec 11 (0Bh) 256μsec 18 (12h) 32.768msec 5 (05h) 4μsec 12 (0Ch) 512μsec 19 (13h) 65.536msec 6 (06h) 8μsec 13 (0Dh) 1.024msec 20 (14h) 131.072msec PCIE-1730H User Manual...
  • Page 26 PCIE-1730H User Manual...

  • Page 27: Appendix B Block Diagram

    Appendix Block Diagram...

  • Page 28: Pcie-1730H

    PCIE-1730H PCIE-1730H User Manual...
  • Page 29 PCIE-1730H User Manual...
  • Page 30 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
