Hitachi NEXT Series Instruction Manual page 121

Air Pipe
9
Air-Cooled
125 psi (0.86 MPa) type
670
060
059
865
025
033
D72
026
037
033
F02
033
004
021
006
B35
B78
C07
874
061
058
100 psi (0.69 MPa) type
029
059
060
028
039
034
D71
027
033
※B99
865
F03
875
057
040
041
865
035
024
022
033
023
E29
D70
11. PARTS LIST
Ref.
Description
No.
004 O-Ring, condensate water separator seat
006 Cover, Condensate Separator
021 Demister
022 Air Piping (1)
023 Air Piping (2)
024 Air Piping (3)
025 Air Piping (4)
026 Air Piping (5)
027 Air Piping (6)
028 Air Piping (7)
029 Air Piping (8)
033 Gasket(1)
034 Gasket, 1st-stage air end discharge flange
035 Gasket, cooler
F01
037 Gasket, 2nd-stage suction
033
039 Gasket, 2nd-stage air end discharge flange
040 Piping, Aftercooler Condensate Water
041 Air Relief Valve seat
056 Air Piping (9)
057 Air Piping (10)
058 Support, discharge piping
E30
059 Piping Support (1)
060 Piping Support (2)
865
061 Piping Support (3)
056
670 Hi-Precooler
865 Gasket (2)
869
868 Lower Cover, check valve
869 Upper Cover, check valve
870
870 Gasket
871 Check Valve
871
874 Discharge Piping
875 Air Relief Valve
870
B35 Fix Board, separator
868
B78 Vibration Isolation Rubber
C07 Motorized Isolation Valve
D70 Thermistor (TH4)
D71 Thermistor (TH2)
D72 Thermistor (TH3)
E29 Cover,piping (1)
E30 Cover,piping (2)
F01 Air Piping (11)
F02 Condensate Separator
F03 Air Piping (12)
※Does not come with the product.
