Hitachi NEXT Series Instruction Manual

Oil-free rotary screw air compressor
Hide thumbs Also See for NEXT Series:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
INSTRUCTION MANUAL
HITACHI Oil-Free Rotary Screw Air Compressor
Water-Cooled
DSP-132W6N
DSP-145W6N
DSP-160W6N
DSP-200W6N
DSP-240W6N
Water-Cooled
DSP-160V6WN
DSP-240V6WN
Prior to operation of this air compressor,
ensure that all operators read and
understand this INSTRUCTION MANUAL
completely, thereby operating it safely
and properly.
Place the INSTRUCTION MANUAL near
the air compressor to make it available
at any time, and refer to it as the need
arises.
Fixed Speed
Variable Speed Drive Control
NEXT
●   T his INSTRUCTION MANUAL explains in detail
the important items that require attention;
observed as the following:
●   A lways observe notations of WARNING, CAUTION
and IMPORTANT, as they indicate considerable
risks to safety.
GRAPHIC DESCRIPTIONS:
：  T his is a warning. If handled improp-
WARNING
erly, death or severe injury could
result.
：  T his is a caution. If handled improp-
CAUTION
erly, injury and/or physical damage
could result.
：  T his graphic is Variable Speed-control
Drive (VSD) models.
：  T his graphic is for items that need
IMPORTANT
attention, other than WARNING and
CAUTION.
：  T his graphic is a page number reference.
series
TWO STAGE
