IQT-F116-R4*-V1

Operation

5 Operation
5.1

General Information about Tag Types

Read/write tag 13.56 MHz (inductive)
Read/write tags in this frequency range offer a considerably higher reading speed
than read/write tags for the 125 kHz and 250 kHz system. Since this is a
nonproprietary system, cost- effective tags are available from many third-party
manufacturers.
By issuing a command, you can notify the device of the specific read/write tag
with which it is to communicate.
The following read/write tags are currently supported:
Tag types 13.56 MHz
Data
carrier
type
20
21
22
23
24
Table 5.1
The read/write tags all feature a read/write range in which data can be written and
modified, as well as a protected memory in which the read-only code is saved.
This read-only code is issued by the manufacturer only once and can be read
using a command, but not altered.
Chip type Details
ISO 15693 All data carriers that
conform with ISO
I code SLI Philips
Tag-it HF-I 'Plus' by Texas
Instruments
SRF55V02P my-D by Infinion
SRF55V10P my-D by Infinion
Tag types 13.56 MHz
1)
The purpose of this data carrier type is to read the UID (fix code) of all data
carriers supported by Pepperl+Fuchs that conform with ISO 15693.
Desig-
nation
P+F Access Bits
R/W -
1)
Fixcode 64
IQC21 R/W 896
Fixcode 64
IQC22 R/W 2k
Fixcode 64
IQC23 R/W 2k
Fixcode 64
IQC24 R/W 10k
Fixcode 64
Block
addresses
[HEX]
-
-
0...1B
-
0...3F
-
0...38
-
0...F7
-
9
