IQT-F116-R4*-V1

Installation

4 Installation
4.1

Storage and transport

For storage and transport purposes, package the unit using shockproof
packaging material and protect it against moisture. The best method of protection
is to package the unit using the original packaging. Furthermore, ensure that the
ambient conditions are within allowable range.
4.2

Unpacking

Check the product for damage while unpacking. In the event of damage to the
product, inform the post office or parcel service and notify the supplier.
Retain the original packaging in case you have to store or ship the device again at
a later date.
Should you have any questions, please contact Pepperl+Fuchs.
4.3

Assembly and connection of the read /write station

Note!
Do not install that the read/write station directly onto metallic surfaces. Keep a
minimum distance of 50 mm around the equipment to metal.
If you wish to install several devices next to each other, keep a minimum
distance of 210 mm in order to avoid interference.
Install the equipment on an even surface.
Installation and connection
1. Fasten the equipment with two screws through the assembly holes in the
housing.
2. Connect the device to a computer, with a RS 485 interface.
8
