IQT-F116-R4*-V1
Operation
version VE
This command transfers the software version.
Command:
Response:
change tag CT
This command sets the transponder type the reader communicates with. The
delivery status is type "21".
Command:
Response:
The following transponder types are currently supported:
Tag types 13.56 MHz
Data
carrier
type
20
21
22
23
24
Table 5.3
With the <TagType> "20" a mixed operation with different transponder types is
possible. Since the read/write station requires a significantly longer time for the
Autodetect, only static read and write is useful in this mode. In the "Autodetect"-
mode, the parameters word start address and number of words are only checked,
if a tag is read or writen, because the memory areas of different transponder types
are different. Therefore the error message "status 4" can only occur, when a
transponder is in front of the read/write station.
12
VE <DeviceNo> <CHCK> <ETX>
<Status> <DeviceNo> (c) P+F IDENT-I
<Type code>
<Part no.>
<SW no.>
<Date> <CHCK> <ETX>
CT <DeviceNo> <TagType> <CHCK> <ETX>
<Status> <DeviceNo> <CHCK> <ETX>
Chip type Details
ISO 15693 All data carriers that
conform with ISO
I code SLI Philips
Tag-it HF-I 'Plus' by Texas
Instruments
SRF55V02P my-D by Infinion
SRF55V10P my-D by Infinion
Tag types 13.56 MHz
1)
The purpose of this data carrier type is to read the UID (fix code) of all data
carriers supported by Pepperl+Fuchs that conform with ISO 15693.
Desig-
nation
P+F Access Bits
R/W -
1)
Fixcode 64
IQC21 R/W 896
Fixcode 64
IQC22 R/W 2k
Fixcode 64
IQC23 R/W 2k
Fixcode 64
IQC24 R/W 10k
Fixcode 64
Block
addresses
[HEX]
-
-
0...1B
-
0...3F
-
0...38
-
0...F7
-
