IQT-F116-R4*-V1
Operation
Standard read/write commands
Read data
Command description
single read words
enhanced buffered read
words
Write data
Command description
single write words
enhanced buffered write
words
Fixcode
Command description
single read fixcode
enhanced buffered read
fixcode
5.3

System commands

Note!
Command structure
Since the IQT-F116-R4M-V1 features a device adress (= <DeviceNo>), you must
specify the device address within the commands.
For the IQT-F116-R4-V1 the device address is not applicable.
Examples
Command structure IQT-F116-R4-V1:
Command: <CommandCode><CommandParameters><CHCK><ETX>
Response: <Status><Data><CHCK><ETX>
Command structure IQT-F116-R4M-V1:
Command:
<CommandCode> <DeviceNo><CommandParameters><CHCK><ETX>
Response: <Status><DeviceNo><Data><CHCK><ETX>
Optionally you can replace <CHK><ETX> with #<CR>.
Abbreviation Page
SR See "single read words SR" on page 14
ER See "enhanced buffered read words ER" on
page 14
Abbreviation Page
SW See "single write words SW" on page 14
EW See "enhanced buffered write words EW"
on page 15
Abbreviation Page
SF See "single read fixcode SF" on page 15
EF See "enhanced buffered read fixcode EF"
on page 15
