Cleco 55NJLT Operation & Service Manual page 8

"M" RIGHT ANGLE HEAD
882629
FLUSH SOCKET SPINDLE
SIZE SPINDLE CONVERSION
PART NO. KIT* PART NO.
10mm 202566 201102
11mm 202725 201214
13mm 202567 201103
14mm ------------
15mm 202568 201104
*Conversion kit contains all parts
needed to convert a "M" right angle
head to flush socket operation.
*Denotes parts not included in subassemblies
listed below. The "M" right angle gears can be
purchased as a set using Part No. 861481. The
"M" right angle head can be purchased as a
subassembly using Part Numbers:
3/8" Sq. Dr. Spindle—Part No. 861495
8
382633
867506
843589
864076 867643
------------
NAME OF PART
PART NO.
Spline Protector
382633
Ball Bearing
842517
Grease Fitting
843589
Lock Pin Spring
847219
"O"-Ring 1/2" x 5/8"
847710
Pinion Bearing (upper)
863360
Driven Gear
864076
Bearing Cap
864396
Housing (incl. 843589)
867506
Pinion Gear
867519
Housing Make-Up Plate
867520*
Housing Lock Nut
867521*
Housing Clamp Ring
867522*
Lock Pin Spring Cap
867641
Socket Lock Pin
867642
3/8" Sq. Dr. Spindle (incl.
867643
847219, 867641, 867642)
Spindle Needle Bearing
882629
842517 867520
867519
847219
867642
867641
842517
202569
842980
867521
863360
864396
847710
869051
3/8 - 24 Thd.
DRILL SPINDLE
QTY.
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
867522
