Cleco 55NJLT Operation & Service Manual page 17

"V" RIGHT ANGLE
HOLD & DRIVE HEAD
867924
867546
204350
622772
204355
PART NO.
204343 ANGLE HEAD
204344 DRIVE SPINDLE
204345 BEARING CAP
204346 HOLD SPINDLE
204347 CLAMP RING†
204348 CLAMP NUT†
204349 SPRING
204350 NEEDLE BEARING
204355 DRIVEN GEAR
204356 PINION
617290 "O"-RING
622772 RETAINING RING
842160 BALL
847659 BALL BEARING
864710 LOCK PIN RETAINER*
864711 SOCKET LOCK PIN*
864712 LOCK PIN SPRING*
867546 PIPE PLUG
867924 RETAINER RING
867997 SET SCREW
869880 ROLLER BEARING
204347
847659 204348
204343
842160 617290
204345
DESCRIPTION
204356
867997
204344
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
† PARTS NOT INCLUDED IN SUBASSEMBLY
22
1
1
*INCLUDED ON 204346
1
1
COMPLETE ANGLE HEAD SUBASSEMBLY: 201698
1
1
110 FT. LBS.(150Nm) MAXIMUM
1
RECOMMENDED TORQUE
1
869880
864711
864712
864710
204349
204346
17
