Cleco 55NJLT Operation & Service Manual page 11

"T" HEAD — RETRACTABLE SPINDLE
PART NO.
202537
202538
202539
202540
844011
844013
844014
COMPLETE "T" HEAD WITH RETRACTABLE SPINDLE CAN BE ORDERED
USING PART NUMBER — 201134
COMPLETE RETRACTABLE SPINDLE CAN BE ORDERED USING PART NUMBER — 201674
REACTION BAR BRACKET ASSEMBLY
PARTS LIST
REACTION BAR BRACKET ASSEMBLY
PART NO. NAME OF PART
202319 Reaction Bracket
202320 Reaction Bar Clamp
842554 5/16- 18 x 1- 3/4" Bracket Bolt
The complete reaction bar bracket can be purchased as
Subassembly using Part No. 201012.
The reaction bracket, No. 202319,
CAUTION
!
must fully engage the spline on the
right angle head. Position the bracket forward on the small
diameter of the head and move it rearward to engage the
spline. Securely tighten the reaction bar and bolts to
prevent coming loose from vibration.
PARTS LIST — RETRACTABLE SPINDLE
NAME OF PART
1/2" SQUARE DRIVE EXTENSION SPINDLE
(INCLUDES 844011, 844013, 844014, & PIN)
RETRACTABLE SPINDLE
RETAINER CLIP
SPRING
SOCKET RETAINER
SOCKET SPRING RETAINER
SOCKET RETAINER SPRING
202319
1-1/4"
QTY.
1
1
2
C L
1-5/16"
3/4" NPT
C L
QTY.
1
1
1
1
1
1
1
3/8" DIA.
202320
842554 (QTY. 2)
11
