State

Status

Rev

Message
Online
The module is enabled and is responding to the
system controller's status polls.
No Response The module is enabled but is not responding to the
system controller's status polls.
Empty
The system controller has not detected the
presence of a module in the option slot, nor has a
module been manually enabled for this option slot.
Offline
The module is installed but has been taken Offline
by a user.
Offline / The module is installed but has been taken Offline
No Response
by a user. The module is not responding to polls.
Not Ready The module is installed and performing startup
initialization.
61200262L1-1A
Read security: 5
Displays whether the module is online or offline. Even though a module is
physically installed, it must be marked Online for it to be considered an
available resource. Marking an installed module Offline may be useful in
system troubleshooting. If you choose Offline, the module will not be in
alarm condition, but will display Offline.
Only if State reads Online, can the ATLAS use an installed
module for any data bandwidth.
Read security: 5
Displays status information on the IMUX-56/64 Module. Table 3-3
describes status messages that may appear and their meanings.
Read security: 5
(Hardware Revision) Displays the hardware revision of the IMUX-56/64
Module.
Meaning
IMUX-56/64 Module User Manual
Chapter 3. Operation

Table 3-3. Status Messages

Comments
This is the normal response of
the system.
This response indicates either a
problem in the system or the
module is not installed.
The module is still responding to
controller polls.
This response indicates either a
problem in the system or the
module is not installed.
The initialization of the IMUX-
56/64 should take less than 10
seconds.
3-5
