Chapter 3

OVERVIEW

TERMINAL MENU STRUCTURE

61200262L1-1A
Operation
You can configure and control the IMUX-56/64 Module from several sourc-
es, as shown in Table 3-1. The ATLAS User Manual provides detailed in-
structions on operating each of the supported management approaches. The
remainder of this chapter describes the menu items available for managing
the IMUX-56/64 Module using the terminal menu.

Table 3-1. Management Methods for the IMUX-56/64 Module

Source
ATLAS Front Panel
Terminal Menu
Simple Network
Management Protocol
(SNMP)
You must have the appropriate password level to edit items using
the terminal menu. (See the section Access Passwords in the
ATLAS User Manual for detailed information on working with
passwords.)
Security level 1 users can view and edit every available field.
Security level 5 users can view any field, but they cannot edit.
Each menu description in this section indicates the required
password level required for write and read access.
ATLAS uses hierarchical menus to access all of its features. The top-most
menu level leads to submenus which are grouped by functionality. All sub-
menu options display in the VT-100 terminal window.
You can use the
Modules
IMUX-56/64 Module. The
64 Module as IMUX (see Figure 3-2). The following sections describe the
menu and its submenus.
ules
IMUX-56/64 Module User Manual
Purpose
For minimal configuration and status support
For detailed configuration, status, and
diagnostics
For reporting alarm conditions and system
status (no configuration)
terminal menu to configure and control the
menu option,
Modules
, shows the IMUX-56/
Type
Mod-
3-1
