MODULES

Slt

Type

Menu

Alarm

3-4
The following paragraphs (Slt (slot), Type, Menu, Alarm, State, Status, and
Rev (revision)) describe the IMUX-56/64
Read security: 5
(Slot) Displays the number of available slots in the ATLAS chassis. Slot 0
refers to the ATLAS Base Unit.
Write security: 3; Read security: 5
Displays the module type currently installed in the slot or the module type
you plan to install in the slot. If an IMUX-56/64 Module is installed, the
Type field automatically defaults to IMUX (the IMUX-56/64 Module). You
can use this field to preconfigure the system before installing modules by
specifying the module that you want to install into each slot.
If a module is installed,
the installed module, and it cannot be set to any other option.
Read security: 5
Displays additional status and configuration submenus for the
IMUX-56/64 Module. (To access the submenus for this item, use the arrow
keys to scroll to the
Menu
press .)
Enter
Read security: 5
Displays whether there is an alarm condition on the IMUX-56/64 Module.
Press in this field to activate the
Enter
IMUX-56/64 Module User Manual
Modules

Figure 3-2. Modules Menu

Type automatically displays the name of
column for the module you want to edit, and
menu.
Alarm
fields (see Figure 3-2).
