Chapter 3. Operation

MENU ACCESS

SYSTEM
CONFIG

BONDING Config

TXINIT Timer

TXFA Timer

3-2
The ATLAS System Controller automatically detects the presence of the
IMUX-56/64 Module when it is installed in the system. To access menus and
submenus, use the keyboard arrow keys to scroll to the appropriate row and
column; then press
Enter
For example, to view the
keys to move to the row IMUX and the column Menu; then press
the keyboard.
Refer to the ATLAS User Manual for detailed instructions on
how to navigate through the terminal menu.
The IMUX-56/64 Module includes a
menu. The following paragraphs describe this submenu.

System Config

Write security: 5; Read security: 5
Displays the configuration submenus available for the IMUX-56/64 Mod-
ules. This configuration is shared among all IMUX-56/64 Modules (see Fig-
ure 3-1).
Write security: 3; Read security: 5
Specifies the length of time the originating endpoint attempts to detect the
BONDING negotiation pattern from the answering endpoint before decid-
ing the BONDING call has failed.
Write security: 3; Read security: 5
Specifies the length of time both endpoints attempt to detect the BONDING
frame pattern when a call is connected before deciding the BONDING call
has failed. When interoperating with other manufacturers' BONDING
IMUX-56/64 Module User Manual
on the keyboard.
submenu for IMUX, use the keyboard arrow
Menus
BONDING Config

Figure 3-1. BONDING Config Submenu

on
Enter
submenu under the
61200262L1-1A
