Page 3 Welcome to the world of MG!!! Thank you for choosing MG Hector – India's first Internet Car This manual will familiarize you with the operation and maintenance of your new vehicle. It will also provide you important safety information. Please do read it carefully and follow the recommendations. This manual is like a permanent part of your car. It would go a long way in ensuring a safe and trouble-free operation and running of your MG Hector.
Page 5: Table Of Contents
CONTENTS Contents PREFACE............8 Electric Liftgate ..........17 Windows ..........25 Ÿ KEYS, DOORS AND WINDOWS..9-32 Ÿ External Liftgate Switch .......18 Ÿ Power Window ..........25 Keys ............10 Ÿ Internal Liftgate Switch ........18 Ÿ Power Window Switch........26 Key-in Reminder*..........11 Liftgate Closing Switch.........18 Power Window Lock Button .....27 Ÿ...
Page 6 CONTENTS Ÿ Manual Adjustment Type*......36 Ÿ ISOFIX .............45 Roof Rail ..........60 Ÿ Load Information...........60 Ÿ Electric Adjustment Type*......36 Table of Vehicle Handbook Information on Child Restraint Systems ....47 INSTRUMENTS AND Ÿ Ventilation Seat Control Button....36 CONTROLS ........61-102 Air Bag System ........48 Driver’s Seat Height Adjustment..37 Instrument Panel ........62 Air Bag Indicator .........
Page 7 CONTENTS Type-II Trip Computer Display Ÿ Front Passenger Fasten-Seat-Belt Parking Assist System* ......101 Screen ............71 Warning Lamp*..........91 Ÿ 360 Degree Panoramic Parking Type-I Trip Computer Display Ÿ Fuel Level Too Low Warning Lamp ..91 Screen Assist* ..........102 Screen Switch ........77 Ÿ...
Page 8 CONTENTS AUDIO ENTERTAINMENT Ventilation..........126 Automatic Upshift........141 Ÿ Ÿ SYSTEM...........111-114 Ÿ Rapid Defrosting and Defogging ..126 Ÿ Kick-down..........141 Audio Control Buttons on DRIVING AND CONTROLS ..127-156 Hill-start Hold Control......141 Ÿ Steering Wheel*........112 Driving Instructions ......128 Ÿ Run Downhill ..........142 Driver Information and Vehicle Control ........128 Protection Mode ........142 Ÿ...
Page 9 Windshield Washer Solvent ....165 Maintenance Interval ....232-234 Vehicle Traction........186 Maintenance Record Sheet ..235-236 Diesel Exhaust Fluid (DEF) ....166 Ÿ Emergency Trailer........187 MG Motor India Sales and Windshield Wiper.......172 Front Towing Hook ......187 Ÿ Service Network......237-241 Air Filter ..........173 Ÿ...
Page 10: Preface
Please to resell the vehicle, please handover the refer to the actual vehicle for vehicle configuration. Manual to the new owner along with the MG Motor India Pvt. Ltd. reserves the copyright of the vehicle for use when needed. Manual.
Page 11: Keys, Doors And Windows
KEYS, DOORS AND WINDOWS Keys, Doors and Windows Keys ............10 Doors............17 Electrically Folding Ÿ Outside Rearview Mirror*......24 Ÿ Liftgate .............17 Ÿ Key-in Reminder*..........11 Ÿ Automatically Folding Electric Liftgate ..........17 Ÿ Ÿ Remote Control..........11 Outside Rearview Mirror*......24 Ÿ External Liftgate Switch .......18 Vehicle Locating..........11 Ÿ...
Page 12: Keys
As shown in the figure above, turn the release Note switch on the key first, and then pull out the mechanical key . If the key is lost, please contact to MG Authorised Service Center. Plug back the mechanical key after use.
Page 13: Key-In Reminder
KEYS, DOORS AND WINDOWS Foldable Type Remote Control : Liftgate Unlock Button. Press and hold for about 2s; open the liftgate, and the hazard warning lamp will flash once. Note The functioning range of the remote c o n t r o l m a y b e d i f f e r e n t d u e t o e n v i r o n m e n t a l r e a s o n s .
Page 14: Ÿ Activation Of Door Lock And Anti-Theft Mode
, i t i s lamp will flash twice, and the immobilizer protection recommended to have the system is activated. checked by the MG Authorised Service 3. The ignition switch is not at the LOCK As for a vehicle configured with ENGINE Center. position...
Page 15: Automatic Locking Of Door
After the battery When the doors are locked, they will be transmission autostop function which can runs out, please go to the MG Authorised unlocked automatically if the ignition switch is prevent unnecessary battery loss caused by Service Center to have the battery changed.
Page 16: Door Lock
KEYS, DOORS AND WINDOWS Door Lock External Door Locking and Unlocking As shown in the figure, for type I I I, when the As shown in the figure above, the lockhole on To lock a door outside of the vehicle with a door is locked or unlocked with a key from the left front door external handle is hidden key, plug the key and rotate it clockwise.
Page 17: Internal Door Locking And Unlocking
KEYS, DOORS AND WINDOWS Internal Door Locking and Unlocking External / Internal Door Opening To open doors from inside or outside, unlock the doors first, and pull the external or internal door handles. When the doors are locked, pulling the internal door handle twice can open the doors.
Page 18: Child Safety Lock
KEYS, DOORS AND WINDOWS Child Safety Lock To activate the child safety lock: As shown in the figure above, open the right front door and two rear doors, and find the internal knobs of locks (not the knob of child safety lock).
Page 19: Door Lock Thermal Protection
KEYS, DOORS AND WINDOWS Doors Liftgate Walk Away Lock / Approach Unlock* External Liftgate Switch Liftgate Opening with Remote Key Press the remote key liftgate opening key for Walk Away Lock about 3s to unlock the liftgate when the engine is shut down.
Page 20: Internal Liftgate Switch
KEYS, DOORS AND WINDOWS External Liftgate Switch Internal Liftgate Switch Liftgate Closing Switch In the liftgate open state, press the liftgate closing switch, as shown in the figure. The liftgate automatically closes after two prompt Firstly, unlock the vehicle, and press the Press the switch.
Page 21: Kick Type Electric Tailgate
KEYS, DOORS AND WINDOWS Kick Type Electric Tailgate* 2. During liftgate closing, when any obstacle (such as personnel) with stronger resistance is in the resistance anti-pinch zone, as shown in Figure ②, the liftgate enters the anti-pinch mode. The liftgate opens reversely to the preset stopping point.
Page 22: Inductive Tailgate
KEYS, DOORS AND WINDOWS Inductive Tailgate* Warning The inductive Tailgate can be opened without Detect and Alert touching the vehicle. The Tailgate operates if the smart key is Do not approach the detecting area if you detected within 50 ~ 100 cm from the tailgate. do not want the tailgate to open.
Page 23: Liftgate Service Hole
KEYS, DOORS AND WINDOWS Liftgate Service Hole Passive Entry Caution If the operation is correct, but the liftgate cannot be opened and closed normally with qualified conditions to open and c l o s e t h e e l e c t r i c l i f t g a t e , i t i s recommended to drive to the nearest Aftersales Service Center for repair.
Page 24: Passive Locking
KEYS, DOORS AND WINDOWS Passive Unlocking / Locking of Liftgate Passive Unlocking Passive Locking Passive Locking When all doors are closed and the ignition If the doors are locked, when the liftgate is switch is at LOCK position, bring a legal key closed, the system will search automatically and get close to the front door handle (within whether there is a legal key in the vehicle.
Page 25: Engine Hood
KEYS, DOORS AND WINDOWS Engine Hood Opening Engine Hood 2. After the engine hood is opened slightly, Make sure that your or other persons’ stretch out the hand to the lower side of hands or other body parts are away from the engine hood front edge.
Page 26: Outside Rearview Mirror
KEYS, DOORS AND WINDOWS Outside Rearview Mirror Please check the visual field of all rearview mirrors before driving. After adjustment, recover the selector If the electric folding button is pressed, the switch to non-pressed state (both ends Adjusting Outside Rearview Mirror outside rearview mirror will not be unfolded not pressed).
Page 27: Defrosting Of Outside Rearview Mirror
KEYS, DOORS AND WINDOWS Windows Inside Rearview Mirror Power Window rearview mirror will be unfolded smoothly. If When the ignition switch is at ON position, you the freeze is not removed, the freeze will can control the power window with the power hinder the movement of the rearview mirror, window switch on the door armrest panel.
Page 28: Power Window Switch
If an occupant stretch his / her body out of Anti-pinch Function of Driver’s Side recommended to drive to the MG Authorised the vehicle, he/she may be hit by objects Power Window* Service Center for check and repair.
Page 29: Power Window Lock Button
KEYS, DOORS AND WINDOWS Power Window Lock Button Sunshade Auxiliary Handrail The power window lock button can lock the Your vehicle is configured with sunshade Above the front passenger’s side door and front passenger’s side and rear power window which can reduce dazzling effect on the driver rear doors, an auxiliary handrail is installed.
Page 30: Sunroof
KEYS, DOORS AND WINDOWS Sunroof* Power Sunroof* Sunroof Sliding When the ignition switch is at ON position, stops moving, or push the front end of the the power sunroof can be operated. switch once quickly and then release (operate within 0.3s). Caution Sunroof Tilting Always observe the following notes:...
Page 31: Sunvisor
(operate within 0.3s). opening of closing function is still unavailable after initialization learning, it is recommended One-button Opening or Closing of to drive to the MG Authorised Service Center Sunroof for check and repair. While operating the sunroof switch, you can...
Page 32: Sun Blind
KEYS, DOORS AND WINDOWS Sun Blind Sunroof Tilting switch when the sunroof stops moving. You can also push the sunroof switch (short press) forward once quickly, and the sunroof will be closed automatically Sunroof Sliding Press the open or close button of the sun blind The front part of the sunroof can be tilted.
Page 33 If the button is released in long pressing or closing, push the switch once. please drive to the MG Authorised Service process, the glass will stop moving, and the sun Center for check and repair.
Page 35: Seats And Protective Devices
SEATS AND PROTECTIVE DEVICES Seats and Protective Devices Headrest ...........34 7 Seat Variant...........39 Position............34 Ÿ Seat Backrest Adjustment and Folding 39 Ÿ Ÿ Height Adjustment........34 Seat Overturn ...........39 Ÿ Front Seat..........34 Seat Backrest Folding.......40 Ÿ Ÿ Seat Position and Backrest Seat Layout Diagram........40 Ÿ...
Page 36: Headrest
SEATS AND PROTECTIVE DEVICES Headrest Front Seat Position Height Adjustment Seat Position and Backrest Normal Condition The middle position of the headrest should be To adjust the headrest upward, pull the • When you sit on the seat, make your hips on the same horizontal line as the occupant’s headrest upward to a proper position and fix as close to the backrest as possible.
Page 37: Seat Position Adjustment
SEATS AND PROTECTIVE DEVICES Seat Position Adjustment Manual Adjustment Type* Electric Adjustment Type* • The seat height shall be so set that the occupant can see all directions and the positions of all display instruments. The head must be at least one hand away from the roof lining The thighs are right on the seat without constriction.
Page 38: Seat Backrest Adjustment
SEATS AND PROTECTIVE DEVICES Seat Backrest Adjustment Manual Adjustment Type* Electric Adjustment Type* Ventilation Seat Control Button Some variants of vehicles have the ventilation Pull up the handle near the seat cushion; adjust As shown in the figure, turn the adjustment function for the front seats.
Page 39: Driver's Seat Height Adjustment
SEATS AND PROTECTIVE DEVICES Driver’s Seat Height Adjustment Seat Backrest Adjustment and Folding Manual Adjustment Type* Electric Adjustment Type* Turn the handle on the outer side of the seat As shown in the figure, rotate the height The seat backrest inclination angle is upward and downward until the seat is adjustment switch on the outer side of the seat adjustable within a certain range.
Page 40: Rear Seat
SEATS AND PROTECTIVE DEVICES Rear Seat Rear Seat (5 Seat Model) Middle Row Seat To recover, pull up the drawstring and unfold Rear seat cannot be adjusted forward or the backrest to a proper angle. Finally, try to backward. shake the backrest to check whether it is fixed. Armrest Note Hold the backrest first and do not make...
Page 41: Seat Variant
SEATS AND PROTECTIVE DEVICES 7 Seat Variant Seat Backrest Adjustment and Folding Seat Overturn To recover, pull up the lever and unfold the backrest to a proper angle. Finally, try to shake the backrest to check whether it is fixed. Note Hold the backrest first and do not make the head or other body parts within the...
Page 42: Seat Backrest Folding
It is strongly recommended to 7 Seater layout diagram have the seat belt or deployed seat belt tensioner at the MG Authorised Service Center replaced after an accident. Seat Belt Force Limiter* It is configured on the seat belts for the driver’s seat and the left seat of second row.
Page 43: Wearing
The deployed seat belt pretensioner must be 1. Pull out the seat belt from the recoiler, and replaced by the MG Authorised Service Warning fasten it across the body without twisting. Center. The seat belt pretensioner can only be The seat belt shall not be buckled against deployed once.
Page 44: Height Adjustment
SEATS AND PROTECTIVE DEVICES Unbuckle Middle Row / Rear Row Seat Belt Left and Right Seat Belt Loose or heavy clothing will hamper close For buckling and unbuckling of the left and wearing the seat belt. Do not place any object right seat belts of the rear row, please refer to (such as hand bag and mobile phone) between that of the front seat belt.
Page 45: Seat Belt Use During Pregnancy
SEATS AND PROTECTIVE DEVICES Seat Belt Use during Pregnancy Warning The hip belt shall be placed as low as possible to go across the pelvis, so as avoid force on the belly. 2. Plug the latch plate at the seat belt end into The seat belt provides protection for the small buckle on the left side of the seat.
Page 46: Child Seat
SEATS AND PROTECTIVE DEVICES Child Seat Child Restraint System Type Caution The vehicle is not equipped with a child seat. If you want to add one, a child seat that is For a little child, a child seat shall always applicable to ISOFIX “general”...
Page 47: Isofix
SEATS AND PROTECTIVE DEVICES ISOFIX Caution The size and configuration range of the child seat is very wide. Not all child seats are applicable to your vehicle due to the effects of the vehicle trim as well as the s e a t s h a p e a n d s i z e . Y o u h a v e responsibility to ensure that the child seat installed matches with your vehicle and that the child seat can be connected...
Page 48 SEATS AND PROTECTIVE DEVICES vehicle. Refer to the child seat instructions to get to know when and how to strain the upper strap. As shown in the figure, the ISOFIX upper fixing point is on the roof above the rear seat. Open the outer cover from the upper edge.
Page 49: Table Of Vehicle Handbook Information On Child Restraint Systems
SEATS AND PROTECTIVE DEVICES Table of Vehicle Handbook Information on Child Restraint Systems installation suitability for various seating positions Mass Group Seating position (or other site) Front Passenger Front Passenger Rear Centre Intermediate Intermediate Outboard Centre Group 0 up to 10 kg Group 0+ up to 13 kg Group I 9 to 18 kg Group II 15 to 25 kg...
Page 50: Air Bag System
SEATS AND PROTECTIVE DEVICES Air Bag System Air Bag Indicator Warning Depending on the vehicle configuration, the system includes the following air bags: Even if an air bag is equipped, you may • Driver frontal air bag also be injured seriously or lose your life in a collision accident if you do no use the •...
Page 51: Air Bag Position
SEATS AND PROTECTIVE DEVICES Air Bag Position Frontal Air Bag Side Air Bag* Side Curtain Air Bag As shown in the Figure A above, the driver As shown in the Figure C, the front seat side As shown in the Figure D, the side curtain air frontal air bag is located in the middle of the air bag is installed on the backrest side near to bag is installed at the side wall and roof joint,...
Page 52 (such as telegraph pole and tree trunk), rear- and dust may come out from its air event. accident, please contact the MG Authorised end collisions under large vehicle (trucks, etc.) Service Center timely to provide professional breast board and lateral glancing collisions.
Page 53 Please drive to the The deployment of the front passenger air bag MG Authorised Service Center for repair and may also cause damage to the windshield. maintenance of the air bag system. •...
Page 54 SEATS AND PROTECTIVE DEVICES • Side collision • Overturn, falling from high place, rolling • Hit into front vehicle bottom, especially truck bottom • Rear-end collision • Hit deformable objects, such as sandpile, guard bar, column and tree...
Page 55 SEATS AND PROTECTIVE DEVICES Side Air Bag / Side Curtain Air Bag (If Equipped) May not Be Inflated in the Following Collisions In case of side collisions with certain angle or collisions to vehicle body side (not passenger compartment), the side air bag/side curtain air bag system may not be activated.
Page 56 SEATS AND PROTECTIVE DEVICES Important Note • Rear-end collision • Side collision to truck during drifting Do not use a backward-facing child restraint system on a seat (front seat) protected by a frontal air bag (in activated state). Otherwise, severe injuries or even death may be caused to the child when the air bag is deployed.
Page 57: Storage
STORAGE Storage Storage Box ..........56 Ÿ Instrument Panel Right Storage Box ............56 Instrument Panel Central Ÿ Storage Box ............56 Ÿ Armrest Storage Box ........56 Glasses Box* ..........56 Ÿ Console Storage Box* .........57 Ÿ Glove Box ............57 Ÿ Seat Pocket.............57 Ÿ Cup Holder ............57 Ÿ...
Page 58: Instrument Panel Right Storage Box
STORAGE Storage Box Instrument Panel Right Storage Box Armrest Storage Box Glasses Box* It is located between the front seats. Pull up If equipped, the glasses box is located on the Instrument Panel Central Storage Box the storage box cover to open it. roof.
Page 59: Console Storage Box
STORAGE Console Storage Box* Cup Holder Warning Keep the glove box door closed when the vehicle is running to reduce the injury risks in case of accidents or emergency braking. Seat Pocket It is behind the armrest box. The cup holder is located on the console between the front seats.
Page 60: Door Storage Groove And Armrest
STORAGE Door Storage Groove and Armrest Rear Side Wall Storage Groove Backrest Hook and Armrest The door storage groove and armrest are They are located on the left and right rear side On the junction of each seat backrest and located on inner side of the door panel.
Page 61: Luggage Compartment Cargo Cover
STORAGE Luggage Compartment Cargo Cover* Packing Up Luggage Cover Luggage Cover Removal The cover is used to shield the objects in the As shown in the figure, release the luggage As shown in the figure, press the caps on both luggage compartment.
Page 62: Roof Rail
STORAGE Roof Rail Warning Warning The roof rail is an external trim item. To avoid damaging the vehicle, please do not use the Do not place any object on the luggage It is forbidden to place a cigarette lighter, rack to load heavy objects. compartment cargo cover.
Page 63: Instruments And Controls
INSTRUMENTS AND CONTROLS Instruments and Controls Instrument Panel ........62 Control Indicators.........78 Ÿ Electronic Parking Brake (EPB) Fault Warning Lamp* ........91 Controls ..........63 Type-I Instrument Cluster ......78 Ÿ Ÿ Automatic Vehicle Hold (AVH) Horn..............63 Type-II Instrument Cluster ......80 Ÿ Ÿ Working Indicator* ........92 Ÿ...
Page 64: Instrument Panel
INSTRUMENTS AND CONTROLS Instrument Panel...
Page 65: Controls
INSTRUMENTS AND CONTROLS Controls Horn Front window defroster vent 19. 360 degree panoramic parking screen switch* Front passenger airbag 20. Parking assist system switch* ESC OFF switch 21. Gear Knob Central air vent 22. Ignition switch* Front air outlet 23. Clutch pedal* Control panel 24.
Page 66: Steering Wheel Adjustment
INSTRUMENTS AND CONTROLS Steering Wheel Adjustment* Caution The driver must keep absolute control of the steering wheel during driving. It is not allowed to adjust the steering wheel while the vehicle is running. Adjusting the steering wheel during driving can cause the vehicle out of control.
Page 67: Rear Windshield Wiper And Washer
INSTRUMENTS AND CONTROLS Front Windshield Washer Rear Windshield Wiper and Washer* Exterior Entertainment Power Outlet* To use the rear windshield washer, turn the To spray cleaning fluid on the front windshield: The entertainment system interface is located ignition switch to “ON” position first and then below the air conditioning panel.
Page 68: Rear Accessory Usb Power Outlet
INSTRUMENTS AND CONTROLS Rear Accessory USB Power Outlet* Driving Recorder USB Power Outlet Rear Power USB Port * The second-row USB power outlet (5V/2A) is The driving recorder is located at the bottom There is USB power jacks (5V/2A) available for located at the rear end of the console and it of the inside rearview mirror and it can the second and third row seat and can be used...
Page 69: Warning Lamps, Gauges And Indicators
INSTRUMENTS AND CONTROLS Warning Lamps, Gauges and Indicators Speedometer Tachometer Fuel Gauge It displays the vehicle speed. It displays the engine crankshaft revolutions It displays the fuel level in the fuel tank. per minute. If the fuel level in the fuel tank is too low, the Note control indicator will illuminate.
Page 70: General Odometer
INSTRUMENTS AND CONTROLS Small Odometer Engine Coolant Temperature Gauge General Odometer It displays the temperature of the engine It displays the total accumulated kilometers of It shows vehicle kilometers for a driving trip coolant. the vehicle. After it has been reset to zero. In this mode, “C”...
Page 71: Type-I Trip Computer Display Screen
INSTRUMENTS AND CONTROLS Type-I Trip Computer Display Screen Adjustment Lever Caution If the engine coolant temperature is too high, please stop the vehicle, shut down the engine and inspect the coolant level. The trip computer monitor is located Short press or long press the adjustment lever b e t w e e n t h e t a c h o m e t e r a n d t h e to switch among different screens or carry out speedometer.
Page 72: Mobile Phone Wireless Charging
INSTRUMENTS AND CONTROLS Mobile Phone Wireless Operation of Mobile Phone Charging System Wireless Charging If your vehicle is equipped with a mobile phone Caution wireless charging system, the system can When the driver leaves the vehicle, achieve wireless charging of mobile phones please do not place the mobile phone in through electromagnetic induction, without the vehicle for charging, so as to avoid...
Page 73: Type-Ii Trip Computer Display Screen
INSTRUMENTS AND CONTROLS Type-II Trip Computer Display Screen Instrument Cluster Control Button* Type-II trip computer display screen can be controlled with the control button on the steering wheel. Only when the ignition switch is turned to ON can the instrument cluster be controlled.
Page 74 INSTRUMENTS AND CONTROLS Interface - 2 Tyre Pressure Indication operated in two ways: short press (<2S) Note and long press (<2S). Please keep the tyre pressure within the reference range, otherwise the tyre service life and vehicle controllability can be reduced, or flat tyre can happen which Trip Computer Information Option is very dangerous.
Page 75 INSTRUMENTS AND CONTROLS Interface - 3 Interface -1 Driving Time / Fuel Range Fault Information Inquiry insufficient, add fuel” will appear in the fuel range indication area. If you long press “OK” on the current interface, the driving time will be cleared, while the fuel range cannot be cleared.
Page 76 INSTRUMENTS AND CONTROLS Interface - 2 Fatigue Driving Warning Setup Multimedia Information Option Bluetooth Telephone Information Option Enter the fatigue driving function setup Choose this option and the instrument cluster Choose this option and the Bluetooth interface and you can make fatigue driving will show AM, FM or audio information real- telephone interface will appear.
Page 77 INSTRUMENTS AND CONTROLS Gear Position Display* Navigation Information Option (Equipped on AT Model Only) same time, the arrow icon (↑) in the gear position display area will illuminate. For more details, please refer to “Automatic Transmission” in the driving and control section.
Page 78 INSTRUMENTS AND CONTROLS Instrument Cluster Display Brightness Type - II Instrument Cluster* Adjustment Type - I Instrument Cluster* For high-configuration models, a backlight As it is shown in the figure, the current brightness adjustment button is set at the left backlight brightness will be shown on the LCD Turn the adjustment lever to set the desired side of the instrument panel.
Page 79: Type-I Trip Computer Display Screen Switch
INSTRUMENTS AND CONTROLS Type - I Trip Computer Display Screen Switch If the vehicle is equipped with a Type-I trip computer display screen, you can short press or long press the adjustment lever on the instrument cluster to switch the display modes or conduct clearing. As it is shown in the figure:...
Page 80 INSTRUMENTS AND CONTROLS...
Page 81: Control Indicators
INSTRUMENTS AND CONTROLS Control Indicators Type - I Instrument Cluster If the vehicle is equipped with a Type-I trip computer display screen, you can short press or long press the adjustment lever on the instrument cluster to switch the display modes or conduct clearing. As it is shown in the figure:...
Page 82 INSTRUMENTS AND CONTROLS Engine Tachometer 18. Speedometer 33. Driver Side Seat Belt Warning Light Start And Stop System Shutdown 19. Emergency Stop Light* 34. Passenger Side Seat Belts Warning Indicator* Lights* 19a. SCR (Selective Catalytic Reduction) Start And Stop System Work Indicator* Warning Light 35.
Page 83: Type-Ii Instrument Cluster
INSTRUMENTS AND CONTROLS Type - II Instrument Cluster...
Page 84 INSTRUMENTS AND CONTROLS Speedometer 20. Automatic Parking (AVH) Work 36. Gear Display* Indicator* Engine anti-theft system indicator / 37. Total Odometer Immobilizer 21. Automatic Parking (AVH) Fault 38. Display Warning Light* Transmission Failure Warning Light* 39. Water Temperature Warning Lamp 22.
Page 85: Turn Signal Lamp / Hazard Warning Indicator
INSTRUMENTS AND CONTROLS Turn Signal Lamp / Engine Oil Pressure Too Low Hazard Warning Indicator Warning Lamp Caution These indicators are essential for assurance of driving safety. If the turn signal lamp or the hazard flasher indicator bulb has burnt out, please replace it immediately.
Page 86: Charging System Warning Lamp
4. If the drive belt is normal but the charging system warning lamp keeps illuminated, it can indicate a charging system fault. We advise you to go to the nearest MG Authorised Service Center for vehicle repair as soon as possible.
Page 87: Coolant Temperature Too High Warning Lamp
INSTRUMENTS AND CONTROLS Coolant Temperature Too High Warning Lamp Front Fog Lamp Indicator* Rear Fog Lamp Indicator This warning lamp illuminates as you turn on This indicator illuminates when the front fog This indicator illuminates when the rear fog the ignition switch and it goes out several lamp is turned on.
Page 88: Headlamp High Beam Indicator
INSTRUMENTS AND CONTROLS Headlamp High Beam Indicator Position Lamp Indicator Engine Malfunction Indicator Lamp (MIL) The high beam indicator illuminates when the This indicator illuminates when the position This indicator lamp illuminates when the headlamp high beam is turned on. lamp is turned on.
Page 89: Abs Fault Warning Lamp
It other properties can occur. We advise you to go to the nearest MG indicates that the system is conducting self- Authorised Service Center for vehicle inspection and the warning lamp bulb can repair as soon as possible.
Page 90: Eps Fault Warning Lamp
The warning lamp goes out several seconds accident. We strongly advise you to drive later. the vehicle to the nearest MG Authorised Service Center for inspection. If an When the electronic power steering (EPS) accident happens after the airbag system...
Page 91: Brake System/Ebd Warning Lamp
4. In case of the following circumstances, we advise you to drive the vehicle at a safe Model with Mechanical Hand Brake speed to the nearest MG Authorised The brake system warning lamp illuminates Service Center to inspect the brake and...
Page 92: Engine Immobilizer System Indicator
MG Authorised Service This indicator illuminates when the door is Center to inspect the brake system. opened. It goes out after the engine is started.
Page 93: Driver Fasten-Seat-Belt Warning Lamp
INSTRUMENTS AND CONTROLS Front Passenger Fasten-Seat-Belt Driver Fasten-Seat-Belt Warning Lamp Warning Lamp* Fuel Level Too Low Warning Lamp The seat belt warning lamp illuminates if the The seat belt warning lamp illuminates if the This warning lamp will illuminate immediately driver does not fasten the seat belt properly front passenger seat is occupied but the the ignition switch is turned on.
Page 94: Electronic Parking Brake (Epb) Working Indicator
INSTRUMENTS AND CONTROLS Electronic Parking Brake (EPB) Electronic Parking Brake (EPB) Working Indicator* Fault Warning Lamp* Once the electronic parking brake (EPB) fault warning lamp shows the above abnormalities, please contact the Service Center in time. An electronic parking brake fault can cause the vehicle to coast.
Page 95: Automatic Vehicle Hold (Avh) Working Indicator
Ÿ The lamp Illuminates during driving. Once the automatic vehicle hold (AVH) fault warning lamp shows the above abnormalities, please contact the MG Authorised Service Center in time. The automatic vehicle hold (AVH) working The automatic vehicle hold (AVH) fault...
Page 96: Esc Fault Warning Lamp
INSTRUMENTS AND CONTROLS ESC Fault Warning Lamp ESC OFF Indicator Transmission Fault Warning Lamp* The warning lamp illuminates after the ignition The warning lamp illuminates after the ignition The transmission fault warning lamp switch is turned on and it goes out several switch is turned on and it goes out several illuminates when the ignition switch is turned seconds later.
Page 97: Emergency Parking (Ep) Indicator
“Driving and Controls”. alarm sound. In case of this, please stop the vehicle at the nearest safe place and contact the MG Authorised Service Center immediately. Please do not continue driving until the fault is removed.
Page 98: Tpms Fault Indicator
INSTRUMENTS AND CONTROLS TPMS Fault Indicator* Overspeed Warning Alarm will stop warning when the speed comes below 115km/h, then again over 120km/h, it will be warn for overspeed. Vehicle – Start / Stop Function The warning lamp illuminates after the ignition If the vehicle speed is greater than 80km/h, the switch is turned on and it goes out several meter will make an audible alarm sounds and...
Page 99: Scr (Selective Catalytic Reduction)
Parts. If the indicator is still glowing as possible with at least 5 liters of Diesel for a while, repeat the process. Do it 3 or 4 please contact the MG Authorised Service Exhaust Fluid (DEF). times. If the indicator is still running after Centre for rectification if necessary.
Page 100: Engine Hood Open Indicator
This means that the engine is warming up. Do Please contact the MG Authorised Service Vehicle – Start / Stop Fault Indicator not start during this period, once the light is Centre as soon as possible.
Page 101: Reverse Sensor
INSTRUMENTS AND CONTROLS Reverse Sensor* The intelligent reverse sensor judges the When the distance between the vehicle and the Note distance between rear end of the vehicle and the obstacle behind it is within about 0.4 m, the To ensure reversing safety and to leave Ÿ...
Page 102: Reverse Video Display
INSTRUMENTS AND CONTROLS Reverse Video Display* Sector Indication Area* The bottom red line represents the warning line for a distance front the obstacle to the vehicle rear end within 0.4 m; the middle yellow line represents the warning line for a distance from the obstacle to the vehicle rear end within 1.0 m;...
Page 103: Parking Assist System
The driver should always keep if the parking brake is released at this time, the assist system can only help the driver concentrated. MG Motor shoulders no parking assist system starts to work. avoid accident during reversing or responsibility for any personal injury or If front/rear end of the vehicle is within certain parking.
Page 104: Degree Panoramic Parking Screen Assist
INSTRUMENTS AND CONTROLS 360 Degree Panoramic Parking System Display* Parking Screen Assist* T h e p a r k i n g a s s i s t s y s t e m a c t i v a t e s automatically (under the precondition that the parking brake is released) as the shift lever is turned to the reverse gear.
Page 105: Parking Image Assist During Reversing
MG India is not responsible for any inadvertent driving if assisted by the behind the vehicle when reversing. parking screen of the device cause Parking Image Assist at Forward Gear personal injury and property damage.
Page 107: Lighting
LIGHTING Lighting Outside Lighting........104 Stop Lamp.............107 Ÿ Ÿ Day Running Lamp*........107 Ÿ Lighting Switches.........104 Headlamp Leveling........107 High Beam ............104 Ÿ Ÿ Ÿ Headlamp OFF Delay.........107 Ÿ Automatic Headlamp ON/OFF ....104 Headlamp Flashing ........104 Ÿ Lamp ON Reminder........107 Ÿ Inside Lighting ........108 Ÿ...
Page 108: Outside Lighting
LIGHTING Outside Lighting Lighting Switches instrument panel lamp and backlight of all the The headlamp high beam indicator illuminates when the headlamp high beam is turned on. To panels illuminate. switch from headlamp high beam to low beam, = The low beam lamp and all lamps pull the control lever towards the opposite mentioned above illuminate under the direction until it returns to the normal...
Page 109: Automatic Wiping
LIGHTING Automatic Wiping Hazard Flasher Turn and Lane Change Signal Lamp The sensor is installed on the front windshield Press to turn on/off the hazard flasher. To turn on the Turn And Lane Change Signal Lamp, the ignition switch must be in ON Light and rain sensors are used to sense light Note position.
Page 110: Fog Lamp
LIGHTING Fog Lamp Front Fog Lamp* Steering Assist Lighting Function* During steering, the two front fog lamp will A rear turn signal lamp is integrated on the illuminate to provide auxiliary lighting if certain rear combination lamp and the rear bumper of conditions are satisfied.
Page 111: Rear Fog Lamp
LIGHTING Rear Fog Lamp Day Running Lamp* The day running lamp turns on automatically 2 = all seats occupied with the luggage as the engine starts; it goes out automatically compartment loaded as the position lamp is turned on. 3 = driver’s seat occupied with the luggage Headlamp Leveling compartment loaded Headlamp OFF Delay...
Page 112: Inside Lighting
LIGHTING Inside Lighting Front Reading Lamp Type-I Type-II Rear Reading Lamp Type-I The lamp has 3 working positions. : Press the button to turn on the The rear reading lamp has 2 working buttons: left/right reading lamp and press it again to : The lamp illuminates and keeps : Press the switch and the lamp turn the lamp off.
Page 113: Luggage Compartment Illumination Lamp
LIGHTING Type-II Luggage Compartment Illumination Lamp For certain models, two reading lamps are The luggage compartment illumination lamp installed on the roof over the second row illuminates as the liftgate is opened. It goes out seats. You can press the reading lamp switch after the liftgate is closed.
Page 115: Audio Entertainment System
AUDIO ENTERTAINMENT SYSTEM Audio Entertainment System Audio Control Buttons on Steering Wheel* .........112 Driver Information and Entertainment ........113 Navigator Upgrading* ......114 Ÿ...
Page 116: Audio Control Buttons On Steering Wheel
AUDIO ENTERTAINMENT SYSTEM Audio Control Buttons on Steering Wheel* Type I 4. Song Selection / Station Switch 4. Audio Source Selection Button Thumbwheel Press the button to switch among audio Pull the thumbwheel up and down to select the sources such as radio / USB / Bluetooth music. station or song.
Page 117: Driver Information And Entertainment
Please use other players to play the file and then confirm whether the problem lies in this device. If the fault still cannot be removed, please go to the MG Authorised Service Center for inspection. Never disassemble the host to repair it on yourself.
Page 118: Navigator Upgrading
AUDIO ENTERTAINMENT SYSTEM Navigator Upgrading* W h e n t h e n a v i g a t o r c a n n o t d i s p l a y comparatively new main roads, it is time to update and upgrade the map data.
Page 119: Hvac
HVAC HVAC Air Outlet ..........116 Ÿ Temperature Control Knob ....123 Ÿ Fan Control Knob ....... 123 Air Conditioning .........118 Electronic Air Conditioning Ÿ Air Distribution Mode Button ..123 Ÿ Control Panel ........118 Ÿ Internal Circulation Mode Button..123 Ÿ Temperature Control Key ....119 Ÿ...
Page 120: Air Outlet
HVAC Air Outlet 1. Side Air Outlet 3. Front Windshield Defogger Air Outlet 5. Floor Air Outlet 2. Front Door Window Defogger Air Outlet 4. Central Air Outlet 6. Console Air Outlet...
Page 121 HVAC Console Air Outlet Rear Air Outlet* Side Air Outlet You can divert the air to both sides of the front riding area or the side door windows by operating the two adjustable side air outlets. Beside each air outlet, an air volume adjustment switch is located and you can operate the switch to adjust the air volume.
Page 122: Air Conditioning
HVAC Air Conditioning Electronic Air Conditioning Control Panel 1. A/C Interface 2. A/C Key 3. Auto Key 4. Temperature Rise Key 5. Temperature Adjustment Slider 6. Temperature Drop Key 7. Air Volume Increase Key 8. Air Volume Adjustment Slider 9. Air Volume Decrease Key 10.
Page 123: Temperature Control Key
HVAC Temperature Control Key Air Distribution Mode You can also adjust the A/C temperature via One of the following five positions can be temperature slider. selected in the air distribution mode according to the required airflow direction. Once the temperature reaches the hottest (coolest) extent, if you pull the switch up again, the temperature stays unchanged.
Page 124 HVAC Face-foot Mode Key ( ) Face Mode ( ) Most of the air flows out from the floor air outlet and the front seat lower air outlet; little amount of air flows out from the windshield and front door window defroster air outlet and the side air outlet.
Page 125: Front Windshield Defrosting Key
HVAC Front Windshield Defrosting Key Internal / External Circulation Mode Key Press the button to select the front windshield You can press this button during driving on a Press this key to switch to the external defroster mode. dusty road, or when you want to prevent the circulation mode.
Page 126: Manual Air Conditioning
HVAC Manual Air Conditioning Control Panel 1. Fan Control Knob 2. Front Windshield Defroster Button 3. Air Conditioning (A/C) Button 4. Internal Circulation Button 5. Rear Windshield Defroster Button / Outside Rearview Mirror Defroster Button* 6. Temperature Control Knob 7. Face Blowing Mode 8.
Page 127: Temperature Control Knob
HVAC Temperature Control Knob Fan Control Knob direction. Control the air to blow out from the corresponding air outlet. Please refer to the contents of "Air Distribution Mode" of the above automatic constant temperature A/C. Internal Circulation Mode Button It is used to control temperature of the air Turn the fan speed control knob to control flowing out from the air outlet.
Page 128 HVAC Air Conditioning (A/C) Button Caution If you use the rear windshield defroster under these circumstances, the vehicle You may feel tired and sleepy after long- battery can become under voltage. time driving in the internal circulation Lack of proper maintenance may cause mode, so please switch to the external damage to the defroster or scratches on mode on a regular basis to acquire fresh air.
Page 129: Cool Air
HVAC Cool Air Warm Air Fast Cooling Rapid Heating Note To cool down fast in scorching hot days or Activate the rapid heating mode to increase After the air conditioning system is the passenger area temperature quickly. It is after the vehicle is kept under the blazing sun turned on, you can find water drops in the prohibited to activate this mode for a long for a long time:...
Page 130: Ventilation
HVAC Rapid Defrosting and Defogging Rear Fan Control Switch* Ventilation Please operate in the following steps in Dual Mode cold weather: This mode is applicable to cool and sunny days. Ÿ Air conditioning switch (A/C): ON Warm air is controlled to flow to the floor (southern area) or OFF (northern area) area and outside cool air is controlled to flow Ÿ...
Page 131: Driving And Controls
DRIVING AND CONTROLS Driving and Controls Driving Instructions .......128 Shifting ...............139 Electronic Stability Control (ESC) Ÿ Ÿ System .............. 148 Vehicle Control ..........128 Gear ..............139 Ÿ Ÿ Ÿ ESC OFF Switch ..........150 Emergency Measures........128 Gear Display.............140 Ÿ Ÿ Ÿ Hill-start Hold Control (HHC) Start and Operation ......129 Ÿ...
Page 132: Driving Instructions
After inspection, send the vehicle to the MG Ÿ Have the engine run at idle, and turn the Authorised Service Center for inspection and transmission at the neutral position.
Page 133: Start And Operation
After taking provisional measures, Ÿ steam or coolant overflowed, and thus the performance, promote the vehicle immediately send the vehicle to the MG your face or other body parts may be economy and extend the service life: Authorised Service Center for inspection.
Page 134: Mechanical Ignition Switch Position
DRIVING AND CONTROLS Mechanical Ignition Switch Position* Ÿ Note Please do not use such vehicle electric The engine can be shut down when the equipment as audio and head lamp for a ignition key is turned to the ACC position long time under the condition that the without the need to lock the steering wheel.
Page 135: Engine Start Stop Switch Position
DRIVING AND CONTROLS ENGINE START STOP Switch Position* able to detect the legal key. Please place the Caution key at one position near the ENGINE START Never remove the key or turn the key STOP switch inside the vehicle, such as switch when the vehicle is running.
Page 136: Electronic Steering Column Lock
DRIVING AND CONTROLS Press the ENGINE START STOP switch at the 1. The vehicle is motionless Note ACC position once; the position can be Never keep the engine idling at high 2. The ignition switch is at the LOCK switched to the ON position. The instrument speed for over 5 min.
Page 137: Engine Starting
DRIVING AND CONTROLS Engine Starting 2. Ensure that seats and rearview mirrors Before starting the engine: Note are at proper positions. Adjust them if Ÿ Ensure that no barriers exist around the Keep the engine idling for 3-5 min before necessary.
Page 138: Engine Start Stop Function
DRIVING AND CONTROLS Turbocharged Engine Shutdown Other Control Instructions After keeping the turbocharged engine 1. Emergency start 2. Emergency flameout operating at high speed for a long time, please Ÿ The brake or clutch switch failure will If emergency flameout of the engine is firstly keep it idling for 3-5 min and then kill it, make the start conditions unable to be required when the vehicle is running, you can...
Page 139: Cruise Control System
DRIVING AND CONTROLS Cruise Control System * Type-I Switch As the switch of cruise control system is at the stabilize the speed at 100 km/h, the driver steering wheel, when the cruise control must firstly speed up to 100 km/h. When the system is started, the vehicle can run at such speed reaches 100 km/h, he/she shall press the speed.
Page 140: Engine Immobilizer System
DRIVING AND CONTROLS Third Step: Operation for Cruise Fifth Step: How to Reduce Cruise Note Recovery Control Speed For the MT model, after the cruise control system is started, if you intend to When the vehicle exits from the cruise state and Pull the toggle button towards the “SET/-”...
Page 141: Parking
DRIVING AND CONTROLS Manual Transmission* Note Caution If the vehicle is equipped with one Do not park and drive the vehicle on steering wheel mechanical lock again, a inflammables such as straw and hay. If better anti-theft result will be realized. such inflammables cannot be avoided, park the vehicle to check and confirm Parking...
Page 142: Operation For Shifting Transmission With Six Drive Gears To Reverse (R) Gear
DRIVING AND CONTROLS Operation for Shifting Transmission with Automatic Dual Clutch Six Drive Gears to Reverse (R) Gear Transmission (DTC) * Your vehicle may be equipped with one Note automatic dual clutch transmission, which is a When shifting between the drive gear wet automatic dual clutch transmission with 6 and the reverse gear, be sure to ensure gears.
Page 143: Shifting
DRIVING AND CONTROLS Shifting Locking Button Gear Lever Operation be switched to the drive (D) gear. For example, the duration of the gear lever at the neutral (N) gear is over 2s when the vehicle is 5 km/h. Gear P: Parking Gear The transmission is locked mechanically at the parking gear.
Page 144: Gear Display
DRIVING AND CONTROLS Gear Display D: Drive Gear (Economy Mode) It is used for normal driving. The transmission Toggle the gear lever to the (-) position, and automatically selects among 6 drive gears one gear will be reduced. If the vehicle speed is according to the vehicle speed and the excessively high, the system will not accelerator pedal position.
Page 145: Vehicle Start
DRIVING AND CONTROLS Kick-down After you select the drive (D) gear to drive the As shown in the figure above, when the vehicle Section “Electronic Parking Brake (EPB)” vehicle, if you depress the accelerator pedal is running in the manual mode, if the vehicle under Chapter “Driving and Controls”...
Page 146: Run Downhill
If the transmission enters the limping above, please contact the MG Authorised push the gear lever from the drive (D) gear mode, please contact the MG Authorised...
Page 147: 48V Hybrid Power System
DRIVING AND CONTROLS 48V Hybrid Power System* Auto Engine Start The 48V hybrid power system has the After the engine automatically flames out, the After starting the engine, press the start-stop following functions: auto engine start-stop, engine can be started by any one of the disabling switch, as shown in the figure.
Page 148: Situations Of Auto Engine Start
DRIVING AND CONTROLS Situations of Auto Engine Start After the engine automatically stops, when the 7. The rate of rotation of the steering wheel Dangers vehicle is in any one of the following states (AC is greater than a certain value. After automatic stop, although the should be in switched off condition), the 8.
Page 149 DRIVING AND CONTROLS Start-Stop Timing Battery Capacity Energy Flow Display No-energy Flow Mode The start-stop timing displays the accumulated Display the 48V battery capacity. Represent that there is no energy flowing time of the auto engine stop after the ignition because the engine flames out.
Page 150 DRIVING AND CONTROLS Standby Mode Assist Power Mode Energy Recovery Mode Represent that there is no energy flowing. When the engine speed is lower (<1,800 When the vehicle speed is greater than 20 r/min), and the 48V battery capacity is greater km/h during sliding and braking, without than 40%, the driver speeds up at full depressing the clutch, the system can recover...
Page 151: Continuous Variable Transmission (Cvt)
DRIVING AND CONTROLS Automatic Transmission Instruction for use: Selector Lever 1. Before starting the engine, depress the There is a locking button on the gearshift to Continuous Variable brake pedal firstly to confirm that the prevent the wrong choice of P or R in other Transmission (CVT) transmission gear lever is at the P gear, and gears.
Page 152 DRIVING AND CONTROLS Note automatic mode, which can provide better operating performance. When parking the vehicle on a ramp, press the brake pedal first and pull the hand brake M: Manual Shift Mode before putting the vehicle in P gear. Select the manual mode when the gearshift is R: Reverse Gear moved to the right position (+/–) from...
Page 153 DRIVING AND CONTROLS Warnings Gear Display Ÿ Do not press the accelerator pedal while shifting from P (Park) or N (Neutral) to R (Reverse), D (Drive) or L (Low). Always press the brake pedal until shifting is completed. Failure to do so could cause you to lose control and have an accident.
Page 154 DRIVING AND CONTROLS Downhill Driving Otherwise, the transmission will be seriously Caution damaged. When stopping the vehicle on an uphill If the brake pedal is pressed continuously for a grade, do not hold the vehicle by pressing long time, it may cause the brake to overheat, Limp Mode the accelerator pedal.
Page 155: Brake
Therefore, after driving through water or inspected at the MG Authorised Service having your vehicle cleaned, keep the vehicle running at low speed and depress Center. This may indicate a faulty brake the brake pedal intermittently and gently, system.
Page 156: Anti-Lock Brake System (Abs)
ABS is faulted. Please different ground to which four wheels are 2. Keep safe driving speed to ensure there is immediately contact the MG Authorised attached, and thus calculate different friction sufficient space behind your vehicle and at Service Center.
Page 157 DRIVING AND CONTROLS angle sensor are added. The driving force and working. If the ESC system functions switch is pressed by one unknown article braking force of front and rear, left and right abnormally but the ABS+EBD system incautiously), the ESC function will not be wheels are controlled through the ECU, which functions normally, the ESC indicator is disabled.
Page 158: Esc Off Switch
DRIVING AND CONTROLS ESC OFF Switch Whether the driver is driving or reversing onto 2. The vehicle is motionless and the brake a hill, the start assistant is provided through the pedal is depressed; function. Therefore, engage gear before 3. The system detects that the gradient value starting, please.
Page 159: Parking Brake
Ÿ When parking the vehicle on one downhill When necessary, please have the MG ramp, turn the front wheels towards the Authorised Service Center adjust. road shoulder. Note Vehicle equipped with a manual transmission: Do not drive the vehicle with the parking 1.
Page 160: Electronic Parking Brake (Epb)
DRIVING AND CONTROLS Electronic Parking Brake (EPB) * Manually Apply Parking Brake Manually Release Parking Brake The parking brake impacts rear wheels. If you have to apply parking brake, depress the If you have to release parking brake, firstly brake pedal to stop the vehicle and then draw confirm that the ignition switch is at the ON As shown in the figure above, the EPB switch is back the electronic parking brake switch.
Page 161 DRIVING AND CONTROLS EPB Automatic Clamping Function EPB Hot Disc Reclamping Function continuously conduct the action of drawing back-releasing the EPB switch 6 times. When the engine flames out in the motionless If you park when the rear brake disc temperature state, the vehicle will automatically apply is high, the braking force may reduce after a period Deactivation of Automatic Clamping...
Page 162: Automatic Vehicle Hold (Avh)
We recommend you contact releases the clutch to start the vehicle within 5 press the AVH switch, and the background the MG Authorised Service Center for min, the hydraulic pressure in the brake lamp on the switch illuminates to activate the solution.
Page 163: Fuel
I f y o u s m e l l f u e l o d o r s , p l e a s e the clutch. After the vehicle start conditions immediately ask MG Authorised Service are met, the parking brake will be released Center to repair according to the fault automatically.
Page 164: Fuel Filling
DRIVING AND CONTROLS Fuel Filling Caution Using the fuel with an extremely low octane value will lead to uncontrolled burning and cause the engine to be damaged. Using the fuel containing methyl alcohol is not allowed for the vehicle design. Therefore, do not use the fuel containing methyl alcohol.
Page 165: Vehicle Service & Maintenance
VEHICLE SERVICE & MAINTENANCE Vehicle Service & Maintenance General Information......158 Diesel Exhaust Fluid (DEF) ....166 Ÿ Spare Tyre ..........181 Ÿ Jack Lifting Point ........181 Ÿ Accessories and Vehicle Retrofitting.158 Windshield Wiper.......172 Ÿ Tyre Replacement........182 Ÿ Vehicle Storage........158 Air Filter ..........173 Jump Start (Dead Battery) ....184 Driver Checklist .........158 Ÿ...
Page 166: General Information
VEHICLE SERVICE & MAINTENANCE General Information Driver Checklist Accessories and Vehicle Retrofitting Vehicle Storage Do not slide in case that the engine is out of Long-term Storage Check the interior, exterior and engine operation. Several months of storage of the vehicle: compartment regularly to keep the vehicle Ÿ...
Page 167: Engine Compartment
VEHICLE SERVICE & MAINTENANCE Engine Compartment 1.5T Engine Parking Brake Ensure the travel of parking brake lever is Ÿ appropriate. Instrument Panel Ÿ Check whether all instruments, control buttons and warning lamps are functioning normally. Rearview Mirror Ÿ Ensure the reflecting surface of rearview mirror is in good state and clean.
Page 168: 2.0 Diesel Engine
VEHICLE SERVICE & MAINTENANCE 2.0 Diesel Engine 1. Air filter 2. Brake/clutch fluid reservoir 3. Engine oil filler cap 4. Battery 5. Fuse and relay box 6. Coolant pot 7. Engine oil dipstick 8. Windshield washer solvent container...
Page 169: Engine Oil
This work requires professional skills, tools and equipment; therefore, please Ÿ Avoid repeated or prolonged skin go to the MG Authorised Service Center contact with engine oil. for help. Otherwise, it may cause Ÿ Wash the part in contact with engine personal injury or damage to the vehicle.
Page 170: Coolant
If the coolant level is lower than the MIN Caution to the engine. Please consult the MG (minimum) mark, please go to the MG Authorised Service Center before The engine oil and oil drum are harmful Authorised Service Center for coolant filling attempting to use additives.
Page 171: Brake And Clutch Fluid
Caution Be sure to use the brake/clutch fluid recommended by MG Motor. Add fluid into The coolant is a dangerous substance. the reservoir to reach a proper level. The fluid A v o i d r e p e a t e d o r p r o l o n g e d Ÿ...
Page 172: Auto Transmission Clutch Fluid Adding
2. Open the filler cap. The brake / clutch fluid is irritating to the skin and eyes. 3. Add the clutch fluid recommended by MG Keep the skin or eyes from contact with Motor to reach the MAX (maximum) the brake/clutch fluid. In case of contact, mark.
Page 173: Transmission Fluid
Please go to the MG Authorised Service equipment. To avoid personal injury or vehicle Center for filling of the correct washer damage, it is suggested to go to the MG solvent. Authorised Service Center for help. Do not fill water or radiator antifreezing agent into the windshield washer solvent container.
Page 174: Diesel Exhaust Fluid (Def)
VEHICLE SERVICE & MAINTENANCE Diesel Exhaust Fluid (DEF) Diesel Exhaust Fluid (DEF) Injection Low Diesel Emissions Additive Diesel System Failure Warning Light - Exhaust Fluid (DEF) Indicator Light - If Equipped If Equipped This warning light will illuminate along with a The Low Diesel Exhaust Emissions Additive dedicated message on the display (If Equipped) Diesel Exhaust Fluid (DEF) indicator light...
Page 175 VEHICLE SERVICE & MAINTENANCE MESSAGE DESCRIPTION Diesel Emissions Additive Diesel Exhaust Fluid (DEF) Warning Messages: Low Diesel Emissions Additive Diesel The first low level warning will be given at around 2,400 km range, and is determined according to Exhaust Fluid (DEF) Level Warning the current consumption rate.
Page 176 VEHICLE SERVICE & MAINTENANCE MESSAGE DESCRIPTION Diesel Emissions Additive Diesel Exhaust Fluid (DEF) Fault Warning Messages: Engine Will Not Restart Service Diesel This message will display if Diesel Exhaust Fluid (DEF) system issue detected is not serviced Exhaust Fluid (DEF) System See Dealer during the allowed period.
Page 177 VEHICLE SERVICE & MAINTENANCE Adding Diesel Exhaust Fluid (DEF) Preliminary Conditions Diesel Exhaust Fluid (DEF) - Diesel Exhaust Fluid (DEF) Storage If Equipped Diesel Exhaust Fluid (DEF) is considered a The vehicle is equipped with an Diesel Exhaust very stable product with a long shelf life. If Fluid (DEF) injection system and Selective Diesel Exhaust Fluid (DEF) is kept in Catalytic Reduction to meet emission...
Page 178 Note goes OFF and then start the engine. Instrument Panel" for further information, It is recommended to visit the MG fill the Diesel Exhaust Fluid (DEF) tank Authorised workshop for refill / top up. with no more than 8 liters.
Page 179 VEHICLE SERVICE & MAINTENANCE NOTE: Do not add additives or other fluids to Ÿ Note Diesel Exhaust Fluid (DEF), doing so could If Diesel Exhaust Fluid (DEF) is spilled out Ÿ Once the engine is turned off, the Diesel damage the system. of the filler neck, clean up the area well and Exhaust Fluid (DEF) pump rotates (a noise proceed to filling up again.
Page 180: Windshield Wiper
VEHICLE SERVICE & MAINTENANCE Windshield Wiper Wiper Blade Removal and Installation Foreign objects on the windshield and blade Fold the wiper arm on the windshield for As shown in the figure, firstly press the release will reduce the effectiveness of the wiper. If operation.
Page 181: Air Filter
It is prohibited to drive the vehicle without the air filter element being MG Authorised Service Center for inspection. installed. Otherwise, the engine will be This may indicate faults of the brake system.
Page 182: Fuse
VEHICLE SERVICE & MAINTENANCE Fuse Indoor Fuse Box Engine Compartment Fuse Box Fuse replacement: The indoor fuse box is on the lower left side of The engine compartment fuse box is next to the instrument panel and it can be seen after the battery.
Page 183: Indoor Fuse Box Layout
VEHICLE SERVICE & MAINTENANCE Indoor Fuse Box Layout For vehicles with different models or configurations, the layout of fuse box internal components may be different. The owner’s actual vehicle shall prevail.
Page 184: Engine Compartment Fuse Box Layout
VEHICLE SERVICE & MAINTENANCE Engine Compartment Fuse Box Layout For vehicles with different models or configurations, the layout of fuse box internal components may be different. The owner’s actual vehicle shall prevail.
Page 185: Lamp Bulb Replacement
It Ÿ Light up the lamp for test after the is suggested to go to the MG Authorised bulb being installed. Service Center for help. Otherwise, it Ÿ Replace the cracked or damaged may cause personal injury or damage the headlamp in time.
Page 186: Wheels And Tyres
ABS and other relevant Reduce the fuel economy Ÿ components and even cause collision accidents. Note Please consult the MG Authorised Ÿ Vehicle overload is prohibited. Service Center before replacing original Be sure to keep a proper tyre inflation Ÿ...
Page 187: Internal Tread Wear Indicator
In case of damage or abnormal wear of tyre or wheel, please consult the MG Authorised Service Center for help. The vehicle is equipped with radial tyres. MG Motor suggests replacing with radial tyres of the same size, pattern, tread wear, temperature and rated speed.
Page 188: Tyre Rotation
The front tyres and the rear tyres have using tyre chains, carefully read the installation to the MG Authorised Service Center to different functions and therefore have relearn the tyre pressure. and other related instructions of the tyre chain different levels of wear.
Page 189: Spare Tyre, Jack And Tools
VEHICLE SERVICE & MAINTENANCE Spare Tyre, Jack and Tools Tool Kit Take out the Spare Tyres Jack Lifting Point 5-seat Model 5-seat Model Spare Tyre 1. Open the liftgate and raise the luggage As shown in the figure above, the jack lifting compartment floor.
Page 190: Tyre Replacement
VEHICLE SERVICE & MAINTENANCE Tyre Replacement 1. Take out tools, the jack and spare tyre. 3. Place the jack just below the lifting point 4. As shown in the figure above, connect the Check and confirm that the tyre on the closest to the tyre that needs to be jack rocker to the jack.
Page 191 100~130 N•m. Please replace the leaky tyre as far as Please go to the MG Authorised Service 14. Put the leaky tyre in the spare tyre storage possible for further use. It shall check the Center as soon as possible and tighten location and secure it properly.
Page 192: Jump Start (Dead Battery)
Please use If the battery is dead, please contact the MG (There is a “+” mark on the battery the correct jack in normal state.
Page 193 VEHICLE SERVICE & MAINTENANCE Caution Caution Note There is the risk of battery explosion. You Position the jumper cable properly and It shall start the engine of the vehicle with may be burned by the battery acid, and an do not wrap it around rotating parts of a discharged battery at an interval of electrical short circuit can also cause the engine compartment.
Page 194: Vehicle Traction
If vehicle traction is necessary, please contact 1. Turn on the hazard warning flasher. the MG Authorised Service Center or a 2. Turn the ignition switch to ACC position. professional traction service company. 3. The transmission must be in neutral gear.
Page 195: Emergency Trailer
After completion of traction, MG Authorised Service Center for solution. transmission. remove the towing hook and close the hole cover, and then put the towing hook back into the tool kit.
Page 196: Rear Towing Hook
Ÿ The towing hook must be used when other traction devices are not available. towing is required, it is suggested to contact the MG Authorised Service The vehicle shall be towed from the Ÿ Center or a professional towing service front only.
Page 197: Getting Vehicle Out Of Trap
VEHICLE SERVICE & MAINTENANCE Vehicle Maintenance Getting Vehicle out of Trap Cleaning Agent When the vehicle is caught in snow, puddle or The manufacturer's suggestions must be Note other unstable ground, please follow the observed when using cleaning agent or other In order to avoid damage to the procedures below to get the vehicle out of trap.
Page 198: Vehicle Interior Maintenance And Cleaning
Ÿ must be new. Use a vacuum cleaner or a banister brush to Ÿ Benzene MG Motor suggests replacing the whole seat remove dust and scum that accumulate on the Ÿ Naphtha belt assembly after collision. It is not necessary fabric inside the vehicle frequently.
Page 199: Vehicle Exterior Maintenance And Cleaning
VEHICLE SERVICE & MAINTENANCE MG Motor vehicles are designed to operate Aluminum Wheels and Wheel Trim Note under normal environmental conditions and Cover Cleaning The non-abrasive cleaning agent will natural factors. To maintain the original appearance of the scratch the glass and damage the rear wheel and wheel trim cover (if any), do not windshield defroster grid lines.
Page 200: Corrosion Prevention
VEHICLE SERVICE & MAINTENANCE Corrosion Prevention MG Motor vehicles are designed to have anti- Remove harmful substances on the vehicle in accumulated dirt in the enclosed area before corrosion capabilities. The use of special time. If residues cannot be removed with soap flushing with water.
Page 201: Technical Data
TECHNICAL DATA Technical Data Vehicle Identification ......194 Identification Number (VIN) ....194 Ÿ Vehicle Identification Tag ....194 Ÿ Engine Identification Number .... 194 Ÿ Vehicle Data ........195 Vehicle Tools..........202 Ÿ...
Page 202: Vehicle Identification
TECHNICAL DATA Vehicle Identification Vehicle Identification Number (VIN) Vehicle Identification Tag Engine Identification Number There are 3 commonly used vehicle identification numbers on your car. Remember : Seat floor vehicle identification number The sign is a paper sign and is located on the The rubbed stamp is located on the engine passenger side car.
Page 203: Vehicle Data
TECHNICAL DATA Vehicle Data Main Engine Performance Parameters Parameter Item Unit Engine Model: LJO Engine Model: 2.0D Four-stroke, water-cooled, in-line, 16-valve, dual Four Stroke, Water Cooled, In-Line, 16 Valve, overhead camshaft, inlet VVT (inlet variable DOHC,Timing Belt Drive, Direct Injection, Engine Type camshaft phase), timing chain drive, naturally Common Rail, VGT Turbo Charger with...
Page 204 Total mass 2100 2100 2100 2140 2180 Front axle load 1050 1050 1050 1065 1120 Rear axle load 1050 1050 1050 1075 1060 *Above values may vary depending on seating capacity of the vehicle. Please contact MG Dealer for more information...
Page 205 TECHNICAL DATA Vehicle Main Size Parameters Parameter Value Project Unit N15T 6MT N15T DCT N15T 6MT BSG N15T CVT 2.0D 6MT Overall length 4 655 Total width 1 835 Total height (no load) 1 760 Wheelbase 2 750 Front overhang 950/975 Rear overhang 955/995...
Page 206 N15T 6MT N15T DCT N15T 6MT BSG N15T CVT 2.0D 6MT Maximum Speed Km/h >170 >180 Maximum climbing >30 >30 gradient *Above values may vary depending on road condition and specific country regulation. Please contact MG Dealer for more information.
Page 207 690± 20g (5 seater) / 1050± 20g (6/7 seater) Diesel Exhaust Fluid (DEF)* Standard – ISO 22241 As Required *Specification may vary depending on vehicle manufacturing date. Please contact MG Authorized Workshop for exact specification of lubes / oils / fluids in your vehicle.
Page 208 TECHNICAL DATA Tyre Inflation Pressure (Cold State) Tyre Inflation Pressure (unit: Psi) Tyre Model Project At no load At full load Front Tyre 215/60R17 Rear Tyre Front Tyre 215/55R18 Rear Tyre Wheel Alignment Parameters (No Load) Project Range (Unit: Degree) Front Wheel Camber -26’±45’...
Page 209 TECHNICAL DATA Other Parameters Project Parameters Requirement for dynamic balance of wheels Dynamic unbalance <15 g Reasonable range of brake pedal free travel <30 mm Minimum scrapping thickness of front brake disc 24mm Minimum scrapping thickness of front brake lining Minimum scrapping thickness of rear brake disc Minimum scrapping thickness of rear brake lining...
Page 210: Vehicle Tools
TECHNICAL DATA Vehicle Tools 1. Jack 2. Jack Rocker 3. Traction Hook 4. Wheel Nut Wrench 5. Sleeve...
Page 211: Delivery Of Your Vehicle
DELIVERY OF YOUR VEHICLE DELIVERY OF YOUR VEHICLE Dealer Name............Dealer Address..............FIRST NAME ........................SURNAME ......................MODEL ..................................................VEHICLE DELIVERED ON ....................... BY ................... PRESENTATION AND EXPLANATION FRONT OF THE VEHICLE DRIVING POSITION Eg. Servicing details, Checking the levels Eg.
Page 212 DELIVERY OF YOUR VEHICLE Comments: Please note that MG Motor India will not be responsible for any issues pertaining to Non Genuine Accessories fitted either by dealership or aftermarket. Should you require any further details regarding the vehicle handover or if you have any questions relating to your vehicle, please do not hesitate to contact your Sales or Delivery Advisor.
Page 213 DELIVERY OF YOUR VEHICLE DELIVERY OF YOUR VEHICLE Dealer Name............Dealer Address..............FIRST NAME ........................SURNAME ......................MODEL ..................................................VEHICLE DELIVERED ON ....................... BY ................... PRESENTATION AND EXPLANATION FRONT OF THE VEHICLE DRIVING POSITION Eg. Servicing details, Checking the levels Eg.
Page 214 DELIVERY OF YOUR VEHICLE Comments: Please note that MG Motor India will not be responsible for any issues pertaining to Non Genuine Accessories fitted either by dealership or aftermarket. Should you require any further details regarding the vehicle handover or if you have any questions relating to your vehicle, please do not hesitate to contact your Sales or Delivery Advisor.
Page 215: Mg Motor New Vehicle Warranty
Y o u r M G M O T O R v e h i c l e i s shall be covered under a Warranty by shall not be deemed to be extended by manufactured to meet the regulations MG MOTOR for a period of repairs or replacements of any parts. and environmental requirements for •...
Page 216 MG MOTOR NEW VEHICLE WARRANTY It is the authorized MG MOTOR per their warranty terms and The indirect and remote consequences Dealer's discretion to decide whether conditions. of any fault (loss of operation, duration it is appropriate to repair or replace of immobilization, etc.);...
Page 217 The warranty terms for the use of MG 2.9.3 Deposits due to atmospheric vehicle or commercial loss. Motor vehicle shall be different /...
Page 218 • Commercial Registration - Manufacturer have been carried out; subject. 5 years or 1,50,000 kms (whichever is 2.10.4 have the defect covered by the MG 2.12 By way of consideration for the parts earlier). MOTOR New Vehicle Warranty supplied by MG MOTOR under the...
Page 219 MG described in the “field of application” body of the MG Motor Vehicle in a MOTOR authorized workshop (Paragraph 7.3), shall taken into workshop outside the MG MOTOR network incorporate these tests.
Page 220 In case, the denting or painting job has with the MG MOTOR authorized The MG MOTOR Paintwork Warranty: been carried out on the MG Motor workshop carrying out the operation, Vehicle in a workshop outside the MG Duration of the Paintwork keeping the Customer informed.
Page 221 India and all disputes arising out of warranty and no Authorized Dealer this Warranty will be subject to the of MG Motor or its or his agent or jurisdiction of Courts in Gurugram employee is authorized to make any...
Page 222: Mg Roadside Assistance 24X7
Authorized MG Dealer. than your registered number, as traffic accidents do happen - our goal is to registered with MG;...
Page 223 ( n o t l e s s t h a n 1 0 0 etc.), as long as you are not already at an kilometres), and if so needed by you, MG If towing is delayed, or if the technician on spot Authorized MG Dealer.
Page 224 Sunroof cannot be closed but weather under the MG Roadside Assistance and the owner manual; conditions are fair, and the vehicle is not therefore MG Roadside Assistance will not be exposed to any security risk • Any consequential costs and / or damage responsible for any assistance costs as a result to property as a result of a breakdown;...
Page 225 / or subscribed to by the owner of the External Factors MG vehicle. • MG will take every effort to reach you Right of Refusal once you make the call however external • MG Roadside Assistance shall have the conditions (including traffic, strike etc.),...
Page 227: Service Coupon
24 x 7 pulse hub at 1800 100 6464 I confirm that the vehicle has been inspected by me and delivered to my satisfaction. I do abide by MG terms & conditions laid forward for warranty and other vehicle maintenance details.
Page 229 SERVICE COUPON 1 Free Inspection MG Motor Inspection 1 Month / 1000 km (whichever occurs earlier) - Petrol 1 Month / 1000 km (whichever occurs earlier) - Diesel 1 Free Inspection 1 Month / 1000 km (whichever occurs earlier) - Petrol...
Page 230 GENERAL STATUS REVIEW Check closing efforts of doors Central locking system Other functions UNDER HOOD Check fluid levels Engine oil level Brake oil level Coolant level Power steering oil M/T oil Windshield washer level & add washer fluid UNDERBODY, WHEELS Visually check routing, leaks &...
Page 231 SERVICE COUPON 2 Free Inspection MG Motor Inspection 6 Months / 5000 km (whichever occurs earlier) - Petrol 6 Month / 7500 km (whichever occurs earlier) - Diesel 2 Free Inspection 6 Months / 5000 km (whichever occurs earlier) - Petrol...
Page 232 Steering Wheel & Linkage Wheel Alignment Wheel Balancing (When required or as suggested by (When required or as suggested by MG Motor retailer) MG Motor retailer) Power Steering Fluid and Line Drive Shaft Boots Safety Belts, Buckles & Anchorages Lubricate Locks, Hinges & Hood Latch Tyre Condition and Inflation Pressure &...
Page 233 SERVICE COUPON 3 Free Inspection MG Motor Inspection 1 Year / 10000 km (whichever occurs earlier) - Petrol 1 Year / 15000 km (whichever occurs earlier) - Diesel 3 Free Inspection 1 Year / 10000 km (whichever occurs earlier) - Petrol...
Page 234 Steering Wheel & Linkage Wheel Alignment Wheel Balancing (When required or as suggested by (When required or as suggested by MG Motor retailer) MG Motor retailer) Power Steering Fluid and Line Drive Shaft Boots Safety Belts, Buckles & Anchorages Lubricate Locks, Hinges & Hood Latch Tyre Condition and Inflation Pressure &...
Page 235 SERVICE COUPON 4th Free Inspection MG Motor Inspection 2 Years / 20000 km (whichever occurs earlier) - Petrol 2 Years / 30000 km (whichever occurs earlier) - Diesel 4th Free Inspection 2 Years / 20000 km (whichever occurs earlier) - Petrol...
Page 236 Steering Wheel & Linkage Wheel Alignment Wheel Balancing (When required or as suggested by (When required or as suggested by MG Motor retailer) MG Motor retailer) Power Steering Fluid and Line Drive Shaft Boots Safety Belts, Buckles & Anchorages Lubricate Locks, Hinges & Hood Latch Tire Condition and Inflation Pressure &...
Page 237 SERVICE COUPON 5th Free Inspection MG Motor Inspection 3 Years / 30000 km (whichever occurs earlier) - Petrol 3 Years / 45000 km (whichever occurs earlier) - Diesel 5th Free Inspection 3 Years / 30000 km (whichever occurs earlier) - Petrol...
Page 238 Steering Wheel & Linkage Wheel Alignment Wheel Balancing (When required or as suggested by (When required or as suggested by MG Motor retailer.) MG Motor retailer.) Power Steering Fluid and Line Drive Shaft Boots Safety Belts, Buckles & Anchorages Lubricate Locks, Hinges & Hood Latch Tyre Condition and Inflation Pressure &...
Page 239: Change Of Ownership Record
CHANGE OF OWNERSHIP RECORD Change of Ownership Record Model Registration or License Number New Owner’s Name New Owner’s Address Telephone No. If resold by MG Motor Dealership Enter Dealer Stamp in Box above...
Page 240: Maintenance Interval
MAINTENANCE INTERVAL Periodic Maintenance Schedule - Petrol Manual Transmission and Hybrid Vehicles Years 1 Month 6 Months 1 Year 2 Year 3 Year 4 Year 5 Year 6 Year 7 Year 8 Year 9 Year 10 Year Replacement Operation / Processes Frequency: Km / Year for Periodic...
Page 241 MAINTENANCE INTERVAL Periodic Maintenance Schedule - Petrol Automatic Transmission Years 1 Month 6 Months 1 Year 2 Year 3 Year 4 Year 5 Year 6 Year 7 Year 8 Year 9 Year 10 Year Replacement Operation / Processes Frequency: Km / Year for Periodic whichever is Service Schedule...
Page 242 MAINTENANCE INTERVAL Periodic Maintenance Schedule - Diesel Manual Transmission Years 1 Month 6 Months 1 Year 2 Year 3 Year 4 Year 5 Year 6 Year 7 Year Operation / Processes Replacement Frequency: Km / Yr for Periodic whichever is earlier Service Schedule Engine Oil 15K/1 Year...
Page 243: Maintenance Record Sheet
MAINTENANCE RECORD SHEET MAINTENANCE RECORD SHEET (Repair Category - Free Service / Paid Service / Running Repair / Accident Repair) Repair Name of Servicing Service Repair Details of Repair Done Retailer Stamp Kms. R.O. No. Adv. Sign. Date Category Retailer...
Page 244 MAINTENANCE RECORD SHEET MAINTENANCE RECORD SHEET (Repair Category - Free Service / Paid Service / Running Repair / Accident Repair) Repair Name of Servicing Service Repair Details of Repair Done Retailer Stamp Kms. R.O. No. Adv. Sign. Date Category Retailer...
Page 245: Mg Motor India Sales And Service Network
MG MOTOR INDIA SALES AND SERVICE NETWORK ANDHRA PRADESH DELHI NCR VIJAYAWADA MG Cars Pvt. Ltd. Priority Auto Lincs Pvt. Ltd. Sri Jayalakshmi Automotives Pvt. Ltd. 1S Plot No 13, Shivaji Marg, New Delhi - 110015 1S Survey No.166/1, New Taleigao Bypass Road,...
Page 246 MG MOTOR INDIA SALES AND SERVICE NETWORK JHARKHAND SURAT RANCHI 2S MVIT Workshop - Survey No. 32/33, Nanavati Autosquare Pvt. Ltd. Singhania Future Pvt. Ltd. Nellakunte Village, Jala Hobli, Yelahanka 1S Ground Floor, Icon Business Centre, 1S Near Firayalals Pulsar Plaza, Line Tank Road,...
Page 247 MG MOTOR INDIA SALES AND SERVICE NETWORK MADHYA PRADESH BHOPAL EC Old Mahindra Showroom, Next to AutoBahn NAGPUR Hriday Cars Pvt. Ltd. VW Showroom Nangia Automotive Pvt. Ltd. 1S Khasra No. 59, P.H.No-20, Ward No-54, 3S Plot No B-33-1/4, Ring Road, MIDC, Nagpur...
Page 248 MG MOTOR INDIA SALES AND SERVICE NETWORK RAJASTHAN TELANGANA JAIPUR HYDERABAD LUCKNOW GPS Automobiles Pvt. Ltd. RAAM4WHEELERS LLP Beeaar Autowheels India Pvt. Ltd. 1S Plot No. 2&3/4, Choudhary Charan Singh 1S 8-2-120/86/10, 10A, 11B, 11C and 11D, 3S Milestone No. 111, Faizabad Road, Chinhat, Colony, Tonk Road, Jaipur - 302029 Opp.
Page 249 VEHICLE RECORD SHEET MODEL CHASSIS NO. ENGINE NO. KEY NO. DATE OF DELIVERY MILEAGE (KM) MAKE SR NO./ BATCH CODE BATTERY TYRE TYRE LOCATION FR RH FR LH RR RH RR LH MAKE BATCH NUMBER OWNER'S NAME & ADDRESS: ADDRESS OF SELLING DEALER Showroom: Workshop: For any feedback, please call Toll free No.
Page 250 1800 100 6464 MG Motor India Pvt. Ltd. All information, illustrations and specifications contained in this Owner's Manual are based on the latest production information available at the time of publication. The right is reserved to make changes at any time without notice.

This manual is also suitable for:

Hector plus

MG Hector Owner's Manual

Quick Links

Related Manuals for MG Hector

Summary of Contents for MG Hector
