Hartzell HC-82XF-1 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FAA Approved
Manual No. 175
61-00-75
Revision 1
June 2011
Propeller Owner's Manual
Steel Hub Reciprocating Propellers with Aluminum Blades
Two Blade
HC-82(X,V)(F,K,L)-1( )( )
HC-82(X,V)(F,K,L)-2( )( )
HC-82(X,V)(F,L)-6( )( )( )
WARNING 1:
WARNING 2:
WARNING 3:
WARNING 4:
Hartzell Propeller Inc.
One Propeller Place
Piqua, OH 45356 - 2634 U.S.A.
Ph: 937-778-4200 (Hartzell Propeller Inc.)
Ph: 937-778-4379 (Product Support)
Product Support Fax: 937-778-4391
and Logbook
THESE PROPELLER MODELS ARE OBSOLETE.
THIS MANUAL IS NOT MAINTAINED BY HARTZELL
PROPELLER INC. THE FAA REQUIRES THAT THIS
DOCUMENT CONTINUE TO BE MADE AVAILABLE.
REFER TO HARTZELL PROPELLER INC. SERVICE
BULLETIN HC-SB-61-331 FOR INFORMATION
ABOUT PROPELLER MODEL UPGRADE FROM "1"
OR "8" STYLE HUBS TO "D" OR "A" STYLE HUBS.
HARTZELL PROPELLER INC. COMMERCIAL
SUPPORT FOR THE PROPELLER MODELS
CONTAINED IN THIS MANUAL IS NOT AVAILABLE.
USE OF OBSOLETE MAINTENANCE
INFORMATION OR PARTS THAT HAVE UNKNOWN
HISTORIES IS NOT APPROVED BY HARTZELL
PROPELLER INC. AND MAY CREATE AN UNSAFE
CONDITION THAT COULD RESULT IN DEATH,
SERIOUS BODILY INJURY, AND/OR SUBSTANTIAL
PROPERTY DAMAGE.
Three Blade
HC-83(X,V)20-1( )( )( )
HC-83(X,V)20-2( )( )
HC-83(X,V)F-2( )( )
HC-83(X,V)F-3( )( )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC-82XF-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Hartzell HC-82XF-1

Summary of Contents for Hartzell HC-82XF-1

  • Page 1 HC-82(X,V)(F,L)-6( )( )( ) HC-83(X,V)F-3( )( ) WARNING 1: THESE PROPELLER MODELS ARE OBSOLETE. THIS MANUAL IS NOT MAINTAINED BY HARTZELL PROPELLER INC. THE FAA REQUIRES THAT THIS DOCUMENT CONTINUE TO BE MADE AVAILABLE. WARNING 2: REFER TO HARTZELL PROPELLER INC. SERVICE BULLETIN HC-SB-61-331 FOR INFORMATION ABOUT PROPELLER MODEL UPGRADE FROM “1”...
  • Page 2 Propeller Owner's Manual © 2005, 2011 - Hartzell Propeller Inc. - All rights reserved Inside Cover 61-00-75 Rev. 1, Jun/11...
  • Page 3 Manual. Please give it your attention, especially the section dealing with Inspections and Checks. Thank you for choosing a Hartzell propeller. Properly maintained it will give you many years of reliable service. Jim Brown Chairman, Hartzell Propeller Inc.
  • Page 4 Propeller Owner's Manual WARNING People who fly should recognize that various types of risks are involved; and they should take all precautions to minimize them, since they cannot be eliminated entirely. The propeller is a vital component of the aircraft. A mechanical failure of the propeller could cause a forced landing or create vibrations sufficiently severe to damage the aircraft, possibly causing it to become uncontrollable.
  • Page 5 Failure could be as severe as loss of propeller or propeller blades and cause loss of propeller control and/or loss of aircraft control. Hartzell Propeller Inc. follows FAA regulations for propeller certification on certificated aircraft. Experimental aircraft may operate with unapproved engines or propellers or...
  • Page 6 Propeller Owner's Manual (This page is intentionally blank.) Page 4 61-00-75 MESSAGE Dec/05...
  • Page 7 • Revised information about ice-protection systems • Updated Reference Publications section • Added information about Hartzell Recommended Facilities • Installation and Removal Chapter • Revised references about ice protection systems • Clarified use of aviation grade reciprocating engine oil for lubrication of felt dust seal •...
  • Page 8 Propeller Owner's Manual REVISIONS HIGHLIGHTS 1. Introduction A. General This is a list of current revisions that have been issued against this manual. Please compare it to the RECORD OF REVISIONS page to ensure that all revisions have been added to the manual. B.
  • Page 9 Propeller Owner's Manual Revision No. Issue Date Comments Original Dec/05 New Issue Revision 1 Jun/11 Minor Revision Page 7 61-00-75 Rev. 1 Jun/11 REVISION HIGHLIGHTS...
  • Page 10 Propeller Owner's Manual (This page is intentionally blank.) Page 8 61-00-75 REVISION HIGHLIGHTS Rev. 1 Jun/11...
  • Page 11 Propeller Owner's Manual RECORD OF REVISIONS Rev. No. Issue Date Date Inserted Inserted By Rev. 1 Jun/11 Jun/11 Page 9 61-00-75 RECORD OF REVISIONS Dec/05...
  • Page 12 Propeller Owner's Manual RECORD OF REVISIONS Rev. No. Issue Date Date Inserted Inserted By Page 10 61-00-75 RECORD OF REVISIONS Dec/05...
  • Page 13 Propeller Owner's Manual RECORD OF TEMPORARY REVISIONS Issue Date Inserted Date Removed Date Inserted Removed Page 11 61-00-75 RECORD OF TEMPORARY REVISIONS Dec/05...
  • Page 14 Propeller Owner's Manual RECORD OF TEMPORARY REVISIONS Issue Date Inserted Date Removed Date Inserted Removed Page 12 61-00-75 Dec/05 RECORD OF TEMPORARY REVISIONS...
  • Page 15 Propeller Owner's Manual SERVICE DOCUMENTS LIST CAUTION 1: DO NOT USE OBSOLETE OR OUTDATED INFORMATION. PERFORM ALL INSPECTIONS OR WORK IN ACCORDANCE WITH THE MOST RECENT REVISION OF A SERVICE DOCUMENT. INFORMATION CONTAINED IN A SERVICE DOCUMENT MAY BE SIGNIFICANTLY CHANGED FROM EARLIER REVISIONS.
  • Page 16 Propeller Owner's Manual SERVICE DOCUMENTS LIST Service Document Number Incorporation Rev/Date Page 14 61-00-75 SERVICE DOCUMENTS LIST Rev 1 Jun/11...
  • Page 17 Propeller Owner's Manual AIRWORTHINESS LIMITATIONS The Airworthiness Limitations section is FAA approved and specifies maintenance required under 14 CFR §§ 43.16 and 91.403 of the Federal Aviation Regulations unless an alternative program has been FAA approved. FAA APPROVED by: ______________________________ date: ____________ Manager, Chicago Aircraft Certification Office, ACE-115C...
  • Page 18 2. The following data summarizes all current information concerning Hartzell life limited parts as related to propeller models affected by this manual. These parts are not life limited on other installations; however, time accumulated toward life limit accrues...
  • Page 19 Propeller Owner's Manual LIST OF EFFECTIVE PAGES Chapter Page Revision Date Cover Cover and Inside Cover Rev. 1 Jun/11 Message 1 thru 4 Original Dec/05 Revision Highlights Rev. 1 Jun/11 Revision Highlights Original Dec/05 Revision Highlights 7 and Rev. 1 Jun/11 Record of Revisions 9 and 10...
  • Page 20 Propeller Owner's Manual LIST OF EFFECTIVE PAGES Chapter Page Revision Date Inspection and Check and 5-2 Original Dec/05 Inspection and Check 5-3 and 5-4 Rev. 1 Jun/11 Inspection and Check Original Dec/05 Inspection and Check Rev. 1 Jun/11 Inspection and Check 5-7 thru 5-12 Original Dec/05...

  • Page 21: Table Of Contents

    8. Abbreviations ................ 1-13 9. Hartzell Product Support ............1-14 10.Warranty Service ..............1-14 11. Hartzell Recommended Facilities ......... 1-15 DESCRIPTION AND OPERATION ..........2-1 1. Description of Propeller and Systems ........2-3 A. Constant Speed, Counterweighted, Nonfeathering Propellers ..........2-9...
  • Page 22 3. Governors ................2-29 A. Theory of Operation ............2-29 B. Governor Types ............... 2-32 C. Identification of Hartzell Governors ........2-32 4. Propeller Anti-Ice and De-Ice Systems ........ 2-33 A. Propeller Anti-Ice System ..........2-33 B. Propeller De-Ice System ..........2-34 INSTALLATION AND REMOVAL ..........
  • Page 23 Propeller Owner's Manual TABLE OF CONTENTS Page C. Installing F Flange Propeller Models HC-82(X,V)F-1( )( )( ) and HC-82XF-6( )( )( ) ....3-15 D. Installing K and L Flange Propeller Models HC-82(X,V)(K,L)-1( )( ) and HC-82VL-6( )( ) ....3-23 E.
  • Page 24 Propeller Owner's Manual TABLE OF CONTENTS Page TESTING AND TROUBLESHOOTING ........4-1 1. Operational Tests ..............4-3 A. Initial Run-Up ..............4-3 B. Static RPM Check .............. 4-3 C. Post-Run Check ..............Propeller Ice Protection Systems ........... 4-4 A. Electric De-Ice System ............4-4 B.
  • Page 25 Propeller Owner's Manual TABLE OF CONTENTS Page 3. Required Periodic Inspections and Maintenance ....5-5 A. Periodic Inspection ............. 5-5 B. Periodic Maintenance ............5-6 C. Airworthiness Limitations ........... 5-6 D. Overhaul Periods ............... 5-6 4. Inspection Procedures ............5-7 A.
  • Page 26 Propeller Owner's Manual TABLE OF CONTENTS Page 3 Blade Repairs ............... 6-10 A. Repair of Nicks or Gouges ..........6-10 B. Repair of Bent Blades ............6-12 4. Painting After Repair ............. 6-13 A. General ................6-13 B. Painting of Aluminum Blades ........... 6-14 5.
  • Page 27 Propeller Owner's Manual TABLE OF CONTENTS Page ANTI-ICE AND DE-ICE SYSTEMS ..........7-1 1. Introduction ................7-3 A. Propeller De-ice System ............ 7-3 B. Propeller Anti-ice System ........... 7-3 2. System Description ..............7-4 A. De-ice System ..............7-4 B. Anti-ice System ..............7-5 3.
  • Page 28 Propeller Owner's Manual LIST OF FIGURES Page Steel Hub Unit (For Splined Shaft Mounting)..........Figure 2-1 ....2-3 Spline Shaft Attachment ......Figure 2-2 ....2-4 Flanged Attachment........ Figure 2-3 ....2-5 Constant Speed, Counterweighted, Nonfeathering Propeller Assembly ..Figure 2-4 ....

  • Page 29: Assembly

    Propeller Owner's Manual LIST OF FIGURES Page Determining Torque Value When Using Torquing Adapter ........Figure 3-4 ....3-17 K and L Flange Installations on -1( ), and -6( ) Propeller Models ...... Figure 3-5 ....3-22 Installing K or L Flange Propeller on the Engine Flange ........
  • Page 30 Propeller Owner's Manual LIST OF FIGURES Page Checking Blade Track......Figure 5-1 ....5-12 Blade Play ..........Figure 5-2 ....5-12 Reciprocating Engine Overspeed Limits Figure 5-3 ....5-15 Lubrication Fitting ........Figure 6-1 ....6-4 Lubrication Label ........Figure 6-2 ....
  • Page 31 Personnel Requirements ........... 1-5 Maintenance Practices ............1-5 Continued Airworthiness ............ 1-7 Reference Publications ............Definitions ................Abbreviations ................ 1-13 Hartzell Product Support ............1-14 10.Warranty Service ..............1-14 Hartzell Recommended Facilities ......... 1-15 Page 1-1 61-00-75 INTRODUCTION Rev. 1 Jun/11...
  • Page 32 Propeller Owner’s Manual (This page is intentionally blank.) Page 1-2 61-00-75 INTRODUCTION Rev. 1 Jun/11...

  • Page 33: Airworthiness Limitations

    All propeller models included in this manual use NOTE: aluminum propeller blades. B. The purpose of this manual is to enable qualified personnel to install, operate, and maintain a Hartzell propeller. Separate manuals are available concerning overhaul procedures and specifications for the propeller. This manual includes several design types.

  • Page 34: Airframe Or Engine Modifications

    Propeller Owner’s Manual 3. Airframe or Engine Modifications A. Propellers are approved vibrationwise on airframe and engine combinations based on tests or analysis of similar installations. This data has demonstrated that propeller stress levels are affected by airframe configuration, airspeed, weight, power, engine configuration and flight maneuvers.

  • Page 35: Restrictions And Placards

    Propeller Owner’s Manual 4. Restrictions and Placards The propellers covered by this manual may have a restricted operating range that requires a cockpit placard. The restrictions, if present, will vary depending on the propeller, blade, engine, and/or aircraft model. Review the propeller and aircraft type certificate data sheet (TCDS), Pilot Operating Handbook (POH), and any applicable Airworthiness Directives for specific information.
  • Page 36 If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications that are available on the Hartzell web site at www.hartzellprop.com:...
  • Page 37 Propeller Owner’s Manual (11) Propeller ice protection system components not supplied by Hartzell Propeller Inc. are controlled by the applicable TC or STC holder’s Instructions for Continued Airworthiness (ICA). CAUTION: DO NOT USE OBSOLETE OR OUTDATED INFORMATION. PERFORM ALL INSPECTIONS OR WORK IN ACCORDANCE WITH THE MOST RECENT REVISION OF THIS MANUAL.
  • Page 38 Hartzell Manual No. 165A (61-00-65) - Illustrated Tool and Equipment Manual. Hartzell Manual No. 180 (30-61-80) - Propeller Ice Protection System Manual (Also available on the Hartzell web site at www.hartzellprop.com.) Hartzell Manual No. 181 (30-60-81) - Propeller Ice Protection Component Maintenance Manual (Also available on the Hartzell web site at www.hartzellprop.com.)

  • Page 39: Definitions

    Propeller Owner’s Manual 7. Definitions A basic understanding of the following terms will assist in maintaining and operating Hartzell propeller systems. Term Definition Annealed ... Softening of material due to overexposure to heat Blade Angle .
  • Page 40 Propeller Owner’s Manual Term Definition Erosion ... . . Gradual wearing away or deterioration due to action of the elements Exposure ... Leaving material open to action of the elements Feathering .
  • Page 41 Propeller Owner’s Manual Term Definition Overspeed Damage . . . Damage that occurs when the propeller hub assembly rotates at a speed greater than the maximum limit for which it is designed Pitch ....Same as “Blade Angle” Pitting .
  • Page 42 Propeller Owner’s Manual Term Definition Underspeed ..The condition in which the actual engine (propeller) RPM is lower than the RPM selected by the pilot through the propeller control lever Variable Force ..A force that may be applied or removed during propeller operation Vertical Balance .

  • Page 43: Abbreviations

    Propeller Owner’s Manual 8. Abbreviations Abbreviation Term AMM ....Aircraft Maintenance Manual AN ....Air Force-Navy (or Army-Navy) AOG .

  • Page 44: Hartzell Product Support

    5:00 p.m., United States Eastern Time) at (937) 778-4379 or at (800) 942-7767, toll free from the United States and Canada. Hartzell Product Support can also be reached by fax at (937) 778-4391, and by e-mail at techsupport@hartzellprop.com. After business hours, you may leave a message on our 24 hour product support line at (937) 778-4376 or at (800) 942-7767, toll free from the United States and Canada.

  • Page 45: Hartzell Recommended Facilities

    Propeller Owner’s Manual 11. Hartzell Recommended Facilities A. Hartzell Propeller Inc. recommends using Hartzell approved distributors and service facilities for the purchase, repair and overhaul of Hartzell propeller assemblies or components. B. Information about the Hartzell worldwide network of aftermarket distributors and approved service facilities is available on the Hartzell web site at www.hartzellprop.com.
  • Page 46 Propeller Owner’s Manual (This page is intentionally blank.) Page 1-16 61-00-75 INTRODUCTION Rev. 1 Jun/11...
  • Page 47 “X” to “V” Shank Hub Modification ........2-26 Governors ................2-29 Theory of Operation ............2-29 Governor Types ............... 2-32 Identification of Hartzell Governors ........2-32 Propeller Anti-Ice and De-Ice Systems ........ 2-33 Propeller Anti-Ice System ..........2-33 Propeller De-Ice System ..........2-34...
  • Page 48 Propeller Owner's Manual FIGURES Page Steel Hub Unit (For Splined Shaft Mounting)..........Figure 2-1 ....2-3 Spline Shaft Attachment ......Figure 2-2 ....2-4 Flanged Attachment........ Figure 2-3 ....2-5 Constant Speed, Counterweighted, Nonfeathering Propeller Assembly ..Figure 2-4 ....2-7 Constant Speed, Counterweighted, Nonfeathering Propeller Assembly ..

  • Page 49: Description Of Propeller And Systems

    Propeller Owner's Manual 1. Description of Propeller and Systems Hartzell steel hub propellers covered in this manual are constant speed assemblies that use a steel hub as a central component (Figure 2-1). The propeller attaches to the engine through either a splined shaft or one of several flanged designs.
  • Page 50 Propeller Owner's Manual Page 2-4 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 51 Propeller Owner's Manual Page 2-5 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 52 Propeller Owner's Manual (This page is intentionally blank.) Page 2-6 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 53 Propeller Owner's Manual Page 2-7 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 54 Propeller Owner's Manual Page 2-8 61-00-75 DESCRIPTION AND OPERATION Dec/05...

  • Page 55: Constant Speed Counterweighted, Nonfeathering Propellers

    Propeller Owner's Manual A. Constant Speed, Counterweighted, Nonfeathering Propellers Propeller models HC-82(X,V)(F,K,L)-1( )( ) and HC-83(X,V)20-1( )( ). Refer to Figure 2-6. Constant speed counterweighted, nonfeathering propellers are typically used on single engine aircraft. Propeller blade angle change is actuated by a hydraulic piston/cylinder combination mounted on the forward end of the propeller hub.
  • Page 56 Propeller Owner's Manual A governor is an engine speed-sensing device that maintains a constant engine/propeller RPM by changing blade angle and varying load on the engine. The governor uses an internal pump that is driven by an accessory drive from the engine. This pump uses engine lubricating oil and increases the engine oil pressure for supply to the propeller.
  • Page 57 Propeller Owner's Manual (This page is intentionally blank.) Page 2-11 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 58 Propeller Owner's Manual Page 2-12 61-00-75 DESCRIPTION AND OPERATION Dec/05...

  • Page 59: Constant Speed, Non-Counterweighted, Nonfeathering Propellers

    Propeller Owner's Manual B. Constant Speed, Non-counterweighted, Nonfeathering Propellers Propeller models HC-82(X,V)(F,L)-6( )( ). Refer to Figure 2-6. Constant speed, non-counterweighted, nonfeathering propellers are typically used on single engine aircraft. Propeller blade angle change is actuated by a hydraulic piston/cylinder combination mounted on the forward end of the propeller hub.
  • Page 60 Propeller Owner's Manual The governor uses an internal pump that is driven by an accessory drive from the engine. This pump uses an engine oil supply and increases the engine oil pressure for supply to the propeller. Engine speed sensing hardware within the governor controls the supply of oil to, or drain of oil from the propeller, resulting in a change of blade pitch to maintain constant engine speed.
  • Page 61 Propeller Owner's Manual Page 2-15 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 62 Propeller Owner's Manual Page 2-16 61-00-75 DESCRIPTION AND OPERATION Dec/05...

  • Page 63: Constant Speed And Feathering Propellers

    Propeller Owner's Manual C. Constant Speed and Feathering Propellers Propeller models HC-82(X,V)(F,K,L)-2( )( ), HC-83(X,V)F-2( )( ) and HC-83(X,V)20-2( )( ). Refer to Figures 2-7 and 2-8. A constant speed and feathering propeller is typically used on a twin engine aircraft. It is counterweighted, and is controlled by an engine speed-sensing device (governor) to maintain a constant engine/propeller RPM by changing blade angle and varying load on the engine.
  • Page 64 Propeller Owner's Manual Oil is metered by the governor to oppose these constant forces and maintain a constant engine RPM. The forces of the installed spring and counterweight attempt to rotate the blades to a higher blade angle. A governor is an engine speed-sensing device that maintains a constant engine/propeller RPM by changing blade angle and varying load on the engine.
  • Page 65 Propeller Owner's Manual It is undesirable to feather the propeller when the engine is stopped after landing. To prevent feathering during normal engine shut down, the propeller incorporates spring energized latches (start locks). If the propeller rotation is approximately 800 RPM or above, the latches are disengaged by centrifugal force acting on the latch weights to compress the springs.
  • Page 66 Propeller Owner's Manual Page 2-20 61-00-75 DESCRIPTION AND OPERATION Dec/05...

  • Page 67: (Internal Beta System)

    Propeller Owner's Manual D. Constant Speed, Feathering and Reversing Propellers (Internal Beta System) Propeller models HC-83(X,V)F-3( )( ) Refer to Figure 2-9. A constant speed, feathering and reversing propeller is typically used on a twin engine aircraft. It is counterweighted and uses internal and external reversing control hardware.

  • Page 68: Reversing System

    Propeller Owner's Manual The governor uses an internal pump that is driven by an accessory drive from the engine. This pump uses an engine oil supply and increases the engine oil pressure for supply to the propeller. Engine speed sensing hardware within the governor controls the supply of oil to, or drain of oil from the propeller, resulting in a change of blade pitch to maintain constant engine speed.
  • Page 69 Propeller Owner's Manual The lowest blade angle attainable by the governor is low pitch. An external valve and internal valve hydraulically control the low pitch stop and the blade angles between low pitch and reverse. Beta refers to the blade angle range between low pitch and full reverse blade angles.

  • Page 70: Model Designation

    Propeller Owner's Manual 2. Model Designation The following pages illustrate sample model designations for Hartzell steel hub reciprocating propeller hub assemblies and blades. A. Steel Hub Propeller Model Identification The propeller model number is impression stamped on the propeller hub.

  • Page 71: Aluminum Blade Model Identification

    Propeller Owner's Manual B. Aluminum Blade Model Identification Hartzell uses a model designation to identify specific blade assemblies. Example: HC-82VK-1D/V8433-7. A slash mark separates the propeller and blade model designations. The blade model designation is impression stamped on the blade butt end (internal) and is either on a decal or ink stamped on the blade camber side (external).

  • Page 72: X" To "V" Shank Hub Modification

    C. “X” to “V” Shank Hub Modification (1) In addition to inspection/rework requirements stated in Hartzell Standard Practices Manual 202A (61-01-02), all “X” shank hubs must be modified to a “V” shank hub. This modification includes replacing the pilot tubes and modifying the blades from an “X”...
  • Page 73 Propeller Owner's Manual (This page is intentionally blank.) Page 2-27 61-00-75 DESCRIPTION AND OPERATION Dec/05...

  • Page 74: Governor In Onspeed Condition

    Propeller Owner's Manual APS6149 Pilot Control Speeder Spring Flyweights Pilot Valve Governor in Onspeed Condition Figure 2-11 APS6150 Pilot Control Speeder Spring Flyweights Pilot Valve Governor in Underspeed Condition Figure 2-12 Pilot Control APS6151 Speeder Spring Flyweights Pilot Valve Governor in Overspeed Condition Figure 2-13 Page 2-28 61-00-75...
  • Page 75 Propeller Owner's Manual 3. Governors A. Theory of Operation (1) A governor is an engine RPM sensing device and high pressure oil pump. In a constant speed propeller system, the governor responds to a change in engine RPM by directing oil under pressure to the propeller hydraulic cylinder or by releasing oil from the hydraulic cylinder.

  • Page 76: Feathering Governor

    Propeller Owner's Manual APS6152 Pilot Control Lift Rod Speeder Spring Flyweights Pilot Valve Feathering Governor Figure 2-14 APS6153 Pilot Control Coil Speeder Spring Flyweights Pilot Valve Synchronizer/Synchrophaser Governor Figure 2-15 Page 2-30 61-00-75 DESCRIPTION AND OPERATION Dec/05...
  • Page 77 Both synchronizing and synchrophasing systems serve to reduce noise and vibration. (7) A Hartzell synchronizing or synchrophasing system uses one engine (the master engine) as an RPM and phase reference and adjusts the RPM of the remaining engine(s) (slave engine[s]) to match it.
  • Page 78 Propeller Owner's Manual B. Governor Types The governors used in Hartzell Constant Speed propeller systems are supplied either by Hartzell or other manufacturers. These governor types function in a similar manner. C. Identification of Hartzell Governors Hartzell governor may be identified by model number as...
  • Page 79 Propeller Owner's Manual 4. Propeller Anti-Ice and De-Ice Systems Some Hartzell propellers may be equipped with an anti-ice or de-ice system. A short description of each of these systems follows: A. Propeller Anti-Ice System A propeller anti-ice system prevents ice from forming on propeller surfaces.
  • Page 80 Propeller Owner's Manual B. Propeller De-Ice System A propeller de-ice system is a system that permits ice to form, and then removes it by electrically heating the de-ice boots. The ice partially melts and is thrown from the blade by centrifugal force.
  • Page 81 Propeller Owner’s Manual CONTENTS Page Tools, Consumables, and Expendables ......... 3-5 Tooling ................3-5 Consumables ..............3-6 Expendables ..............3-6 O-ring and Propeller Mounting Hardware Identification ..3-7 Pre-Installation ..............3-11 Inspection of Shipping Package ........3-11 Uncrating ................3-11 Inspection after Shipment ..........

  • Page 82: X,V)(F,K,L)-1( )( )( )

    Propeller Owner’s Manual CONTENTS Page Propeller Assembly Removal ..........3-74 Removing the F Flange Propeller Models HC-82(X,V)F-1( )( )( ) and HC-82XF-6( )( )( ) ....3-74 Removing the K and L Flange Propeller Models HC-82(X,V)(K,L)-1( )( ) and HC-82VL-6( )( ) ....
  • Page 83 Propeller Owner’s Manual FIGURES Page F Flange Installation on -2 Propeller Models ............ Figure 3-8 ....3-30 K and L Flange Installation on -2 Propeller Models........Figure 3-9 ....3-36 HC-83(X,V)F-2( )( ) Propeller Assembly . Figure 3-10 ....3-44 HC-83(X,V)F-3( )( ) Propeller Assembly .
  • Page 84 Propeller Owner’s Manual (This page is intentionally blank.) Page 3-4 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...

  • Page 85: Tools, Consumables, And Expendables

    AST-2805, or a locally procured torque wrench adapter of the appropriate size K Flange • Safety wire pliers • Calibrated torque wrench • Torque wrench adapter, Hartzell P/N AST-2805 or a locally procured torque wrench adapter of the appropriate size L Flange • Safety wire pliers •...

  • Page 86: Consumables

    Propeller Owner’s Manual B. Consumables • Quick Dry Stoddard Solvent or Methyl-Ethyl-Ketone (MEK) C. Expendables • 0.032 inch (0.81 mm) stainless steel aircraft safety wire • O-rings (see Table 3-1) Page 3-6 61-00-75 INSTALLATION AND REMOVAL Dec/05...
  • Page 87 Propeller Owner’s Manual 2. O-ring and Propeller Mounting Hardware Identification Part Propeller Model Part No. Cone, Rear HC-83(X,V)20-1(B,C,E)(1) A-50-3 HC-83(X,V)20-1(B,C,E)(1) A-50-3 HC-83(X,V)20-2( )( ) A-50-3 Dowel Pin HC-82(X,V)F-2(B,C)(1) B-6138-8-8 HC-82(X,V)F-1( )( )( ) B-6138-8-8 HC-82(X,V)F-6( )( )( ) B-6138-8-8 HC-83(X,V)F-2( )( ) B-6138-8-8 HC-83(X,V)F-3( )( ) B-6138-8-8...
  • Page 88 Propeller Owner’s Manual Part Propeller Model Part No. Nut, Piston Rod HC-83(X,V)F-2( )( ) B-3368 HC-83(X,V)F-3( )( ) B-3368 HC-83(X,V)20-2( )( ) B-3368 Nut, Fork Rod (HC-83X20-1( )( ) A-848-2 HC-82(X,V)(F,L,K)-1( )( )( ) A-848-2 HC-82(X,V)(F,L)-6( )( )( ) A-848-2 Nut, Piston HC-83(X,V)F-2A( ) A-880-2...
  • Page 89 Propeller Owner’s Manual Part Propeller Model Part No. O-ring, Rear Cone HC-83X20-1( )( ) C-3317-228 HC-83(X,V)20-2( )( ) C-3317-229 O-ring, Cylinder HC-83X20-1( )( ) C-3317-229 HC-83(X,V)20-2( )( ) C-3317-229 Pitch Change Block HC-83(X,V)20-1( )( ) A-95-A HC-82(X,V)(F,K,L)-1(D,F,L)( ) A-95-A HC-82XF-1C A-95 Safety Pin, Hub Nut HC-83(X,V)20-1(B,C,E)(1)

  • Page 90: O-Ring And Propeller Mounting Hardware Identification

    Propeller Owner’s Manual Part Propeller Model Part No. Washer, (Mounting Bolt/Stud) HC-82(X,V)F-1( )( )( ) A-1381 HC-82(X,V)F-6( )( )( ) A-1381 HC-82(X,V)F-2( )( ) B-6527-7 HC-82(X,V)L-2C(1) B-6527-7 B-6329-7 HC-82(X,V)L-2B(1) B-6527-7 HC-83(X,V)F-2( )( ) B-3851-0863 HC-83(X,V)F-3( )( ) A-1381 O-ring and Propeller Mounting Hardware Identification Table 3-1, Continued Page 3-10 61-00-75...

  • Page 91: Pre-Installation

    Propeller Owner’s Manual 3. Pre-Installation A. Inspection of Shipping Package Examine the exterior of the shipping container, especially the box ends around each blade, for signs of shipping damage. A hole, tear, or crushed appearance at the end of the box (blade tips) may indicate that the propeller was dropped during shipment, possibly damaging the blades.

  • Page 92: Propeller Assembly Installation

    Hartzell’s control. In addition to propeller installation procedures, items such as rigging and preflight testing of flight idle blade...
  • Page 93 Propeller Owner’s Manual Page 3-13 61-00-75 INSTALLATION AND REMOVAL Dec/05...
  • Page 94 Propeller Owner’s Manual D-985 Mounting Bolt Washer Mounting Bolt Propeller Flange Engine Flange Shaft O-ring F Flange Installation on -1( )( ) Propeller Models Figure 3-2 Page 3-14 61-00-75 INSTALLATION AND REMOVAL Dec/05...

  • Page 95: X,V)F-1( )( )( ) And Hc-82Xf-6( )( )( )

    Propeller Owner’s Manual C. Installing F Flange Propeller Models HC-82(X,V)F-1( )( )( ) and HC-82XF-6( )( )( ) Refer to Figure 3-1 INSERT THE DOWEL PINS INTO CAUTION: THE PROPELLER FLANGE USING A BRASS HAMMER OR EQUIVALENT TOOL TO PREVENT DAMAGE TO THE DOWEL PINS.
  • Page 96 Propeller Owner’s Manual D-2999F TORQUE Dowel Pin Shaft/Engine Flange O-ring Propeller Flange Engine Flange Mounting Bolt Washer Mounting Bolt Torque Wrench Adapter Torque Wrench If torque wrench adapter is used, use the calculation in Figure 3-4 to NOTE: determine correct torque wrench setting. Installing F Flange Propeller on the Engine Flange Figure 3-3 Page 3-16...
  • Page 97 Propeller Owner’s Manual MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING INSTALLATION. WHEN INSTALLING THE PROPELLER CAUTION: ON THE AIRCRAFT, DO NOT DAMAGE THE ICE PROTECTION SYSTEM COMPONENTS, IF APPLICABLE.
  • Page 98 Propeller Owner’s Manual F Flange propeller mounting bolts A-1333-( ) 80-90 Ft-Lb (108-122 N•m) A-1328-( ) 80-90 Ft-Lb (108-122 N•m) K Flange propeller mounting bolts A-1333-( ) 60-70 Ft-Lb (81-95 N•m) A-1333-( ) & A-1328 60-70 Ft-Lb (81-95 N•m) A-1333-( ) & A-1315 60-70 Ft-Lb (81-95 N•m) L Flange propeller mounting bolts...
  • Page 99 Propeller Owner’s Manual CLEANING AGENT MEK IS FLAMMABLE WARNING: AND TOXIC TO THE SKIN, EYES AND RESPIRATORY TRACT. SKIN AND EYE PROTECTION ARE REQUIRED. AVOID PROLONGED CONTACT. USE IN A WELL VENTILATED AREA. USE CARE TO AVOID SCRAPING CAUTION: ALUMINUM FROM THE BORE OF THE SPINNER BULKHEAD.
  • Page 100 (14) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 101 Propeller Owner’s Manual (16) Install the spinner dome as follows: The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation instructions.
  • Page 102 Propeller Owner’s Manual D-1334 Dowel Pin Engine Flange Shaft O-ring Shim Mounting Bolt Starter Ring Gear Adapter Ring K and L Flange Installations on -1( ), and -6( ) Propeller Models Figure 3-5 Page 3-22 61-00-75 INSTALLATION AND REMOVAL Dec/05...

  • Page 103: X,V)(K,L)-1( )( ) And Hc-82Vl-6( )( )

    Propeller Owner’s Manual D. Installing K and L Flange Propeller Models HC-82(X,V)(K,L)-1( )( ) and HC-82VL-6( )( ) Refer to Figure 3-1. MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING INSTALLATION.
  • Page 104 Propeller Owner’s Manual (6) Align the four mounting bolts (already installed in the propeller hub flange) with the threaded bushings in the engine flange. Four of the propeller mounting bolts will NOTE: already be installed in the propeller flange. Interference with other propeller parts requires that the bolts be installed during propeller assembly.
  • Page 105 Propeller Owner’s Manual MAKE SURE THAT COMPLETE CAUTION: AND TRUE SURFACE CONTACT IS ESTABLISHED BETWEEN THE PROPELLER HUB FLANGE AND THE ENGINE FLANGE. (7) Slide the propeller flange onto the engine flange, against the starter ring gear and shim. Insert the engine bushings into the NOTE: counterbores that encircle the propeller mounting bolts in the propeller flange.
  • Page 106 (d) Manual 183 (61-12-83) - Propeller Anti-icing Boot Removal and Installation Manual (13) Propeller ice protection system components not supplied by Hartzell Propeller Inc. are controlled by the applicable TC or STC holder’s Instructions for Continued Airworthiness (ICA). Page 3-26...
  • Page 107 Propeller Owner’s Manual (14) Install the spinner dome as follows: The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation instructions.
  • Page 108 Propeller Owner’s Manual D-1495 Page 3-28 61-00-75 INSTALLATION AND REMOVAL Dec/05...

  • Page 109: Installing F Flange Propeller Models Hc-82(X,V)F-2( )( )

    Propeller Owner’s Manual E. Installing F Flange Propeller Models HC-82(X,V)F-2( )( ) Refer to Figures 3-7. INSERT THE DOWEL PINS INTO CAUTION: THE PROPELLER FLANGE USING A BRASS HAMMER OR EQUIVALENT TOOL TO PREVENT DAMAGE TO THE DOWEL PINS. THE DOWEL PINS ARE AN INTERFERENCE FIT WITH THE PROPELLER FLANGE.
  • Page 110 Propeller Owner’s Manual D-980 Start Lock Unit Mounting Bolt Washer Mounting Bolt Engine Shaft Shaft O-ring F Flange Installation on -2 Propeller Models Figure 3-8 Page 3-30 61-00-75 INSTALLATION AND REMOVAL Dec/05...
  • Page 111 Propeller Owner’s Manual USE CAUTION DURING INSTALLATION WARNING: WHEN THE START LOCKS HAVE BEEN ENGAGED TO FACILITATE INSTALLATION OF THE SPINNER BULKHEAD. IF THE BLADES ARE RELEASED SUDDENLY, THE EXTREME FORCE CAN CAUSE SERIOUS INJURY AND DAMAGE TO THE PROPELLER. (3) If the spinner bulkhead is to be installed and is not already in place, perform the following steps: The start locks must be engaged to provide...
  • Page 112 Propeller Owner’s Manual USE CARE TO AVOID SCRAPING CAUTION: ALUMINUM FROM THE BORE OF THE SPINNER BULKHEAD. SCRAPINGS COULD BECOME WEDGED BETWEEN THE FLANGES. (6) Align the threaded holes of the propeller flange with the bolt holes in the engine flange, and align the dowel pins in the propeller flange with the dowel pin holes in the engine flange.
  • Page 113 Propeller Owner’s Manual (10) Safety all mounting bolts with 0.032 inch (0.810 mm) minimum diameter stainless steel wire (two bolts for each safety). (11) Procedure for reinstallation of the piston nut, if applicable. (a) Following the installation of the propeller, retract the start lock pins and hold them in place with a heavy wire inserted through the hole of each start lock housing.
  • Page 114 (14) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 115 Propeller Owner’s Manual (16) Install the spinner dome as follows: The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation instructions.
  • Page 116 Propeller Owner’s Manual D-980 Start Lock Unit Shaft O-ring Engine Shaft Mounting Bolt Shim Starter Ring Gear Adapter Ring K and L Flange Installation on -2 Propeller Models Figure 3-9 Page 3-36 61-00-75 INSTALLATION AND REMOVAL Dec/05...

  • Page 117: X,V)(K,L)-2( )( )

    Propeller Owner’s Manual F. Installing K and L Flange Propeller Models HC-82(X,V)(K,L)-2( )( ) Refer to Figure 3-7. CLEANING AGENT MEK IS FLAMMABLE WARNING: AND TOXIC TO THE SKIN, EYES AND RESPIRATORY TRACT. SKIN AND EYE PROTECTION ARE REQUIRED. AVOID PROLONGED CONTACT.
  • Page 118 Propeller Owner’s Manual TO FACILITATE BOXING AND SHIPPING WARNING 1: OF THE PROPELLER, THE PISTON NUT MAY HAVE BEEN REMOVED TO PERMIT ROTATING OF THE BLADES BEFORE PACKAGING. FOR SAFETY REASONS, IF THE PISTON NUT WAS NOT REMOVED, THE PROPELLER MUST BE PUT IN FEATHER POSITION BEFORE IT IS INSTALLED ON THE AIRCRAFT.
  • Page 119 Propeller Owner’s Manual MAKE SURE THAT COMPLETE CAUTION: AND TRUE SURFACE CONTACT IS ESTABLISHED BETWEEN THE PROPELLER HUB FLANGE AND THE ENGINE FLANGE. (8) Slide the propeller flange onto the engine flange, against the starter ring gear and shim. (9) Insert the engine bushings into the counterbores that encircle the propeller mounting bolts in the propeller flange.
  • Page 120 Propeller Owner’s Manual (12) Use a torque wrench with the appropriate torque wrench adapter to torque all mounting bolts in sequence. Refer to Table 3-2 and Figure 3-4 to determine the proper torque value to which the torque wrench must be set. Refer to the Tools, Consumables, and NOTE: Expendables section in this chapter for a list of...
  • Page 121 (18) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 122 Propeller Owner’s Manual (20) Install the spinner dome as follows: The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation instructions.
  • Page 123 Propeller Owner’s Manual (This page is intentionally blank.) Page 3-43 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 124 Propeller Owner’s Manual D-1495 Page 3-44 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...

  • Page 125: Installing F Flange Propeller Models Hc-83(X,V)F-2( )( )

    Propeller Owner’s Manual G. Installing F Flange Propeller Models HC-83(X,V)F-2( )( ) Refer to Figure 3-10. INSERT THE DOWEL PINS INTO CAUTION: THE PROPELLER FLANGE USING A BRASS HAMMER OR EQUIVALENT TOOL TO PREVENT DAMAGE TO THE DOWEL PINS. THE DOWEL PINS ARE AN INTERFERENCE FIT WITH THE PROPELLER FLANGE.
  • Page 126 Propeller Owner’s Manual (b) From the engine side of the bulkhead, insert the attaching bolts through the bulkhead and into the start lock units. (c) Install the washers and locking nuts (Table 3-1) on the propeller side of the start lock to secure the attaching bolts and the bulkhead.
  • Page 127 Propeller Owner’s Manual MAKE SURE THAT COMPLETE AND TRUE CAUTION: SURFACE CONTACT IS ESTABLISHED BETWEEN THE PROPELLER HUB FLANGE AND THE ENGINE FLANGE. (7) Slide the propeller onto the engine shaft. NEW PROPELLER MOUNTING BOLTS CAUTION: MUST BE USED WHEN INITIALLY INSTALLING A NEW OR OVERHAULED PROPELLER.
  • Page 128 (14) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 129 (d) Manual 183 (61-12-83) - Propeller Anti-icing Boot Removal and Installation Manual (15) Propeller ice protection system components not supplied by Hartzell Propeller Inc. are controlled by the applicable TC or STC holder’s Instructions for Continued Airworthiness (ICA). (16) Install the spinner dome as follows:...
  • Page 130 Propeller Owner’s Manual Page 3-50 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...

  • Page 131: Installing F Flange Propeller Models Hc-83(X,V)F-3( )( )

    Propeller Owner’s Manual H. Installing F Flange Propeller Models HC-83(X,V)F-3( )( ) Refer to Figure 3-11. (1) Install the beta valve inside the engine shaft. Refer to the engine manufacturer’s instructions. CLEANING AGENT MEK IS FLAMMABLE WARNING: AND TOXIC TO THE SKIN, EYES AND RESPIRATORY TRACT.
  • Page 132 Propeller Owner’s Manual MAKE SURE THAT COMPLETE AND TRUE CAUTION 1: SURFACE CONTACT IS ESTABLISHED BETWEEN THE PROPELLER HUB FLANGE AND THE ENGINE FLANGE. MAKE SURE THE PITCH CHANGE CAUTION 2: ROD ACCURATELY ALIGNS WITH THE ENGINE-MOUNTED BETA VALVE. MISALIGNMENT WILL DAMAGE THE BETA VALVE AND/OR THE PITCH CHANGE ROD.
  • Page 133 (11) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 134 Propeller Owner’s Manual (13) Install the spinner dome as follows: The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation instructions.
  • Page 135 Propeller Owner’s Manual (This page is intentionally blank.) Page 3-55 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 136 Propeller Owner’s Manual Page 3-56 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...

  • Page 137: Installing Splined Propeller Models Hc-83(X,V)20-1( )( )( )

    Propeller Owner’s Manual Installing Splined Propeller Models HC-83(X,V)20-1( )( )( ) Refer to Figure 3-12. THE PISTON MUST BE REMOVED CAUTION: BEFORE INSTALLING THE PROPELLER ON THE AIRCRAFT. IF THE PISTON HAS ALREADY BEEN REMOVED, PROCEED TO STEP 4.I.(3). (1) Piston removal (a) The piston ears, forks, and counterweights should have corresponding index numbers (1, 2, and 3) impression-stamped or marked with a felt-tipped...
  • Page 138 Propeller Owner’s Manual (5) Install the rear cone O-ring (Table 3-1) over the shaft and against the cone. Refer to Figure 3-13. MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING INSTALLATION.
  • Page 139 Propeller Owner’s Manual TO PREVENT DAMAGE TO THE BLADE CAUTION: AND BLADE PAINT, WRAP THE BLADE SHANKS IN SEVERAL LAYERS OF MASKING OR DUCT TAPE BEFORE INSTALLING THE SPINNER DOME. REMOVE THE TAPE AFTER THE SPINNER IS INSTALLED. (8) Carefully slide the spinner dome over the installed propeller.
  • Page 140 Propeller Owner’s Manual (13) Safety the hub nut using the hub lock safety pin (Table 3-1). Refer to Figure 3-14. (14) If the piston O-ring (Table 3-1) and the felt dust seal are not already installed in the piston, perform the following steps.
  • Page 141 Propeller Owner’s Manual TO MAINTAIN PROPER BLADE ANGLES, CAUTION: REINSTALL THE PISTON IN THE SAME POSITION AS WHEN IT WAS ORIGINALLY ASSEMBLED. INDEX NUMBERS ON THE PISTON AND THE GUIDE COLLAR ARE PROVIDED TO MAKE SURE OF PROPER POSITIONING. (15) Locate and match up the index numbers (1, 2, and 3) on the forks and piston ears with the corresponding index numbers on the counterweights.
  • Page 142 (27) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.
  • Page 143 CAUTION 2: IF NOT ALIGNED PROPERLY, AND MAY AFFECT THE BALANCE OF THE PROPELLER. The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation...
  • Page 144 Propeller Owner’s Manual Page 3-64 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...

  • Page 145: Installing Splined Propeller Models Hc-83(X,V)20-2( )( )

    Propeller Owner’s Manual J. Installing Splined Propeller Models HC-83(X,V)20-2( )( ) Refer to Figure 3-16. MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING INSTALLATION. THE PISTON MUST BE REMOVED CAUTION: BEFORE INSTALLING THE PROPELLER ON THE AIRCRAFT.
  • Page 146 Propeller Owner’s Manual (b) Remove the safety wire (if installed) from the link pin units. (c) Remove the safety screw from each link pin unit. (d) Remove each link pin unit. (e) The piston ears and guide collar should have corresponding index numbers (1 and 2 on a 2- blade propeller;...
  • Page 147 Propeller Owner’s Manual CLEANING AGENT MEK IS FLAMMABLE WARNING: AND TOXIC TO THE SKIN, EYES AND RESPIRATORY TRACT. SKIN AND EYE PROTECTION ARE REQUIRED. AVOID PROLONGED CONTACT. USE IN A WELL VENTILATED AREA. (3) Clean the propeller hub spline and engine spline surfaces with Quick Dry Stoddard Solvent or MEK.
  • Page 148 Propeller Owner’s Manual (8) Install the rear cone and bulkhead on the shaft. (9) With a suitable crane hoist and sling, carefully move the propeller assembly to the aircraft engine mounting flange in preparation for installation. If the propeller is equipped with an anti-ice NOTE: or a de-ice system, follow the applicable manufacturer’s instructions for installation of...
  • Page 149 Propeller Owner’s Manual (12) To properly position the rear bulkhead, temporarily install the spinner dome with at least four screws. Make sure the start lock pins are parallel with NOTE: the blade axis, but offset to one side. (13) Adjust the spinner to equalize the clearance between the blades and the blade cutouts in the dome.
  • Page 150 Propeller Owner’s Manual (18) If the piston O-ring (Table 3-1) and the felt dust seal are not already installed in the piston, perform the following steps. Refer to Figure 3-15. (a) Lubricate the piston O-ring with aviation grade reciprocating engine oil and carefully install it in the inner groove provided for it in the piston.
  • Page 151 Propeller Owner’s Manual TO MAINTAIN PROPER BLADE ANGLES, CAUTION: REINSTALL THE PISTON IN THE SAME POSITION AS WHEN IT WAS ORIGINALLY ASSEMBLED. INDEX NUMBERS ON THE PISTON AND THE GUIDE COLLAR ARE PROVIDED TO MAKE SURE OF PROPER POSITIONING. (20) Locate and match up the index numbers (1 and 2 on 2-blade propeller;...
  • Page 152 (34) If the propeller is equipped with an ice protection system that uses components supplied by Hartzell Propeller Inc., applicable instructions and technical information for the components supplied by Hartzell can be found in the following publications available on the Hartzell web site at www.hartzellprop.com.

  • Page 153: Post-Installation Checks

    CAUTION 2: IF NOT ALIGNED PROPERLY, AND MAY AFFECT THE BALANCE OF THE PROPELLER. The following instructions relate to Hartzell NOTE: spinners only. In some cases, the airframe manufacturer produced the spinner assembly. In those cases, refer to the airframe manufacturer’s manual for spinner installation...

  • Page 154: Propeller Assembly Removal

    MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. (2) Remove the safety wire on the propeller mounting bolts. Page 3-74...
  • Page 155 Propeller Owner’s Manual MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG.) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING REMOVAL. (3) Support the propeller assembly with a sling. NOTE 1: To permit rotation of the propeller for ease of bolt removal, supporting the propeller with a sling may be delayed until all but two mounting bolts and washers have been removed.

  • Page 156: Removing The F Flange Propeller Models Hc-82(X,V)F-1( )( )( ) And Hc-82Xf-6( )( )( )

    MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. (2) Remove the safety wire on the propeller mounting bolts. Page 3-76...
  • Page 157 Propeller Owner’s Manual MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG.) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING REMOVAL. (3) Support the propeller assembly with a sling. NOTE 1: To permit rotation of the propeller for ease of bolt removal, supporting the propeller with a sling may be delayed until all but two mounting bolts and washers have been removed.
  • Page 158 (7) Remove and discard the shaft O-ring. (8) Remove the shim. (9) If the spinner was manufactured by Hartzell Propeller: (a) Do not remove the spinner adapter ring. (b) Visually inspect the spinner adapter ring for cracks. (c) If cracks are found in the spinner adapter ring, remove it from the engine starter ring gear and replace it.

  • Page 159: Removing The F Flange Propeller Models Hc-82(X,V)F-2( )( )

    AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-79 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 160 Propeller Owner’s Manual USE CAUTION DURING PROPELLER WARNING 3: REMOVAL WHEN THE START LOCKS ARE ENGAGED. IF THE BLADES ARE RELEASED SUDDENLY, THE EXTREME FORCE CAN CAUSE SERIOUS INJURY AND DAMAGE TO THE PROPELLER. (2) Routine propeller engine shutdown will engage the start lock units, preventing the propeller from feathering.
  • Page 161 Propeller Owner’s Manual DISCARD THE PROPELLER MOUNTING CAUTION: BOLTS AND WASHERS IF THEY ARE DAMAGED OR CORRODED, OR IF THE PROPELLER IS REMOVED FOR OVERHAUL. (5) Remove the propeller mounting bolts and washers. For propeller removals between overhaul NOTE: intervals, mounting bolts and washers may be reused if they are not damaged or corroded.
  • Page 162 AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-82 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 163 Propeller Owner’s Manual FOR SAFETY REASONS, THE WARNING 3: PROPELLER MUST BE PUT IN THE FEATHER POSITION BEFORE IT IS REMOVED FROM THE AIRCRAFT. (2) Routine propeller engine shutdown will engage the start lock units, preventing the propeller from feathering. For purposes of propeller removal, the propeller should be put in feather position during engine shutdown.
  • Page 164 Propeller Owner’s Manual MAKE SURE THE SLING IS RATED UP TO WARNING: 800 POUNDS (363 KG.) TO SUPPORT THE WEIGHT OF THE PROPELLER ASSEMBLY DURING REMOVAL. (4) Support the propeller assembly with a sling. NOTE 1: To permit rotation of the propeller for ease of bolt removal, supporting the propeller with a sling may be delayed until all but two mounting bolts and washers have been removed.
  • Page 165 (11) Remove the shim. (12) Using the support sling, lift the propeller from the mounting flange. (13) If the spinner was manufactured by Hartzell Propeller: (a) Do not remove the spinner adapter ring. (b) Visually inspect the spinner adapter ring for cracks.

  • Page 166: Removing The K And L Flange Propeller Models Hc-82(X,V)(K,L)-2( )( )

    AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-86 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 167 Propeller Owner’s Manual USE CAUTION DURING PROPELLER WARNING 3: REMOVAL WHEN THE START LOCKS ARE ENGAGED. IF THE BLADES ARE RELEASED SUDDENLY, THE EXTREME FORCE CAN CAUSE SERIOUS INJURY AND DAMAGE TO THE PROPELLER. (2) Routine propeller engine shutdown will engage the start lock units, preventing the propeller from feathering.
  • Page 168 Propeller Owner’s Manual (5) Remove the propeller mounting bolts and washers. For propeller removals between overhaul NOTE: intervals, mounting bolts and washers may be reused if they are not damaged or corroded. USE ADEQUATE PRECAUTIONS TO CAUTION: PROTECT THE PROPELLER ASSEMBLY FROM DAMAGE WHEN IT IS REMOVED FROM THE AIRCRAFT ENGINE AND WHEN IT IS STORED.

  • Page 169: Removing F Flange Propeller Models Hc-83(X,V)F-3( )( )

    AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-89 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 170 Propeller Owner’s Manual FOR SAFETY REASONS, THE WARNING 3: PROPELLER MUST BE PUT IN FEATHER POSITION BEFORE IT IS REMOVED FROM THE AIRCRAFT. (3) Routine propeller engine shutdown will engage the start lock units, preventing the propeller from feathering. For purposes of propeller removal, the propeller should be put in feather position during engine shutdown.
  • Page 171 Propeller Owner’s Manual NOTE 2: If the propeller will be reinstalled, and it has been dynamically balanced, make an identifying mark (with a felt-tipped pen only) on the propeller hub and a matching mark on the engine flange to make sure of proper positioning of the propeller during reinstallation.
  • Page 172 AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-92 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 173 Propeller Owner’s Manual OIL WILL FLOW OUT OF THE CAUTION: PROPELLER WHEN THE PISTON IS REMOVED. PUT A DRIP PAN UNDER THE PROPELLER TO CATCH THE EXCESS OIL. (2) Piston Removal (Refer to Figure 3-17.) (a) Remove the self-locking nut from each piston rod. (b) Remove the washer from each piston rod.
  • Page 174 Propeller Owner’s Manual (3) Remove the hub lock safety pin. Refer to Figure 3-14. (4) Using tool BST-2910, completely loosen the shaft nut from the engine shaft threads. Because the shaft nut is pulling the propeller NOTE: hub off the tapered rear cone, there will be significant initial resistance to the loosening of the shaft nut.

  • Page 175: Removing The 20 Splined Propeller Models Hc-83(X,V)20-1( )( )( )

    AIRFRAME MANUFACTURER’S MANUALS AND PROCEDURES MUST BE FOLLOWED BECAUSE THEY MAY CONTAIN ISSUES VITAL TO AIRCRAFT SAFETY THAT ARE NOT CONTAINED IN THIS MANUAL OR IN THE HARTZELL PROPELLER OVERHAUL MANUALS. Page 3-95 61-00-75 INSTALLATION AND REMOVAL Rev. 1 Jun/11...
  • Page 176 Propeller Owner’s Manual FOR SAFETY REASONS, THE WARNING 3: PROPELLER MUST BE PUT IN THE FEATHER POSITION BEFORE IT IS REMOVED FROM THE AIRCRAFT. (2) Routine propeller engine shutdown will engage the start lock units, preventing the propeller from feathering. For purposes of propeller removal, the propeller should be put in feather position during engine shutdown.
  • Page 177 Propeller Owner’s Manual (3) Piston removal (Refer to figure 3-17) (a) Remove the piston nut. (b) Remove the safety wire from the link pin units. (c) Remove the safety screws from each link pin unit. (d) Remove each link pin unit. (e) The piston ears and guide collar should have corresponding index numbers (1 and 2 for a 2-blade propeller;...
  • Page 178 Propeller Owner’s Manual USE ADEQUATE PRECAUTIONS TO CAUTION: PROTECT THE PROPELLER ASSEMBLY FROM DAMAGE WHEN IT IS REMOVED FROM THE AIRCRAFT ENGINE AND WHEN IT IS STORED. (8) Using the support sling, slide the propeller from the engine splined shaft and lift the propeller from the engine.
  • Page 179 Propeller Owner's Manual CONTENTS Page Operational Tests ..............4-3 Initial Run-Up ..............4-3 Static RPM Check .............. 4-3 Post-Run Check ..............Propeller Ice Protection Systems ........... 4-4 Electric De-Ice System ............4-4 Anti-Ice System ..............Troubleshooting ..............4-5 Incorrect Maximum RPM (on ground) ........
  • Page 180 Propeller Owner's Manual (This page is intentionally blank.) Page 4-2 61-00-75 TESTING AND TROUBLESHOOTING Rev. 1 Jun/11...

  • Page 181: Operational Tests

    Propeller Owner's Manual 1. Operational Tests Following propeller installation, and before flight, the propeller hydraulic system must be purged of air and proper operation verified. A. Initial Run-Up (1) Perform engine start and warm-up in accordance with the Pilot's Operating Handbook (POH). (2) Cycle the propeller control throughout its operating pitch range from low to high (or as directed by the POH).

  • Page 182: Post-Run Check

    Propeller Owner's Manual (6) Slowly advance the propeller control lever until the engine speed stabilizes. (a) If engine speed stabilizes at the maximum RPM specified by the TC or STC holder, then the low pitch stop is set correctly. (b) If engine speed stabilizes above or below the rated RPM, the low pitch stop may require adjustment.

  • Page 183: Troubleshooting

    (3) If adjustment of the propeller low pitch blade angle is required, adjustment must be performed by qualified personnel at an appropriately licensed propeller service facility or by the Hartzell factory. B. Maximum RPM is Low (1) Engine power is low (a) Follow aircraft POH and/or AMM recommended checks to determine if the engine power is low.

  • Page 184: Maximum Rpm Is High

    Propeller Owner's Manual (g) If the engine speed stabilizes at a higher RPM than it was previously running, then the governor maximum RPM stop setting is incorrectly set. Make additional fine adjustments to the governor maximum RPM stop setting until the rated maximum RPM is reached.

  • Page 185: Hunting And Surging

    Propeller Owner's Manual D. Hunting and Surging Hunting is characterized by a cyclic variation in engine speed above and below desired speed. Surging is characterized by a large increase/decrease in engine speed, followed by a return to set speed after one or two occurrences. (1) If propeller is hunting, a repair facility should check: (a) Governor (b) Fuel control...
  • Page 186 Propeller Owner's Manual (b) HC-8( )( )( )-1( )( ), -2( )( ), and -3( )( ) propeller models: Governor is not reducing oil volume in the propeller. Excessive friction in the blade bearings or the pitch change mechanism Excessive friction in the misalignment between the guide collar and the piston rods (3) Decrease in engine speed while increasing airspeed: (a) HC-82(X,V)(F,L )-6( )( )( ) propeller models:...

  • Page 187: Loss Of Propeller Control - Hc-82(X,V)(F,L )-6( )( )( ) Propeller Models

    Propeller Owner's Manual (b) HC-8( )( )( )-1( )( ), -2( )( ), and -3( )( ) propeller models: Governor is not increasing oil volume in the propeller. Engine oil transfer bearing is leaking excessively. Excessive friction in the blade bearings or the pitch change mechanism F.

  • Page 188: Loss Of Propeller Control - Hc-8( )( )( )-1( )( ), -2( )( ), And -3( )( ) Propeller Models

    Propeller Owner's Manual G. Loss of Propeller Control - HC-8( )( )( )-1( )( ), -2( )( ), and -3( )( ) propeller models: (1) Propeller goes to uncommanded high pitch (or feather) (a) Loss of propeller oil pressure - check: Governor pressure relief valve for proper operation Governor drive for damage...

  • Page 189: Failure To Unfeather - Hc-8( )( )( )-2( )( ) And -3( )( ) Propeller Models Only

    Propeller Owner's Manual Failure to Unfeather - HC-8( )( )( )-2( )( ) and -3( )( ) propeller models only: (1) Check for proper function and rigging of the propeller control linkage to the governor. (2) Check governor function. (3) Check for excessive oil leakage at the engine oil transfer bearing.

  • Page 190: Vibration

    Propeller Owner's Manual (3) Excessive engine oil transfer bearing leakage. Refer to an appropriately licensed propeller repair facility. (4) Excessive governor pump leakage. Refer to an appropriately licensed propeller repair facility. (5) Broken start locks. Refer to an appropriately licensed propeller repair facility. K.

  • Page 191: Propeller Overspeed

    Propeller Owner's Manual (j) Airfoil profile identical between blades (after overhaul or rework for nicks - verify at appropriately licensed propeller repair facility). (k) Hub, blade, or blade clamp for damage or cracking. (l) Grease or oil leakage from a seemingly solid surface of the hub, blade clamp, or blade.

  • Page 192: Oil Or Grease Leakage

    Propeller Owner's Manual (c) Governor oil pressure low - HC-8( )( )( )-1( )( ), -2( )( ), and -3( )( ) propeller models. (d) Governor oil passage clogged. (e) Governor pilot valve jammed - HC-8( )( )( )-1( )( ), -2( )( ), and -3( )( ) propeller models.
  • Page 193 Propeller Owner's Manual (2) Oil Leakage - Probable Cause (a) Faulty O-ring seal between the hub and the cylinder. (b) Faulty O-ring seal between the piston and the cylinder. (c) Displaced felt seal between the piston and the cylinder (d) Faulty O-ring between the propeller hub and the engine flange.
  • Page 194 Propeller Owner's Manual (This page is intentionally blank.) Page 4-16 61-00-75 TESTING AND TROUBLESHOOTING Rev. 1 Jun/11...
  • Page 195 Propeller Owner’s Manual CONTENTS Page Pre-Flight Checks ..............5-3 Operational Checks ..............5-4 Required Periodic Inspections and Maintenance ....5-5 Periodic Inspection ............. 5-5 Periodic Maintenance ............5-6 Airworthiness Limitations ........... 5-6 Overhaul Periods ............... 5-6 Inspection Procedures ............5-7 Blade Damage ..............
  • Page 196 Propeller Owner’s Manual (This page is intentionally blank.) Page 5-2 61-00-75 INSPECTION AND CHECK Dec/05...

  • Page 197: Pre-Flight Checks

    Propeller Owner’s Manual 1. Pre-Flight Checks Follow propeller preflight inspection procedures as specified in the Pilot Operating Handbook (POH) or this manual. In addition, perform the following inspections: A. Blades (1) Visually inspect the entire blade (lead, trail, face, and camber sides) for nicks, gouges, erosion, and cracks.

  • Page 198: Operational Checks

    Propeller Owner’s Manual F. Inspect de-ice boots (if installed) for damage. Refer to De-Ice System Inspections in the Anti-Ice and De-Ice Systems chapter of this manual, for inspection information. G. Refer to the Periodic Inspections section in this chapter for additional inspection information and possible corrections to any discrepancies discovered as a result of preflight checks.

  • Page 199: Required Periodic Inspections And Maintenance

    Propeller Owner’s Manual 3. Required Periodic Inspections and Maintenance Perform detailed inspection procedures at 100 hour intervals, not to exceed twelve (12) calendar months. Procedures involved in these inspections are detailed below. A. Periodic Inspection NOTE 1: Inspection and maintenance specified by an airframe manufacturer’s maintenance program and approved by the applicable airworthiness agency may not coincide with the inspection time...

  • Page 200: Periodic Maintenance

    Operators are urged to keep informed of airworthiness information via Hartzell Service Bulletins and Service Letters, which are available from Hartzell distributors or from the Hartzell factory by subscription. Selected information is also available on Hartzell Propeller’s website at www.hartzellprop.com.

  • Page 201: Inspection Procedures

    CAUTION 2: CHECK THE LATEST REVISION OF HARTZELL SERVICE LETTER 61( ) FOR THE MOST CURRENT INFORMATION. (1) Hartzell “reciprocating” propellers installed on piston engine aircraft are to be overhauled at intervals as follows: (a) Agricultural Aircraft - Propeller models HC-8( )X,V( )-( ) - 1000 hours or 36 calendar months (whichever occurs first).

  • Page 202: Grease Or Oil Leakage

    Propeller Owner’s Manual B. Grease or Oil Leakage NOTE: A new or newly overhauled propeller may leak slightly during the first several hours of operation. This leakage may be caused by the seating of seals and O-rings, and the slinging of lubricants used during assembly.

  • Page 203: Vibration

    Propeller Owner’s Manual (4) If cracks or failing components are found, these parts must be replaced before further flight. Report such occurrences to airworthiness authorities and to Hartzell Propeller Inc. Product Support. C. Vibration Instances of abnormal vibration should be investigated immediately.
  • Page 204 Refer to Blade Repairs section in Maintenance Practices chapter of this manual. (8) If cracks or failing components are found, these parts must be replaced before further flight. Report such occurrences to airworthiness authorities and Hartzell Propeller Inc. Product Support. Page 5-10 61-00-75...

  • Page 205: Tachometer Inspection

    (1) Verify the accuracy of the engine tachometer with a hand-held tachometer at 100 hour intervals or at annual inspection, whichever occurs first. (2) Hartzell Propeller Inc recommends using a tachometer that is accurate within +/- 10 RPM, has NIST calibration (traceable), and has an appropriate calibration schedule.
  • Page 206 Propeller Owner’s Manual APS6155 Checking Blade Track Figure 5-1 APS6163 FORE AND AFT PLAY IN AND OUT PLAY BLADE END PLAY RADIAL PLAY Blade Play Figure 5-2 Page 5-12 61-00-75 INSPECTION AND CHECK Dec/05...

  • Page 207: Loose Blades

    Propeller Owner’s Manual (2) Possible Correction (a) Remove foreign matter from the propeller mounting flange. (b) If no foreign matter is present, refer to an Airworthiness agency approved propeller repair station. F. Loose Blades Refer to Figure 5-2. Limits for blade looseness are as follows: End Play ±...

  • Page 208: Anti-Ice System

    Propeller Owner’s Manual J. Anti-ice System Refer to the Anti-Ice and De-ice Systems chapter of this manual for inspection procedures. 5. Special Inspections A. Overspeed An overspeed has occurred when the propeller RPM has exceeded the maximum RPM stated in the applicable Aircraft Type Certificate Data Sheet.
  • Page 209 Propeller Owner’s Manual Page 5-15 61-00-75 INSPECTION AND CHECK Dec/05...

  • Page 210: Lightning Strike

    Propeller Owner’s Manual B. Lightning Strike CAUTION: ALSO CONSULT ENGINE AND AIRFRAME MANUFACTURER’S MANUALS. THERE MAY BE ADDITIONAL REQUIREMENTS SUCH AS DE-ICE AND ENGINE SYSTEM CHECKS TO PERFORM AFTER A PROPELLER LIGHTNING STRIKE. (1) General In the event of a propeller lightning strike, an inspection is required before further flight.

  • Page 211: Foreign Object Strike

    Propeller Owner’s Manual (d) Regardless of the degree of damage, make a log book entry to document the lightning strike. (e) The propeller must be removed from the aircraft, disassembled, evaluated, and/or repaired by an appropriately licensed propeller repair facility for flight beyond the temporary operation limits granted above.
  • Page 212 Maintenance Practices chapter of this manual. (c) For engine mounted accessories (for example, governors, pumps, and propeller control units) manufactured by Hartzell, if the foreign object strike resulted in a sudden stop of the engine, the unit must be disassembled and inspected in accordance with the applicable maintenance manual.

  • Page 213: Fire Damage Or Heat Damage

    6. Long Term Storage A. Parts shipped from the Hartzell factory are not shipped or packaged in a container that is designed for long term storage. B. Long term storage procedures may be obtained by contacting the Hartzell factory via the product support number listed in the Introduction chapter of this manual.
  • Page 214 Propeller Owner’s Manual (This page is intentionally blank.) Page 5-20 61-00-75 INSPECTION AND CHECK Rev. 1 Jun/11...
  • Page 215 Propeller Owner's Manual CONTENTS Page Cleaning ................. 6-3 General Cleaning ............... 6-3 Spinner Cleaning and Polishing ......... 6-3 Lubrication ................6-5 Lubrication Intervals ............6-5 Lubrication Procedure ............6-5 Approved Lubricants ............6-8 Blade Repairs ............... 6-10 Repair of Nicks or Gouges ..........
  • Page 216 Propeller Owner's Manual CONTENTS Page Feathering Pitch Stop Adjustment ........6-23 Propeller Models HC-8( )( )( )-2( )( ) and HC-83(X,V)F-3( )( ) ........... 6-23 Start Lock Adjustment ............6-23 Propeller Models HC-8( )( )( )-2( )( ) and HC-83(X,V)F-3( )( ) ...........

  • Page 217: Cleaning

    Propeller Owner's Manual 1. Cleaning CAUTION: DO NOT USE PRESSURE WASHING EQUIPMENT TO CLEAN THE PROPELLER OR CONTROL COMPONENTS. PRESSURE WASHING CAN FORCE WATER AND/OR CLEANING SOLVENTS PAST SEALS, AND LEAD TO INTERNAL CORROSION OF PROPELLER COMPONENTS. A. General Cleaning CAUTION 1: WHEN CLEANING THE PROPELLER, DO NOT PERMIT SOAP OR SOLVENT...
  • Page 218 Propeller Owner's Manual D-980 LUBRICATION FITTING (ONE IN EACH CLAMP HALF) Lubrication Fitting Figure 6-1 Page 6-4 61-00-75 MAINTENANCE PRACTICES Dec/05...

  • Page 219: Propeller Assembly

    Propeller Owner's Manual 2. Lubrication A. Lubrication Intervals (1) The propeller is to be lubricated at 12 months or at 100 hour intervals, whichever occurs first. NOTE 1: If annual operation is significantly less than 100 hours, calendar lubrication intervals should be reduced to six months.
  • Page 220 WARNING: WHEN MIXING AEROSHELL GREASES 5 AND 6, AEROSHELL GREASE 5 MUST BE INDICATED ON THE LABEL (HARTZELL P/N A-3594) AND THE AIRCRAFT MUST BE PLACARDED TO INDICATE THAT FLIGHT IS PROHIBITED IF THE OUTSIDE AIR TEMPERATURE IS LESS THAN -40°F (-40°C).
  • Page 221 (4) Aeroshell greases 5 and 6 both have a mineral oil base and have the same thickening agent; therefore, mixing of these two greases is acceptable in Hartzell propellers. (5) A label (Hartzell P/N A-3494) is normally applied to the propeller to indicate the type of grease previously used (Figure 6-2).

  • Page 222: Approved Lubricants

    (9) Install on each lubrication fitting. C. Approved Lubricants (1) The following lubricants are approved for use in Hartzell compact propellers: Aeroshell 6 - Recommended "all purpose" grease. Used in most new production propellers since 1989.
  • Page 223 Propeller Owner's Manual APS6157 Example 1 LOOKING AT LEADING EDGE Example 3 Example 2 LEADING EDGE FACE/CAMBER 2.5 Inches (63.5 mm) = D x 20 2.5 Inches (63.5 mm) = D x 10 0.13 Inch (1.38 mm) deep 0.25 Inch (6.35 mm) deep LOCAL LOCAL REPAIR...

  • Page 224: Blade Repairs

    MAKING REPAIRS ON BLADES THAT ARE APPROACHING SERVICEABLE LIMITS, CONTACT AN APPROPRIATELY LICENSED PROPELLER SERVICE FACILITY OR THE HARTZELL PRODUCT SUPPORT DEPARTMENT FOR BLADE DIMENSIONAL LIMITS. Nicks, gouges, and scratches on blade surfaces or on the leading or trailing edges of the blade, greater than 1/32 inch wide or deep, must be removed before flight.
  • Page 225 PEENED BEFORE FURTHER FLIGHT. SHOT PEENING OF AN ALUMINUM BLADE MUST BE ACCOMPLISHED BY AN FAA APPROVED REPAIR FACILITY IN ACCORDANCE WITH HARTZELL ALUMINUM BLADE MANUAL 133C (61-13-33). (1) Repairs to the leading or trailing edge are to be accomplished by removing material from the bottom of the damaged area.

  • Page 226: Repair Of Bent Blades

    Propeller Owner's Manual (3) The area of repair should be determined as follows: Leading and trailing edge damage: Depth of nick x 10. Face and camber: Depth of nick x 20. Refer to Figure 6-3. Leading edge includes the first 10 percent NOTE: of chord from the leading edge.

  • Page 227: Painting After Repair

    Painting should be performed by an appropriately licensed propeller service facility in accordance with Hartzell Standard Practices Manual 202A (61-01-02). It is permissible to perform a blade touch-up with aerosol paint in accordance with the procedures in Painting of Aluminum Blades, below.

  • Page 228: Painting Of Aluminum Blades

    Propeller Owner's Manual The paint manufacturers may be contacted as listed below: Tempo Products Co. Sherwin Williams Co. A plasti-kote Company 2390 Arbor Boulevard 1000 Lake Road Dayton, Ohio Medina, OH 44256 Tel: 937.298.8691 Tel: 800.321.6300 Fax: 937.298.3820 Fax: 216.349.4241 Cage Code: 0W199 Cage Code: 07708 B.
  • Page 229 Propeller Owner's Manual (4) Before refinishing the blades, apply a corrosion preventive coating to the bare aluminum surface. Oakite 31, Chromicote L-25, or Alodine 1201 are approved chemical conversion coatings. Apply these coatings in accordance with the directions provided by the product manufacturer.

  • Page 230: Dynamic Balance

    Some engine manufacturers' instructions also contain information on dynamic balance limits. (4) Unless otherwise specified by the engine or airframe manufacturer, Hartzell recommends that the propeller be dynamically balanced to a reading of 0.2 IPS or less. B. Inspection Procedures Before Balancing (1) Visually inspect the propeller assembly before dynamic balancing.
  • Page 231 Propeller Owner's Manual (b) Visually check each propeller blade assembly for evidence of grease leakage. (c) Visually inspect the inner surface of the spinner dome for evidence of grease leakage. (2) If there is no evidence of grease leakage, lubricate the propeller in accordance with the Maintenance Practices chapter in this manual.

  • Page 232: Placement Of Balance Weights For Dynamic Balance

    Propeller Owner's Manual C. Placement of Balance Weights for Dynamic Balance (1) The preferred method of attachment of dynamic balance weights is to add the weights to the spinner bulkhead; however, the configuration of the spinner bulkhead on many of the propeller models covered in this manual makes it impractical to mount dynamic balance weights in this manner.
  • Page 233 Propeller Owner's Manual Page 6-19 61-00-75 MAINTENANCE PRACTICES Dec/05...
  • Page 234 Propeller Owner's Manual (b) Maximum number of balance weights for each location For standard installations, the maximum number of balance weights for each location is four (4). NOTE: For propellers with a de-ice system using a blade clamp-mounted lead strap restraint, a maximum of three weights may be attached to the clamp with the de-ice lead strap restraint.

  • Page 235: Propeller Low Pitch Setting

    Propeller Owner's Manual 6. Propeller Low Pitch Setting WARNING 1: RPM ADJUSTMENTS MUST BE MADE WITH REFERENCE TO A CALIBRATED TACHOMETER. AIRCRAFT MECHANICAL TACHOMETERS DEVELOP ERRORS OVER TIME, AND SHOULD BE PERIODICALLY RECALIBRATED TO MAKE SURE THE PROPER RPM IS DISPLAYED. WARNING 2: LOW PITCH BLADE ANGLE ADJUSTMENTS MUST BE MADE IN CONSULTATION WITH...

  • Page 236: Low Pitch Measurement On Propeller Models Hc-82( )( )-2( )( )

    (b) If the blade angle requires adjustment, have the low pitch stop adjusted by an appropriately licensed service facility or by the Hartzell factory. Low pitch measurement on propeller models HC-82( )( )-2( )( ) (1) Low pitch measurement must be performed at an...

  • Page 237: Propeller High Pitch Settings

    Hartzell factory. 7. Propeller High Pitch Settings A. High Pitch (Minimum RPM) Stop - Propeller Models HC-8( )( )( )-1( )( ) AND HC-82(X,V)(F,L)-6( )( )( ) (1) The high pitch stop is set at the factory in accordance with aircraft manufacturer's recommendations.
  • Page 238 Propeller Owner's Manual (This page is intentionally blank.) Page 6-24 61-00-75 MAINTENANCE PRACTICES Rev. 1 Jun/11...
  • Page 239 Propeller Owner’s Manual CONTENTS Page Introduction ................7-3 Propeller De-ice System ............ 7-3 Propeller Anti-ice System ........... 7-3 System Description ..............7-4 De-ice System ..............7-4 Anti-ice System ..............7-5 De-ice and Anti-ice System Functional Tests......7-5 De-ice System ..............7-5 Anti-ice System ..............
  • Page 240 Propeller Owner’s Manual (This page is intentionally blank.) Page 7-2 61-00-75 ANTI-ICE AND DE-ICE SYSTEMS Rev. 1 Jun/11...

  • Page 241: Introduction

    Propeller Owner’s Manual 1. Introduction A. Propeller De-ice System A propeller de-ice system is a system that removes ice after it forms on the propeller blades. A de-ice system uses electrical heating elements to melt the ice layer next to the blades, permitting the ice to be thrown from the blade...

  • Page 242: System Description

    Propeller Owner’s Manual 2. System Description A. De-ice System NOTE: Because of the wide variances of various de-ice systems, the following description is general in nature. Consult the airframe manufacturer’s manual for a description of your specific de-ice system and controls. The de-ice system is controlled by the pilot via a cockpit control switch.

  • Page 243: Anti-Ice System

    Manuals, which are also available on the Hartzell Propeller web site at www.hartzellprop.com. (a) Hartzell Manual No. 181 (30-60-81) - Propeller Ice Protection Component Maintenance Manual (b) Hartzell Manual No. 182 (61-12-82) - Propeller Electrical De-ice Boot Removal and Installation...

  • Page 244: Ice And Anti-Ice System Inspections

    Hartzell Manuals, which are also available on the Hartzell Propeller web site at www.hartzellprop.com. (a) Hartzell Manual No. 181 (30-60-81) - Propeller Ice Protection Component Maintenance Manual (b) Hartzell Manual No. 182 (61-12-82) - Propeller...

  • Page 245: Anti-Ice System Troubleshooting

    Hartzell Manuals, which are also available on the Hartzell Propeller web site at www.hartzellprop.com. (a) Hartzell Manual No. 181 (30-60-81) - Propeller Ice Protection Component Maintenance Manual (b) Hartzell Manual No. 183 (61-12-83) - Propeller...
  • Page 246 Propeller Owner’s Manual (This page is intentionally blank.) Page 7-8 61-00-75 ANTI-ICE AND DE-ICE SYSTEMS Rev. 1 Jun/11...
  • Page 247 Propeller Owner’s Manual CONTENTS Page Introduction ................8-3 Record Keeping ..............8-3 Information to be Recorded ..........8-3 Page 8-1 61-00-75 RECORDS Dec/05...
  • Page 248 Propeller Owner’s Manual (This page is intentionally blank.) Page 8-2 61-00-75 RECORDS Dec/05...
  • Page 249 Propeller Owner’s Manual 1. Introduction Federal Aviation Regulations require that a record be kept of any repairs, adjustments, maintenance, or required inspections performed on a propeller or propeller system. This chapter provides a method for maintaining these records. It also provides a location for recording information that can aid the service technician in maintaining the propeller system.
  • Page 250 Propeller Owner’s Manual (This page is intentionally blank.) Page 8-4 61-00-75 RECORDS Dec/05...

This manual is also suitable for:

Hc-82xk-1Hc-82xl-1Hc-82vf-1Hc-82vk-1Hc-82vl-1Hc-82xf-2 ... Show all

Table of Contents
