Manual No. 140
61-00-40
Revision 5
April 2023
Propeller Owner's Manual
Hydro-Selective Propellers with Aluminum Blades
Hartzell Propeller Inc.
One Propeller Place
Piqua, OH 45356-2634 U.S.A.
Ph: 937-778-4200 (Hartzell Propeller Inc.)
Ph: 937-778-4379 (Product Support)
Product Support Fax: 937-778-4215
and Logbook
Series: HC-D2(MV,V)20-3
HC-D3(MV,V)20-6L
HC-D2(MV,V)20-7( )
HC-D2(MV,V)20-8( )
HC-D3MV20-8D
