Bosch Rexroth AG
FcP 5020 Parameter List

8.4 Group F3: p/Q PID Parameter

Code Name
F3.00 p/Q parameter selection source
F3.01 p/Q parameter digital selection
F3.02 Filter time for pressure feedback 0...999 ms
F3.03 Filter time for flow command
Filter time for pressure ascending
F3.10
[0]
Filter time for pressure descend-
F3.11
ing [0]
F3.12 Proportional gain [0]
F3.13 Integral time 1 [0]
F3.14 Integral time 2 [0]
Integral time TI switch threshold
F3.15
[0]
F3.16 Differential gain [0]
F3.17 Filter time for Kd [0]
F3.18 Lower limit for I+D [0]
F3.19 System minimum speed [0]
Filter time for pressure ascending
F3.30
[1]
Filter time for pressure descend-
F3.31
ing [1]
F3.32 Proportional gain [1]
F3.33 Integral time 1 [1]
F3.34 Integral time 2 [1]
Integral time TI switch threshold
F3.35
[1]
F3.36 Differential gain [1]
F3.37 Filter time for Kd [1]
F3.38 Lower limit for I+D [1]
F3.39 System minimum speed [1]
Pressure command
F3.40
threshold
Tab. 8-3: Parameter list of group F3
70/83
Setting range
0: Depend on the value of F3.01
1: Digital input (F3.01 shows sta-
tus)
2: Communication
0: Parameter group 0
1: Parameter group 1
0...999 ms
0...999 ms
0...999 ms
0.00...500.00 rpm/bar
0...999 ms
0...999 ms
-150.0...0.0 bar (set to 0.0, the
switching function is invalid)
0.000...10.000 (rpm/bar)*s
0...999 ms
-5,000...5,000 rpm
-5,000...5,000 rpm
0...999 ms
0...999 ms
0.00...500.00 rpm/bar
0...999 ms
0...999 ms
-150.0...0.0 bar (set to 0.0, the
switching function is invalid)
0.000...10.000 (rpm/bar)*s
0...999 ms
-5,000...5,000 rpm
-5,000...5,000 rpm
arrived
0.1...1000.0 bar
Default Min.
0
0
4 1
4 1
80 1
40 1
8.00 0.01
80 1
0 1
0.0 0.1
0.000 0.001
35 1
0 1
0 1
80 1
40 1
8.00 0.01
80 1
0 1
0.0 0.1
0.000 0.001
35 1
0 1
0 1
5.0 0.1
DOK-RCON03-FCP5020****-QU04-EN-P
FcP 5020
Attri.
- Stop
- Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
Run
