Block Diagram of Main Functions
Code
C1.05 Motor rated power
C1.06 Motor rated voltage
C1.07 Motor rated current
C1.08 Motor rated frequency
C1.09 Motor rated speed
C1.10 Motor rated power factor
C1.13 Motor inertia mantissa
C1.14 Motor inertia exponent
C1.20 Motor no-load current
Tab. 7-6: Auto-modified EFC motor control parameter list
Once motor control mode (C0.00) is changed, motor parameter will
be reset to factory default (not for MOT-FC parameter) even if F1.16
is set, for that please reload motor parameter by setting F1.16 again.
28/83
Name Code
C1.21 Stator resistance
C1.22 Rotor resistance
C1.23 Leakage inductance
C1.24 Mutual inductance
Motor thermal model protection time
C1.74
constant
C3.00 Speed loop proportional gain
C3.01 Speed loop integral time
C3.05 Current loop proportional gain
C3.06 Current loop integral time
