FcP 5020
CAUTION
Setting more than one input to same function is not allowed, by doing this the
very last change will be keep, but other conflicted parameter will be set to 0. For
example, by setting F2.19=2 and then F2.20=2, the value of F2.19 will be reset
to 0 automatically.
Four pressure command parameters are available in ASF, and these can be
switched according to setting of F1.03 and DI or F1.04. The following table
shows the correspondence between pressure command values and the setting
of the digital inputs.
Pressure command selection bit0
Pressure command selection bit1
F1.04
Pressure command
Tab. 6-5: The setting of digital input selection (F1.04)
Two parameter sets for p/Q controller are available in ASF, and these can be
switched according to setting of F3.00 and DI or F3.01. The following table
shows the correspondence between p/Q parameter selection through DI and
F3.01, parameter sets switching status will be shown via F3.01.
p/Q parameter selection
F3.01
p/Q parameter
Tab. 6-6: The setting of digital input selection (F3.01)
Once F1.11 has been set to "3: Select by digital input", Q_cmd can be selected
between F1.12 and F1.13 by digital input, which has been configured to "4:Flow
command selection", F1.14 shows then the selection status.
DOK-RCON03-FCP5020****-QU04-EN-P
0 1
0 0
0 1
F1.05 F1.06
0
0
F3.10...F3.19
Bosch Rexroth AG
Electric Connection
0 1
1 1
2 3
F1.07 F1.08
1
1
F3.30...F3.39
