Electric Connection
Code Name
F2.00 Analog input AI1
F2.01 Analog input AI2
External analog input EAI
F2.02
(-10V...10V, 4...20mA)
External analog input EAI2
F2.03
(-10V...10V, 4...20mA)
Pressure command corre-
F2.04 sponding to 5V, 10V or
20mA
Pressure command null off-
F2.05
set in V or mA
Pressure feedback corre-
F2.06 sponding to 5V, 10V or
20mA
Pressure feedback null off-
F2.07
set in V or mA
Flow command correspond-
F2.08
ing to 5V, 10V or 20mA
Flow command null offset in
F2.09
V or mA
Tab. 6-1: Analog input parameter list
As the default FcP 5020 configuration, analog input AI2 [F2.01 = 2] is configured
as the pressure feedback input. Analog input AI1 or EAI/EAI2 has no preassigned
configuration by the FcP 5020.
The analog inputs F2.00...F2.03 are mutually exclusive, which therefore do not
allow for any identical setting (except 0) between the parameters. When a re-
peated non-zero value entered, the former will reset to 0 automatically, i.e. the
last entered takes effective.
For broken wire protection of analog input, please check the following table for
setting range of E1.61. For more information please refer to EFC 5610 converter
document (R912005856 or R912005854).
Code Name
E1.61 Broken wire protection
Tab. 6-2: Parameter E1.61 for broken wire protection
Wire broken monitoring function for all analog inputs can be activa-
ted by E1.61. Default value of E1.61 has been set to 0 in FcP 5020
and 2 in CytroPac default setting.
12/83
Setting Range
0: No function assigned from ASF
1: Pressure command
2: Pressure feedback
3: Flow command
4: Oxygen feedback (for myCro)
0.1...1,000.0 bar
0.0...5.0 V, mA
0.1...1,000.0 bar
0.0...5.0 V, mA
1...5,000 rpm
0.0...5.0 V, mA
Setting Range
0: Inactive
1: Warning
2: Error
Default Min.
0 -
2 -
0 -
0 -
10.0 0.1
0.0 0.1
100.0 0.1
4.0
0.1
(mA)
400 1
0.0 0.1
Default Min.
0 -
DOK-RCON03-FCP5020****-QU04-EN-P
FcP 5020
Attri.
Stop
Stop
Stop
Stop
Stop
Stop
Stop
Stop
Stop
Stop
Attri.
Stop
