FcP 5020
Code Name
F2.36 DO1 output
F2.37 EDO output
F2.38 EDO2 output
F2.40 Relay 1 output
F2.41 Extension relay output
Tab. 8-2: Parameter list of group F2
Analog output setting:
For example:
F2.31=1: Pressure command
●
F2.31 = 2: Pressure feedback
●
F2.31 = 3: Setting speed
●
F2.31 = 4: Output speed
●
DOK-RCON03-FCP5020****-QU04-EN-P
Setting range
0: No function assigned from ASF
1: Converter warning
2: Green CytroPac flashing LED
3: Red CytroPac flashing LED
4: Oxygen too high (for myCro)
5: Pressure too low (for myCro)
0: No function assigned from ASF
1: Converter warning
2: Green CytroPac flashing LED
3: Red CytroPac flashing LED
4: Oxygen too high (for myCro)
5: Pressure too low (for myCro)
6: Degas/gas valve control (for my-
Cro)
0: No function assigned from ASF
1: Converter warning
2: Two points / double pump control
Bosch Rexroth AG
FcP 5020 Parameter List
Default Min.
1 -
0 -
0 -
0 -
0 -
Attri.
Run
Run
Run
Run
Run
69/83
