FcP 5020 Parameter List

8.3 Group F2: Input and Output Parameter

Code
Name
F2.00 Analog input AI1
F2.01 Analog input AI2
External analog input EAI
F2.02
(-10V...10V, 4...20mA)
External analog input EAI2
F2.03
(-10V...10V, 4...20mA)
Pressure command corre-
F2.04
sponding to 5V, 10V or 20mA
Pressure command null offset
F2.05
in V or mA
Pressure
feedback
F2.06
sponding to 5V, 10V or 20mA
Pressure feedback null offset
F2.07
in V or mA
Flow command correspond-
F2.08
ing to 5V, 10V or 20mA
Flow command null offset in V
F2.09
or mA
66/83
Setting range
0: No function assigned from ASF
1: Pressure command
2: Pressure feedback
3: Flow command
4: Oxygen feedback (for myCro)
0.1...1,000.0 bar
0.0...5.0 V, mA
corre-
0.1...1,000.0 bar
0.0...5.0 V, mA
1...5,000 rpm
0.0...5.0 V, mA
Default Min.
0
2
0
0
10.0
0.1
0.0
0.1
100.0
0.1
4.0
0.1
(mA)
400
1
0.0
0.1
DOK-RCON03-FCP5020****-QU04-EN-P
FcP 5020
Attri.
-
Stop
-
Stop
-
Stop
-
Stop
Stop
Stop
Stop
Stop
Stop
Stop
