FcP 5020
Code Name
F2.36 DO1 output
F2.37 EDO output
F2.38 EDO2 output
F3.12 Proportional gain [0]
F3.13 Integral time 1 [0]
F3.16 Differential gain [0]
F3.19 System minimum speed [0] -5,000...5,000 rpm
F3.32 Proportional gain [1]
F3.33 Integral time 1 [1]
F3.36 Differential gain [1]
F3.39 System minimum speed [1] -5,000...5,000 rpm
Pressure command arrived
F3.40
threshold
Maximum system pressure
F4.17
warning time delay
Maximum pump pressure
F4.18
error time delay
Drive start level via AI (for
F4.70
myCro)
Drive stop level via AI (for
F4.71
myCro)
Oxygen too high warning
F4.72
level
Oxygen too high warning
F4.73
delay
DOK-RCON03-FCP5020****-QU04-EN-P
Block Diagram of Main Functions
Setting range
0: No function assigned from ASF
1: Converter warning
2: Green CytroPac flashing LED
3: Red CytroPac flashing LED
4: Oxygen too high (for myCro)
5: Pressure too low (for myCro)
0: No function assigned from ASF
1: Converter warning
2: Green CytroPac flashing LED
3: Red CytroPac flashing LED
4: Oxygen too high (for myCro)
5: Pressure too low (for myCro)
6: Degas/gas valve control (for my-
Cro)
0.00...500.00 rpm/bar
0...999 ms
0.000...10.000 (rpm/bar)*s
0.00...500.00 rpm/bar
0...999 ms
0.000...10.000 (rpm/bar)*s
0.1...1000.0 bar
0.0...6000.0 s
0.0...6000.0 s
0.0...20.0 V, mA
0.0...20.0 V, mA
0.0...20.0 V, mA
0.0...100.0 hours
Bosch Rexroth AG
FcP myCro
default default
1 4
0 5
0 0
8.00 2.00
80 200
0.000 0.000
0 500
8.00 2.00
80 200
0.000 0.000
0 500
5.0 5.0
0.0 60.0
0.0 60.0
14.2 14.2
10.4 10.4
15.5 15.5
4.0 4.0
59/83
