Bosch Rexroth AG
Block Diagram of Main Functions
Code Name
Pressure too low warning
F4.74
level
Pressure too low warning
F4.75
delay
d0.88 Warning type
E0.01 First run command source
E0.45 Power loss restart mode
E2.01 DO1 output setting
E2.15 Relay1 output selection
H8.05 EAI input mode
H8.20 EDO output setting
Extended relay output se-
H8.21
lection
U1.00 Run monitoring display
U1.10 Stop monitoring display
Tab. 7-28: Different parameter list between myCro and FcP default setting
60/83
Setting range
0.0...300.0 bar
0.0...100.0 s
0...10: See tab. 8-6 "Monitoring pa-
rameter" on page 75
11: Oxygen too high
12: System pressure too low
0: Panel
1: Multi-function digital input
2: Communication
0: Inactive
1: Active for panel control
2: Active only for 2-wire control
0...99
0...99
0: 0...20 mA
1: 4...20 mA
2: 0...10 V
3: 0...5 V
4: 2...10 V
5: -10...10 V
0...25
0...99
0...99
FcP
default
100.0
60.0
-
1
0
1: Convert-
er running
14: Con-
verter error
0
1: Convert-
er running
1: Convert-
er running
0: Output
frequency
2: Setting
frequency
DOK-RCON03-FCP5020****-QU04-EN-P
FcP 5020
myCro
default
100.0
60.0
-
0
1
0: Convert-
er ready
15: Con-
verter OK
1
0: Convert-
er ready
14: Con-
verter error
33: I/O card
EAI input
33: I/O card
EAI input
