Table 27. Startup checklist (continued)
Electric heat circuits have continuity
1
Perform electric heat start up procedure
2
Verify heating system matches name plate
3
Gas Heat (if applicable)
Gas heat piping includes drip leg previously installed by installing contractor
1
Gas heat flue assembly fully installed
2
Gas heat condensate line and heat tape installed where applicable
3
Verify heating system matches name plate
4
Perform Gas Heat start up procedure in IOM
5
System Checkout
Verify system airflow
1
Verify dampers open and close properly
2
Adjust economizer damper travel
3
Verify compressor operation, voltage and amperage matches name plate information (please document on log sheet)
4
Electric heat operation verified
5
Incoming gas pressure does not drop below 7" water column when burner is on high fire
6
Gas heat operation has been verified with combustion analyzer
7
Operating log completed
8
All panels & doors secured
9
Complete all required documentation
10
Critical Control Parameters and Dry Bulb Changeover Map
Table 28. Critical control parameters
Description
Supply Air Temperature Control Setpoint
Supply Air Temperature Deadband
Supply Air Pressure Setpoint
Supply Air Pressure Deadband
Building Static Pressure Setpoint
Building Static Pressure Deadband
Standby Freeze Avoidance
Relief Enable Setpoint
Economizer Minimum Position Setpoint
Fixed Dry Bulb Economizer C/O Type a (Moist)*
Fixed Dry Bulb Economizer C/O Type b (Dry)*
Fixed Dry Bulb Economizer C/O Type c (Marine)*
Fixed Reference (Enthalpy Changeover)
Differential Comparative (Enthalpy Changeover)
Notes:
1.
See map in next figure for dry bulb changeover.
Examples:
- Minneapolis, Minnesota is in "Region 6" and resides in "Moist" subregion, thus designation is 6b. Economizer changeover setting should be 75°F.
- Charleston, South Carolina is in "Region 3" and resides in "Moist" subregion, thus the designation is 3c. Economizer changeover setting should be 65°F.
2.
Go to SETUP menu and input setting for parameters listed in the table above.
3.
Use the Dry bulb changeover map to determine region of country based on unit site location.
4.
Fixed speed compressor units 8°F deadband.
5.
eFlex™ compressor units 4°F deadband.
RT-SVX063G-EN
Suggested
Parameter
Region 1 Region 2 Region 3 Region 4 Region 5 Region 6 Region 7
55°F
8°F
1.8" w.c.
0.1" w.c.
0.03" w.c.
0.04" w.c.
20%
10%
10%
TOA > 65°
TOA > 65°
F
TOA > 75°F
HOA > 28 Btu
HOA > HRA
Economizer Settings
TOA > 65°
TOA > 65°
TOA > 70°
F
F
F
TOA > 75°
TOA > 75°
TOA > 75°
F
F
Startup the Unit
Completed?
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
TOA > 70°
TOA > 70°
F
F
F
F
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
63
