Trane Startup Checklist - Trane IntelliPak with Symbio 800 Installation, Operation And Maintenance Manual

Startup the Unit

Trane Startup Checklist

This checklist is intended to be a guide for the Trane
technician just prior to unit 'startup'. Many of the
recommended checks and actions could expose the
technician to electrical and mechanical hazards. Refer to
the appropriate sections in the this manual for appropriate
procedures, component specifications and safety
instructions.
Job Name
Job Location
Sales Order #
Unit DL # (special units)
Starting Sales Office
Table 27. Startup checklist
General Start-up
Is adequate access/egress provided?
1
Initial site inspection performed?
2
Unit exterior inspected for damage (dents, bends, missing panels, doors work properly)?
3
Unit clearances adequate to avoid air recirculation?
4
Verify crankcase heaters are working and on for 8 hours prior to unit start
5
Verify unit interior is free from debris and obstructions, etc.
6
All unit drain lines and traps are properly installed
7
Verify unit is grounded. Confirm a ground wire is coming from the power source
8
Verify main power feed wire gauge is properly sized for current load
9
Verify all wiring connections are tight
10
Verify all field control wiring for CV, SZVAV or VAV controls are complete
11
Verify hold down bolts from fan sections removed
12
Fan section isolators checked/adjusted (approximately ¼" gap above shipping block)
13
Verify compressor oil levels at proper levels
14
Compressor discharge service valves and optional suction service valves open/back seated
15
Verify fans rotate freely
16
Verify refrigerant charge on each circuit
17
Verify correct voltage supplied to unit and electrical heaters
18
Verify there are no unit phase monitor errors.
19
Verify all fans rotate in proper direction
20
Verify fan amperages within nameplate specs (please document on log sheet)
21
Unit Configuration and Setup
Verify model number in the UCM configuration matches unit model number on nameplate
1
Configure unit using IOM and critical control parameters using critical control parameters table
2
Air Cooled Condenser
All coil fins inspected and straightened
1
Condenser fans are rotating freely
2
Verify the fan blade set-screws to the motor shaft of the condenser fan assemblies are tight
3
Outside Air and Economizer (if applicable)
Verify damper linkages are tight/adjusted and tip seals are in good condition
1
Outside air pressure sensor installed and tubing connected to fitting on unit exterior
2
Duct pressure tubing connected to duct pressure sensor
3
Tubing from controlled space connected to space pressure fitting (StatiTrac)
4
Electric Heat (if applicable)
62
Important: This checklist is not intended as a substitution
for the contractor's installation instruction.
Important: Except where noted, it is implied that the Trane
technician is to use this checklist for
inspection/verification of prior tasks completed
by the general contractor at installation. Use
the line item content to also record the
associated values onto the Trane unitary
packaged equipment log.
