Service and Maintenance

WARNING
Hazardous Voltage and Exposure to
Ultraviolet Radiation!
This product contains components that emit high-
intensity ultraviolet (UV-C) radiation which can be
harmful to unprotected eyes and skin, and cause
serious damage to the equipment.
Failure to disconnect power before servicing could
result in burns or electrocution which could result in
death or serious injury.
Disconnect all electrical power, including remote
disconnects, and make sure the UV lights are off
before servicing. Follow proper lockout/tagout
procedures to ensure the power cannot be
inadvertently energized.
Trane does not recommend field installation of
ultraviolet lights in its equipment for the intended
purpose of improving indoor air quality. Trane accepts
no responsibility for the performance or operation of
our equipment in which ultraviolet devices were
installed outside of the Trane factory or its approved
suppliers.
Table 58. Filter data
2" Panel Filters (MERV 4
or MERV 8)
Unit
Tons
Face
Size of
Qty Area
Each
(ft
4 16x20x2
20 6 20x20x2 32.2
2 20x24x2
4 16x20x2
25 6 20x20x2 32.2
2 20x24x2
4 16x20x2
30 6 20x20x2 32.2
2 20x24x2
3 20x20x2
40 7 20x24x2 39.7
2 24x24x2
3 20x20x2
50 7 20x24x2 39.7
2 24x24x2
RT-SVX063G-EN
Evaporator Filters
4" Panel Filters (MERV 8
or MERV 14)
Face
Size of
Qty Area
Each
2 2
) (ft )
4 16x20x4
6 20x20x4 32.2
2 20x24x4
4 16x20x4
6 20x20x4 32.2
2 20x24x4
4 16x20x4
6 20x20x4 32.2
2 20x24x4
3 20x20x4
7 20x24x4 39.7
2 24x24x4
3 20x20x4
7 20x24x4 39.7
2 24x24x4
Compressor Circuit Breakers
Every fixed speed compressor is protected by a circuit
breaker. If replacement is necessary, please refer to the
circuit breaker nameplate to identify the part number and
manufacturer. Contact the circuit breaker manufacturer to
locate the datasheet for the circuit breaker to find the "must
hold / must trip" values.
Supply and Relief/Return Fan Overloads
When the VFD bypass option is selected, each supply and
relief/return fan is protected by a motor overload when in
VFD bypass mode. On 60-75T units with dual DDP supply
fan motors (with or without VFD bypass option), each
supply fan motor is protected by a motor overload in both
standard operation and VFD bypass mode. The motor
overloads are factory set to the motor FLA value and
should not be adjusted. If the current to the motor exceeds
the overload dial setting value, the overload relay auxiliary
contacts will trip and interrupt the control signal to the run
and bypass contactor coils. This will remove power from
the fan motor and stop operation.
Cartridge Filters
2" Prefilters
Size of Size of
Qty Qty
Each Each
4 16x20x2 4 16x20x12
4 20x20x2 4 20x20x12
4 20x24x2 4 20x24x12
4 16x20x2 4 16x20x12
4 20x20x2 4 20x20x12
4 20x24x2 4 20x24x12
4 16x20x2 4 16x20x12
4 20x20x2 4 20x20x12
4 20x24x2 4 20x24x12
2 20x20x2 2 20x20x12
6 20x24x2 6 20x24x12
4 24x24x2 4 24x24x12
2 20x20x2 2 20x20x12
6 20x24x2 6 20x24x12
4 24x24x2 4 24x24x12
Final Filters
Cartridge Filters
2" Prefilters
Face
Size of
Area Qty Qty
Each
2
(ft )
4 16x20x2 4
33.3 4 20x20x2 4
4 20x24x2 4
4 16x20x2 4
33.3 4 20x20x2 4
4 20x24x2 4
4 16x20x2 4
33.3 4 20x20x2 4
4 20x24x2 4
4 20x20x2 4
41.6 6 20x24x2 6
2 24x24x2 2
4 20x20x2 4
41.6 6 20x24x2 6
2 24x24x2 2
Face
Size of
Area
Each
2
(ft )
16x20x12
20x20x12 33.3
20x24x12
16x20x12
20x20x12 33.3
20x24x12
16x20x12
20x20x12 33.3
20x24x12
20x20x12
20x24x12 39.1
24x24x12
20x20x12
20x24x12 39.1
24x24x12
