Figure 86. Pressure curve — 70 tons eFlex variable speed
70T eFlex Variable Speed - circuit 1 only
(Use 70T Standard Capacity for circuit 2)
500
450
400
350
300
250
200
90 100 110
Note: Full load acceptable subcooling range: 13-23°F
Figure 87. Pressure curve — 75 tons standard efficiency
75T Standard Capacity
500
450
400
350
300
250
200
90 100 110
Note: Full load acceptable subcooling range: 13-23°F
RT-SVX063G-EN
120 130 140 150
Suction Pressure, PSIG
120 130 140 150
Suction Pressure, PSIG
105 F Ambient
95 F Ambient
85 F Ambient
75 F Ambient
65 F Ambient
160 170 180
105 F Ambient
95 F Ambient
85 F Ambient
75 F Ambient
65 F Ambient
160 170 180
Service and Maintenance
