6.2 Start
The router is put into operation when the power supply is connected to this router. By
default, the router will automatically start to log on to the default APN. DHCP server will start
to assign addresses for devices on the Ethernet port ETH. Router behavior can be changed
via the web interface. This is described in detail in the Configuration manual.
6.3 Configuration
Attention! If no SIM card is inserted in the router, it is not possible to operate. Inserted
SIM card must have activated data transmission.
6.3.1 Configuration over web browser
For status monitoring, configuration and administration of the router is available a web
interface which can be accessed by entering the IP address of the router into the web browser.
The default IP address of the router is 192.168.1.1. Attention, it is necessary to use HTTPS
protocol for secure communication over a network!
Figure 22: Entering the IP address of the router
Configuration may be performed only by the user "root" with default password "root".
Figure 23: Entering login information
24
6. FIRST USE
