5.5 Mounting Recommendations

possibility to be put on a work surface,
DIN rail EN 60715 with included clip CKD-SBD23.
For the most of applications with a built-in router in a switch board it is possible to recognize
two kinds of environments:
no public and industry environment of low voltage with high interference,
public environment of low voltage without high interference.
It is possible to mount the router to a switch board ror both of these environments. Then
there is no need to perform any immunity or emission test in relation to EMC according to EN
61439-1:2011.
For complying with EN 61439-1:2011 standard is necessary to observe the following
router installation into switchboard:
For whip antennas we recommend to observe a distance of 6 cm from cables and metal
surfaces on every side due to the elimination of interference. While using an external
antenna except for the switch-board it is necessary to fit a lightening conductor.
Before mounting a router on sheet-steel we recommend using a "cable" antenna.
For every cables we recommend to bind the bunch, we recommend for this use:
– Length of the bunch (combination of power supply and data cables) can be maxi-
mum 1.5 m. If the length of data cables exceeds 1.5 m or in the event of, the cable
leads towards the switch – board. We recommend installing over – voltage protec-
tors (surge suppressors).
– With data cables they mustn't carry cables with reticular tension
Sufficient space must be left in front of individual connectors for handling of cables,
For correct function of the router we recommend to use in the switch-board earth-bonding
distribution frame for grounding of power supply of router, data cables and antenna.
5. ROUTER DESIGN
12
230 V/50 Hz.
