5.8.1 Status indication

About router status inform three LED indicators on the front panel. The ETH port has two
additional LEDs that provide information about the port status.
Caption Color State
PWR Green Blinking
On
Fast blinking
DAT Red Blinking
WAN Yellow LED goes out
1x per one sec.
LED goes out
1x per two sec.
LED goes out
1x per five sec.
ETH Green On
Off
ETH Yellow On
Blinking
Off
State indication of WAN LED is updated every 10 seconds.
Description
Router is ready
Starting of the router
Updating firmware
Communication in progress on the radio channel
Signal strength is from –50 dBm to –69 dBm
Signal strength is from –70 dBm to –89 dBm or differ-
ence between neighbours cells is exactly 3 dBm
Signal strength is from –90 dBm to –113 dBm or differ-
ence between neighbours cells is smaller than 3 dBm
Selected 100 Mbps
Selected 10 Mbps
The network cable is connected
Data transmission
The network cable is not connected
Table 5: Status indication
