7.5 Technical Parameters of Module

LTE module for NAM – AT&T
LTE parameters
UMTS parameters
Other parameters
Table 15: Technical parameters of module for NAM – AT&T

7.6 Technical Parameters of WiFi

WiFi
Antenna connector
Supported WiFi band
Standards
2.4 GHz supported channels
RX Sensitivity
TX Output Power
Type of device
Bit rate 10 Mbps (DL) / 5 Mbps (UL)
LTE FDD Cat.1, 3GPP release 9 compliant
Supported bandwidths: 5 Mhz, 10 Mhz, 20 Mhz
Supported frequencies: 700 / 850 / 1700(AWS) / 1900 MHz
Bit rate 384 kbit/s (DL) / 384 kbit/s (UL)
Supported frequencies: 850 / 1900 MHz
Rx Diversity and MIMO DL 2x2
SMS over IMS
R-SMA – 50 Ohms
2.4 GHz
802.11b, 802.11g, 802.11n
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11
11b, 11 Mbps: typ. -85 dBm
11g, 54 Mbps: typ. -70 dBm
(HT20) 11n, MSC7: typ. -66 dBm
(HT40) 11n, MSC7: typ. -62 dBm
11b, 11 Mbps: min. 18, typ. 19, max. 20 dBm
11g, 54 Mbps: min. 14.5, typ. 16, max. 17.5 dBm
802.11n (HT20): min. 13.5, typ. 15, max. 16.5 dBm
802.11n (HT40): min. 13.5, typ. 15, max. 16.5 dBm
Access point, station
Table 16: Technical parameters of WiFi
