7.3 Standards and Regulations

The router complies with the following standards and regulations.

Standards and regulations

EMC
Safety
REACH and RoHS compliant

7.4 Type Tests and Environmental Conditions

Phenomena
ESD
RF field AM
modulated
Fast transient
Surge
RF conducted
Radiated emission
Conducted
emission
Dry heat
Cold
Damp heat
Temperature variation
Vibration
Isolation
Table 14: Type tests and environmental conditions
ETSI EN 301 489-1 v1.9.2,
IEC 61000-6-2:2005, IEC 61000-6-3:2006
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013,
EN 62311:2008
Table 13: Standards and regulations
Test Description
EN 61000-4-2 Enclosure contact
Enclosure air
IEC 61000-4-3 Enclosure
EN 61000-4-4 Signal ports
Power port
Ethernet port
EN 61000-4-5 Ethernet port
Power port
EN 61000-4-6 All ports
EN 55022 Enclosure
EN 55022 DC power ports
Ethernet ports
EN 60068-2-2 +75 C, 40 % rel. humidity
EN 60068-2-1 -40 C
EN 60068-2-30, +55 C / +25 C, 12 h – 12 h, 2 cycles,
test Db
EN 60068-2-14 Nb -40 C / +70 C, 3 h / 3 h, 2 cycles, 3 K/min
EN 60068-2-64 ed. 2 Vibration, broadband random and guidance
EN 60068-2-27 ed. 2 15 g peak, 11 ms, half sin
27
7. TECHNICAL PARAMETERS
Test levels
6 kV (crit. A)
8 kV (crit. A)
10 V/m (crit. A)
(80 – 2700 MHz)
2 kV (crit. A)
2 kV (crit. A)
2 kV (crit. A)
2 kV (crit. A), shielded cab.
0,5 kV (crit. A)
10 V/m (crit. A)
(0,15 – 80 MHz)
Class B
Class B
Class B
