Preparations before recording – Power supply

Attaching and removing the battery

1
Install the battery by inserting it in the direction shown in the figure.
•
Insert the battery until it clicks and locks.
Removing the battery
Make sure that the power switch is set to <OFF> and the status indicator is turned off, and then remove by holding onto it taking
care not to drop. ( Turning the unit on/off:
•
While pressing the battery release button (A), remove the battery.

Standard charging time and recordable time

Battery parts number
AG-VBR59 (supplied/optional)
AG-VBR89 (optional)
AG-VBR118 (optional)
Battery parts number
AG-VBR59 (supplied/optional)
AG-VBR89 (optional)
AG-VBR118 (optional)
•
"h" is an abbreviation for hour and "min" for minute.
•
The charging time is the time when the operating ambient temperature is 25 °C (77 °F) and operating relative humidity is
60 %. At other temperature and humidity the charging time may take longer.
•
Continuous recordable time is the time when the unit is used fulfilling all of the following conditions. If you use the unit in other
conditions, continuous recordable time will shorten.
– When set to the factory default menu settings ([FILE FORMAT] is [MOV] and [REC FORMAT] is [2160-59.94p/HEVC
LongGOP 200M]/[2160-50.00p/HEVC LongGOP 200M])
– When the LCD monitor is used and cable is not connected to the external input/output terminal
•
The charging time is the time to charge when the charging capacity of the battery is used up. The charging time or
the continuous recordable time differs depending on the use condition such as high or low temperature.
•
Battery is warm after using or after charging, but this is not a malfunction.
41)
(A)
Voltage/capacity (minimum)
7.28 V/5900 mAh
7.28 V/8850 mAh
7.28 V/11800 mAh
[FREQUENCY]
[59.94Hz]
[50.00Hz]
[59.94Hz]
[50.00Hz]
[59.94Hz]
[50.00Hz]
Continuous recordable time
Approx. 3 h 50 min
Approx. 4 h
Approx. 5 h 45 min
Approx. 6 h
Approx. 7 h 40 min
Approx. 8 h 5 min
33
Charging time
Approx. 3 h 20 min
Approx. 4 h
Approx. 4 h 40 min
Approx. 4 h 25 min
Approx. 4 h 40 min
Approx. 6 h 35 min
Approx. 7 h
Approx. 8 h 50 min
Approx. 9 h 20 min
