Please read these instructions carefully before using this product, and save this manual for future use.
More detailed operating instructions are available in "Owner's
Manual (PDF format)".
To read it, download it from the website.
https://eww.pavc.panasonic.co.jp/hdw/oi/X2000/
Register online at http://shop.panasonic.com/support
If you have any questions, visit :
U.S.A. : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support
PP
Basic Owner's Manual
4K Video Camera
HC-X1500
Model No.
HC-X2000
(U.S. customers only)
DVQX2023ZA
F0120TY0
