Post eVolve Series Installation Manual
6
DATA GENERAL SPECIFICATIONS
Light beacon
Enclosure rating
Enclosure material
Enclosure door
Net weight
Dimensions (W x H x D)
Cable (optional)
Power supply
Input voltage
Frequency
Operating temperature
Operating temperature with
Low Temperature Kit (optional)*
Operating humidity
Overcurrent protection
Overvoltage protection
Surge protection (optional)
* Equipment to be installed outdoor shall be provided with the Low Temperature Kit in order to
comply with the IEC 61851-1:2017
** This protection is not available for model C63
18
RGB Colour indicator
IP54 / IK10
Aluminium & ABS
Frontal key locked door
55Kg
450 x 1550 x 290 mm
Type 1; Type 2
1P+N+PE / 3P+N+PE
230VAC+/- 10% / 400VAC+/-10%
50Hz / 60Hz
-5ºC to +50ºC
-25ºC to +50ºC
5% to 95% Non-condensing
Miniature Circuit Breaker (MCB)
IEC 60898-1 (Curve C)
RCD Type A (30mA) + 6mA DC** / Type B
(optional)
Transient surge protector
IEC 61643-1 (Class II)
