LIGHTMIC CONTROLS AND CONNECTIONS

4
5
6
1.
ON/OFF/MUTE Switch:
located on the side of the LightMic,
turns the unit on or off.
2.
Channel Select Switch (CH A/B):
This switch allows for selection
between Channel A or B. If you are
using a single microphone/transmit-
ter for your system, we recommend
using Channel A.
3.
Power/Charge LED Indicator:
light glows blue when the LightMic
is powered ON, and red when
charging.
4.
External Microphone Input (MIC):
Use the 3.5 mm MIC jack for the
optional TK-250 headset microphone
(part# MC-TK250LTM).
7 | REDCAT User Manual
LT-71
This switch,
The
R E D C A T U s e r M a n u a l
LT-71
3
5.
Auxiliary (AUX):
player or other audio source into
this jack to wirelessly transmit the
audio signal to be played through
the REDCAT.
6.
Charger Input (CHARGER):
the wall charger into this jack for
daily charging. The LED on the front
of the LightMic will glow red to
indicate charging.
1
2
Plug a laptop, MP3
Plug
