• List of the installed analog output ports (1):
select, which analog-output should be configured. To select an analog-
output, move the up/down arrow keys.
• Details (2):
Here the operator can open the configuration screen for the
selected output port. To open the details-menu, push
• Auto configuration (3):
would be configured by default values.
• Test (4):
The test-menu is for testing the analog outputs. To open the test-
menu, push F3
The navigation inside the menu taken place with the
OK key, the analog-output can be edited:
The settings for an analog-output can be change in the "Analog output details"
menu. See the screenshot below.
1
2
3
4
5
6 7
If the operator pushes this key (F2) the output pins
or OK.
For navigation
and selection
Section (1):
o
analog-output will be change.
Sample point (2):
o
the sample point. This means, that the
analog-output signal from the choose
sample point will be transmitted to the
process control system.
Meas. Item (3):
o
selects the measurement item, which should
be transmitted. At the chart below, the
typical measurements items are listed.
Basically, all measurement-channels, which
can be measured, can be selected at this
point.
8
Meas. Unit (4):
o
the transmit signal have. This point cannot
be changed.
Minimum (4mA) (5):
o
entering the equivalent measurement value,
for a current of 4 mA.
Maximum (20mA) (5):
o
entering the equivalent measurement value,
SWG 100 BIO Ex User Manual
At this list the operator can
F1 or OK.
up/down
arrow keys. With the
+
Shows the operator, which
The operator can select
At this point the operator
This point shows, which unit
Here the operator
Here the operator
of
