mru SWG100 BIO-EX User Manual page 118

MRU GmbH
Position 1: Acid-gas filter (#56795)
Required materials 2x Acid gas filter (#56795), contained in the service- set.
Required tools: Needle-nose pliers.
Exchange interval: Exchange necessary, if filter turns from purple to white.
Steps:
1.
Remove exhausted acid gas filter from
the clips.
2.
Pull the viton tubes from the exhausted
acid gas filter. If it is necessary, use needle-
nose pliers.
3.
Plug the viton tubes on the new acid gas
filters. Be sure, that the tubing is correct.
(The single tubes are signed with "+" and
"-", see sketch on the right side.)
Steps:
Pull the viton-tubes from the filter unit. If it is necessary, pliers can be used to solve the
tubes from the filter unit.
Remove the
exhausted filter
unit.
Remove the exhausted filter unit from the clip.
SWG 100 BIO Ex User Manual
Install a new filter
unit.
+ Socket
- Socket
of
Page 118 150
