Programming
Resolution (bits) of encoder
Two variants are available for programming.
To switch over, press and hold
Variant 1 (display of one 10s place)
0 * 25 Bit
1 24 Bit
2 13 Bit
3 12 Bit
Variant 2 (display of two 10s places) (from 10/01/03)
01 Direct entry of resolution with two 10 s places between 01 - 25 bits.
:
25
MSB Assignment
0 * Numerical bit
1 Prefix sign bit
If the highest value bit (MSB) of the rotary encoder is used as the prefix sign bit, presets P1, P2 and the
start count value SC can be programmed with a prefix sign. The
in the programming lines of parameter 3.
X9751171-A010047MSC
key for 10 seconds.
Permanently set resolution with one 10s place of 0 - 3.
key permits confirmation of the prefix sign
MICRO-EPSILON
Line 25
Select variant
Line 26
